Duerkopp Adler 910 Manuale utente

910

CNC-Nähanlage für freie Nahtkonturen

CNC sewing unit for free seam contours

Bedienanleitung / Operating Instructions

Aufstellanleitung / Installation Instructions

Serviceanleitung / Service Instructions

Postfach 17 03 51, D-33703 Bielefeld Potsdamer Straße 190, D-33719 Bielefeld Deutsch/Englisch

Telefon +49 (0) 5 21/ 59 25-00 Telefax+49(0)521/9252435www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr.:/Part-No.:

04/2007 Rev. index: 01.0 Printed in Federal Republic of Germany 0791 910001

Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch auszugsweise

Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches Einverständnis der Dürkopp Adler AG

verboten.

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner,

even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Index Page:

Preface and general safety hints

Part 1: Operating instructions cl. 910

(Edition 04/2007)

1. Description of product .......................................... 5

2. Use in accordance with the requirements.............................. 6

3. Subclass................................................... 6

4. Optional equipment ............................................ 7

5. Stands .................................................... 7

6. Technical data ............................................... 8

7. Operating

7.1 Switchingon-Switchingoff-Safestop................................. 9

7.1.1 Switchingon................................................. 9

7.1.2 Switchingoff................................................. 9

7.1.3 Safestop................................................... 9

7.2 Threading in the needle thread...................................... 10

7.3 Adjusting the thread regulator ...................................... 11

7.4 Winding up the bobbin thread....................................... 12

7.5 Changing the hook thread bobbin .................................... 13

7.6 Adjusting the bobbin thread tension ................................... 14

7.7 Changing the needle ............................................ 15

7.8 Adjustingtheliftingmovementoftheclampingplate......................... 16

7.9 Sewingfootpressure............................................ 16

7.10 Sewingfootheight............................................. 17

8. Operating the control of cl. 910

8.1 The operator terminal ........................................... 18

8.1.1 Thekeys................................................... 19

8.2 Userinterface................................................ 20

8.2.1 Structureofmenu.............................................. 20

8.3 Alteringnumericalvalues,parametervalues,selectionofalternatives.............. 21

8.3.1 Alteringnumericalvalues......................................... 21

8.3.2 Selectionofaparameter.......................................... 22

8.4 Mainmenu.................................................. 23

8.4.1 Submenu Sequences............................................ 25

8.4.2 Submenu Counter.............................................. 26

8.4.3 SubmenuServicemenu(Teach-in) ................................... 28

8.5 CallingupMultitest............................................. 42

Index Page:

8.6 Technicianmode .............................................. 49

8.6.1 SubmenuThreadtension......................................... 51

8.6.2 Mechanical adjustment of thread tensions ............................... 52

8.6.3 Calibration.................................................. 53

8.6.4 SubmenuPositions............................................. 54

8.6.5 SubmenuThreadBurnerSettings.................................... 55

8.7 Loading the factory settings........................................ 57

8.8 Saving and loading of programs ..................................... 58

8.8.1 Loading programs into the control .................................... 58

8.8.2 Saving programs on the dongle ..................................... 59

8.8.3 Deletingprogram.............................................. 61

8.8.4 Formatting the dongle ........................................... 62

8.9 Machinefaults................................................ 63

9. Sewing

9.1 Threadbreakagemode .......................................... 68

10. Maintenance

10.1 Cleaning and checking........................................... 70

10.2 Oillubrication................................................ 71

1. Description of product

The Dürkopp Adler 910 is a CNC sewing unit for free seam contours.

The seam contours can be programmed directly at the control panel

without any further devices.

Technical features

–DAC control with control panel.

The following functions are available:

–4 free seam contours with a total of 2800 available stitches can

be stored.

The coordinates are entered at the control panel.

No further devices are required.

–4 sewing sample sequence programs with up to 4 sewing

samples per sewing sample sequence program can be created

and memorized.

–The coordinates (teach-in) are entered with a precision of

0.5 or 1 mm respectively.

–Counter of capacity and daily number of pieces.

–The speed can be changed from 0 rpm (manual operation with

full operability of the x-y drive) up to 2500 rpm in

steps of 100 rpm.

–Fabric drive via two step motors.

–Drive of the sewing unit directly at the arm shaft via brushless

direct current motor.

–Maximum sewing field size 120 x 60 mm.

–Thread monitor and thread pulling device.

–Oil wick lubrication of arm shaft and driving shaft by means of two

oil reservoirs.

–Service and maintenance work is supported by comprehensive test

programs.

2. Use in accordance with the requirements

Class 910 is a sewing unit determined for processing light to

medium-weight material, i.e. fabrics made of textile fibres or leather.

Such sewing materials are used in the clothing industry and for the

production of home and car upholstery.

Furthermore, this sewing unit can also sew so-called technical seams.

However, in this case the user has to estimate the possible risks

(preferably in cooperation with DÜRKOPP ADLER AG) because on the

one hand such fields of application are comparatively rare and on the

other hand there is an immense variety of possibilities. According to

the result of this estimation suitable safety measures may have to be

taken.

Generally only dry fabrics must be processed on this sewing unit. The

material must not be thicker than 10 mm when compressed by the

lowered fabric clamp. It must not include any hard objects.

In general the seam is produced with sewing threads made of textile

fibres (cotton threads, synthetic threads or core threads) with the

following dimensions:

Class 910 threads of the dimension 15/3 - 120/3

If other threads are to be used, it is indispensable also in this case to

consider the possible risks and to take corresponding safety

measures, if necessary.

This sewing unit must only be installed and operated in dry and

well-kept rooms. In case it is operated in other rooms which are not dry

and well-kept further measures can become necessary which have to

be agreed upon (see EN 60204-31: 1999).

We as manufacturers of industrial sewing machines take it for granted

that at least semi-skilled operators are working with our products so

that we can assume that all usual operations and their risks are known

to them.

3. Subclass

Cl. 910 Single needle lockstitch sewing unit with thread trimmer and thread

pulling device.

Equipped with two sewing feet for general seam contours.

4. Optional equipment

The following optional equipment is available for the sewing unit 910:

Order number Optional equipment

0910 590044 Laser marking (pc.)

9822 510026 Sewing lamp

9822 510027 Table clamp

Needle cooling

Please contact our application centre (APC) for further optional equipment.

5. Stands

The following stand is available for the sewing unit 910:

MG55 400294 Stand package

Table top size 600 x 1060 mm

Stand height 1160 to 1305 mm

6. Technical data

Stitch type: 301

Hook type: oscillating

large capacity hook

Needle system: DPx17 (135x17)

Needle size: 90 - 140 [Nm]

Standard needle size: 120 [Nm]

Thread size: 20/3 - 120/3

Stitch length: dependent on seam

pattern up to 12.7 mm

Max. speed 2500 [min-1]

Max. clamping stroke:18 [mm]

Sewing field size

max. in X-direction: 120 [mm]

max. in Y-direction: 60 [mm]

Number of sewing sample

sequence programs (sequences) 4

Number of sewing samples per

sewing sample sequence program 4

Sewing drive: DC motor

Rated voltage: 1 ~ 230V/ 50/60 Hz

Rated load: 0.45 kw

Noise: Lc = dB (A)

Emission value per work place according to DIN 45635-48-A-1-KL-2

Sewing length: __ mm

Stitches: __

Speed: _____ min-1

Fabric: G1 DIN 23328 2 plies

Sewing cycle: 1.3 sec. On and 1.0 sec. Off

Altri manuali per 910

Indice

Altri manuali Duerkopp Adler Macchina da cucire

Duerkopp Adler

Duerkopp Adler 745-34 Manuale

Duerkopp Adler

Duerkopp Adler 550-16 Guida

Duerkopp Adler

Duerkopp Adler 1230i-6 Guida

Duerkopp Adler

Duerkopp Adler 609 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 550-12-12 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 743-121 Istruzioni operative

Duerkopp Adler

Duerkopp Adler 559 Manuale utente

Duerkopp Adler

Duerkopp Adler 961-11-1 Guida

Duerkopp Adler

Duerkopp Adler 269 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 2180-1 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 745-24 Guida

Duerkopp Adler

Duerkopp Adler 741-26 Guida

Duerkopp Adler

Duerkopp Adler 4280-6 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 669 Premium Manuale utente

Duerkopp Adler

Duerkopp Adler 69-373 Manuale utente

Duerkopp Adler

Duerkopp Adler 1230i-6 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 743-221 Manuale utente

Duerkopp Adler

Duerkopp Adler 742-3 Guida

Duerkopp Adler

Duerkopp Adler 1280-6 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 275 Manuale utente

Duerkopp Adler

Duerkopp Adler 204-370 Guida alla risoluzione dei problemi

Duerkopp Adler

Duerkopp Adler 579 Manuale utente

Duerkopp Adler

Duerkopp Adler 550-767 Manuale utente

Duerkopp Adler

Duerkopp Adler H867 Manuale utente

Manuali Macchina da cucire popolari di altre marche

Riccar

Riccar RL634DE Manuale utente

Singer

Singer 2517 Manuale utente

Pfaff

Pfaff 3307-1 SERIES Manuale utente

Janome

Janome Quilt Maker Pro 18 VERSA Manuale utente

Siruba

Siruba C007JP Manuale utente

Husqvarna Viking

Husqvarna Viking Designer SE Manuale utente

Singer

Singer 148-5 Manuale utente

IKEA

IKEA SY Manuale utente

Pfaff

Pfaff 571 Manuale utente

Singer

Singer 15-91 Manuale utente

Brother

Brother BB370 Manuale utente

Pegasus

Pegasus WT100 Series Manuale utente

Reliable

Reliable 7100DB Manuale utente

Pfaff

Pfaff 937 Manuale utente

Singer

Singer 6038 Manuale utente

Singer

Singer 413K Manuale utente

Pfaff

Pfaff 1471 E1 Manuale utente

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuale utente
