Duerkopp Adler 868 Manuale utente

868

Special Sewing Machine

Instruction manual

Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld

Telefon +49 (0) 521 / 9 25-00 • Telefax +49 (0) 521 / 9 25 24 35 • www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

03/2011 Rev. index: 00.0 Printed in Federal Republic of Germany 0791 868751

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner,

even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Contents Page:

Preface and general safety instructions

Part 1: Operating Instructions Class 868 – Original Instructions

(Edition 03/2011)

1 Product description ............................................ 5

2 Designated use ............................................... 5

3 Subclasses .................................................. 6

4 Optional equipment............................................. 8

5 Technical data

5.1 Technicaldatasubclasses......................................... 11

6 Operation

6.1 Threadingtheneedlethread........................................ 13

6.2 Adjustingtheneedle-threadtension................................... 15

6.2.1 Function of the thread main tension and the thread supplementary tension in relation

tothesewingfootlifting .......................................... 16

6.2.2 Reparationseamwiththreadtensionalwaysclosed ......................... 16

6.2.3 Function of the thread’s supplementary tension in relation to the stroke adjustment

andtheSpeedomat ............................................. 17

6.3 Openingthethreadtension......................................... 17

6.4 Shortstitch .................................................. 18

6.4.1 Shortstitchattheseambeginning.................................... 18

6.4.2 Shortstitchattheendofaseam..................................... 18

6.4.3 Shortstitchattheseambeginningandseamend........................... 18

6.5 Switching the supplementary tension on and off with machines without thread trimmer .... 19

6.6 Adjustingthethreadregulator....................................... 20

6.7 Winding on the hook thread ........................................ 21

6.8 Changing the hook-thread bobbin .................................... 22

6.9 Setting the hook thread tension ...................................... 23

6.10 Insertingandchangingtheneedlewithsingle-needlemachines.................. 24

6.11 Insertingandchangingtheneedlewithdouble-needlemachines.................. 25

6.12 Liftingthesewingfoot............................................ 26

6.13 Lockingthesewingfeetinliftedposition ................................ 27

6.14 Sewing-footpressure............................................ 27

6.15 Sewing-footstroke.............................................. 28

6.16 Settingthestitchlength........................................... 30

6.17 Keypadonthemachinearm........................................ 31

7 Sewing drive and operating panel ................................... 32

8Sewing..................................................... 33

Contents Page:

9 Maintenance

9.1 Cleaningandtesting............................................. 35

9.2 Lubrication................................................... 37

10 Optional equipment

10.1 Seamcenterguide.............................................. 38

10.2 Repair ..................................................... 39

1 Product description

The DÜRKOPP ADLER 868 is a special sewing machine for universal

use.

·It is a flatbed double-lockstitch machine with bottom feed, needle

feed and alternating upper foot feed.

·Depending on the subclass it comes as single or double needle

automat, with or without electromagnetic thread cutter, with or

without edge trimmer.

·Equipped with a large or oversized two-piece vertical hook.

·With a maximum of 20 mm fabric clearance when sewing feet are

lifted.

·A safety clutch prevents a changing of the hook setting or a hook

damage in the case of a thread deflection into the shuttle track.

·Automatic wick lubricating with an inspection glass on the arm for

machine and hook lubrication.

·Integrated winder.

2 Designated use

The 868 class is a sewing machine designed for sewing light to

medium-heavy material. Such material is generally made of textile

fibers, but it may also be leather. It is used in the clothing industry and

for domestic and motor-vehicle upholstery.

This special sewing machine can also be used to produce so-called

technical seams. In this case, however, the operator must assess the

possible dangers which may arise (with which DÜRKOPP ADLER AG

would be happy to assist), since such applications are on the one

hand relatively unusual and, on the other, so varied that no single set

of criteria can cover them all. The outcome of this assessment may

require appropriate safety measures to be taken.

Generally only dry material may be sewn with this machine. The

material may be no thicker than 10 mm when compressed by the

lowered sewing feet. The material may not contain any hard objects,

since if it does the machine may not be operated without an

eye-protection device. No such device is currently available.

The seam is generally produced with textile-fibre sewing thread of

gauge up to 11/3 NeB (cotton), 11/3 Nm (synthetic) or 11/4 Nm

(covering yarn).

Before using any other thread the possible dangers arising must be

assessed and appropriate safety measures taken if necessary.

This special sewing machine may be set up and operated only

in dry, well-maintained premises. If the sewing machine is used in

premises which are not dry and well-maintained it may be

necessary to take further precautions, which should be agreed upon in

advance (see EN 60204-31:1999).

As manufacturers of industrial sewing machines we proceed on the

assumption that personnel who work on our products will have

received training at least sufficient to acquaint them with all normal

operations and with any hazards which these may involve.

3 Subclasses

868-190020 Single-needle double-lockstitch post bed machine

with bottom feed, needle feed, alternating upper

foot feed and large hook.

867-290020 Double-needle double-lockstitch post bed machine

with bottom feed, needle feed, alternating upper

foot feed and large hook.

868-190322 Single-needle double-lockstitch post bed machine

with bottom feed, needle feed, alternating upper

foot feed, electro-pneumatic rapid stroke

adjustment with automatic speed limitation,

operated via knee lever, electro-magnetic thread

cutter, electro-pneumatic seam bartacking,

electro-pneumatic second stitch length and sewing

foot lifting. With large hook, with integrated sewing

lamp.

Function keys for: manually sewing backward,

needle high/low/single stitch, switching on/off of the

bartack, 2nd stitch length, switching on/off of the

supplementary thread tension .

868-290322 Double-needle double-lockstitch post bed machine

with bottom feed, needle feed, alternating upper

foot feed, electro-pneumatic rapid stroke

adjustment with automatic speed limitation,

operated via knee lever, electro-magnetic thread

cutter, electro-pneumatic seam bartacking,

electro-pneumatic second stitch length and sewing

foot lifting. With large hook, with integrated sewing

lamp.

Function keys for: manually sewing backward,

needle high/low /single stitch, switching on/off of

the bartack, 2nd stitch length, switching on/off of

the supplementary thread tension.

868-390322 Double-needle double-lockstitch post bed machine

with bottom feed, needle feed, alternating upper

foot feed, electro-pneumatic rapid stroke

adjustment with automatic speed limitation,

operated via knee lever, electro-magnetic thread

cutter, electro-pneumatic seam bartacking,

electro-pneumatic second stitch length and sewing

foot lifting. With large hook, with integrated sewing

lamp.

Left post.

Function keys for: manually sewing backward,

needle high/low /single stitch, switching on/off of

the bartack, 2nd stitch length, switching on/off of

the supplementary thread tension.

4 Optional equipments

For the 868 the following optional equipments are available:

Order No. Optional equipment Subclasses

868-190020

868-290020

868-190322

868-290322

868-390322

0867 590014 Electro-pneumatic needle cooler x

from the top

0867 590064 Pneumatic connection x x x x x

9780 000108 WE-8 maintenance unit for pneumatic

optional equipments x x o o o

9822 510003 Halogen sewing lamp x x x x x

9880 867100 Sewing lamp add-on kit x x x x x

0798 500088 Sewing lamp transformer x x x x x

9880 867103 Sewing lamp LED x x x x x

9880 867102 Integrated sewing lamp LEDs x x o o o

9850 001089 Power supply complete for x x o o o

integrated sewing lamp LEDs

N800 080001 Edge guide, swivelling x x

N800 080004 Roller stop x x

N800 080021 Edge guide, swivelling x x

N800 005650 Seam center guide x x

N800 005655 Seam center guide, swivelling x x

No. according Tape guide with tape-reel bracket x x

to the band size

9805 791113 USB memory key

for transferring data with the x x x x x

Efka control unit DA321G

0797 003031 Pneumatic connection package x x x x

0867 590354 Pneumatic sewing foot lifting x x

Stands

MG55 400364 Stand set MG 55-3 x x x x x

for motor fitting beneath the table,

with pedal

Table top size 1060 x 600 mm

MG55 400374 Stand set MG 55-3 x x x

for motor fixed on machine head,

with Pedal

Table top size 1060 x 600 mm

x = Optional equipment

o = Standard equipment

Altri manuali per 868

Indice

Altri manuali Duerkopp Adler Macchina da cucire

Duerkopp Adler

Duerkopp Adler 275 Manuale utente

Duerkopp Adler

Duerkopp Adler 739-23 Guida

Duerkopp Adler

Duerkopp Adler 745-22 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 744-122 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 743-105 s Guida

Duerkopp Adler

Duerkopp Adler 523-105 Guida

Duerkopp Adler

Duerkopp Adler 745-24 Guida

Duerkopp Adler

Duerkopp Adler 524-105 Guida

Duerkopp Adler

Duerkopp Adler 743-105 s Istruzioni per l'installazione

Duerkopp Adler

Duerkopp Adler 275 Manuale utente

Duerkopp Adler

Duerkopp Adler 743-221 Manuale utente

Duerkopp Adler

Duerkopp Adler 4280i-6 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 869 Manuale utente

Duerkopp Adler

Duerkopp Adler 868 Manuale utente

Duerkopp Adler

Duerkopp Adler 570 Guida

Duerkopp Adler

Duerkopp Adler 669 Premium Manuale utente

Duerkopp Adler

Duerkopp Adler 510 Manuale utente

Duerkopp Adler

Duerkopp Adler 510 Manuale utente

Duerkopp Adler

Duerkopp Adler 550-767 Manuale utente

Duerkopp Adler

Duerkopp Adler 524 Manuale utente

Duerkopp Adler

Duerkopp Adler 1183i-7 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 467 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 4180-1 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 267 Manuale elenco delle parti

Manuali Macchina da cucire popolari di altre marche

Riccar

Riccar RL634DE Manuale utente

Singer

Singer 2517 Manuale utente

Pfaff

Pfaff 3307-1 SERIES Manuale utente

Janome

Janome Quilt Maker Pro 18 VERSA Manuale utente

Siruba

Siruba C007JP Manuale utente

Husqvarna Viking

Husqvarna Viking Designer SE Manuale utente

Singer

Singer 148-5 Manuale utente

IKEA

IKEA SY Manuale utente

Pfaff

Pfaff 571 Manuale utente

Singer

Singer 15-91 Manuale utente

Brother

Brother BB370 Manuale utente

Pegasus

Pegasus WT100 Series Manuale utente

Reliable

Reliable 7100DB Manuale utente

Pfaff

Pfaff 937 Manuale utente

Singer

Singer 6038 Manuale utente

Singer

Singer 413K Manuale utente

Pfaff

Pfaff 1471 E1 Manuale utente

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuale utente
