USER GUIDE
AMPLIFIED STEREO GAMING HEADSET
For PlayStation 4 |Mobile
Congratulations on your purchase of the Ear Force®P12 headset
from Turtle Beach. You’ll enjoy powerful gaming audio and chat
on the PlayStation 4. Turtle Beach brings over 35 years of expertise
to transforming your listening experience.
WELCOME TO TURTLE BEACH!
Table of Contents
Package Contents P4
About the Ear Force P12 Headset P5
Parts and Controls P6
Setup and Connections: PlayStation 4 P7
Setup and Connections: Mobile Sources P9
Specications P10
Troubleshooting Tips P11
Important Safety Information P12
Compliance / Conformity P13
Warranty P16
4
Go to Table of Contents
Package Contents
B CA
Ear Force P12 Headset Turtle Beach Sticker
For our Knowledgebase and Technical Support please visit
turtlebeach.com/support
EarForceP12In-lineAmplier
5
Go to Table of Contents
About the Ear Force P12 Headset
Amplied Stereo Sound
P12 delivers high-quality digital game and chat for an enhanced
audio experience.
High-Quality Chat
High-sensitivitymicrophoneonaexibleboomkeepsyouheardloud
and clear.
Simple Setup
One simple USB connection delivers all game and chat audio.
Mobile Gaming Versatility
Disconnect from the in-line amp to use the P12 on the go with your
mobile devices including PS Vita™.
Microphone Monitor
Hear your voice in the headset so you don’t have to shout.
Amazing Sound & Comfort
Full-range50mmspeakerssupportedbybreathable,around-the-ear
mesh ear cushions for hours of comfort and noise-isolation.
Adjustable Bass Boost
Dial up the thump with variable Bass Boost.
Convenient In-Line Controls
Mastervolume,BassBoostandmicmutecontrolsatyourngertips.
For All Your Audio Needs
Headsets aren’t just great for games. Use the P12 for enjoying streaming movies
andTVfromNetix™andHuluPlus™orBlu-RayDisc.Crankupyourtuneson
music services like Pandora™ and then chat with friends or make mobile calls!
6
Go to Table of Contents
Parts and Controls
Adjustable High
Sensitivity
Omni-Directional
Microphone
Removable
Over-Ear Noise
Isolating
Earpads
Articulating
Earcups
Containing
50mmDrivers
Adjustable
Headband for
a Perfect Fit
3.5mm Headset
Plug for
Multi-Platform
Compatibility
Mic Status LED
Mic On
Mic Muted
Mic Switch
Master
Volume Control
Bass
Boost Control
7
Go to Table of Contents
Connecting to your PlayStation 4
1. Connectthe3.5mmHeadsetPlugintotheP12In-LineAmplier
2.ConnecttheUSBPlugontheP12In-LineAmpliertoaUSBPortonthefrontofthePS4
Setup and Connections: PlayStation 4
A
B
8
Go to Table of Contents
Setup and Connections: PlayStation 4
3. Go to Settings >> Devices >> Audio Devices >>
Headsets and Headphones >> Volume Control
(Headphones)
4. Turn up the volume level to maximum
5. Go to Settings >> Devices >> Audio Devices >>
Headsets and Headphones >> Microphone Level
6. Follow the on-screen instructions to calibrate
your microphone
1. Go to Settings >> Sound and Screen >>
Audio Output Settings >> Output to Headphones
2. Select “All Audio”
Conguring your PlayStation 4
9
Go to Table of Contents
Setup and Connections: Mobile Sources
Connecting to your Mobile Devices
· Connect the Headset Plug from your Headset to the Headset Jack on your preferred mobile device
Note:Forreliablesound,conrmthatallconnectionsarermlyinserted.
Conguring your Mobile Device
· Your P12 should be automatically detected and will be used as the Primary Headphones/Microphone
forallCalls,Video,andMusic.
A
10
Go to Table of Contents
Specications
· Speakers 50mmDiameterDriverswithNeodymiumMagnets
· Frequency Response20Hz–20kHz
· Microphone Design Flexible Omni-Directional
· Headset Input 3.5mm 4-Pole
· P12 Amplier InterfaceUSB-A,3.5mm4-Pole
· Headset Weight 6.5oz(186g)
