EarthQuake EQ128 Manuale utente

Specification

Nominal Basket Diameter

Nominal Impedance

Max Power Rating

Resonance

Usable Frequency Range

Sensitivity

Magnet Weight

Voice Coil Diameter

12-1/4”, 310 mm

8-Ohms

400 Watts

51 Hz

35 Hz- 4.5 kHz

96.5 dB (2.83V/1M)

60 oz.

2-1/2”, 63 mm

Thiele & Small Parameters

Resonant Frequency (Fs)

DC resistance (Re)

Coil Inductance at Fs (Lces)

Mechanical Q (Qms)

Electromagnetic Q (Qes)

Total Q (Qts)

Compliance Equivalent Volume (Vas)

Mechanical Compliance of Suspension (Cms)

BL Product (BL)

Diaphragm Mass (Mmd)

Maximum Linear Excursion (Xmax)

Surface Area of Cone (Sd)

51 Hz

5.2 Ohms

8.95

0.42

0.41

0.23 mm/N

12.84 T-m

35.2 grams

0.0531 m

38.37 mH

0.20 ft ,

4.0mm

91.6 liters

Mounting Information

Recommended Enclosure Volume

Sealed

Vented

Overall Diameter

Cut Out Diameter

Front Sealing Gasket

Rear Sealing Gasket

Mounting Holes Diameter

Mounting Depth

1.0-2.1 ft , 28.3-59.5 liters

12-1/4”, 310 mm

11-3/16”, 284 mm

fitted as standard

1/4” x 3/8” , 6.5 mm x 9 mm

4-7/8”, 123 mm

Materials of Construction

Aluminum voice coil

Polyimide former

Ferrite magnet

Vented and extended core

Stamped steel basket

Paper cone

Cloth surround

Solid composition paper dust cap

Earthquake EQ128 Pro Audio Series

Sound That Will Move You.

Earthquake Sound Corporation

2727 McCone Avenue • Hayward, CA94545 • United States

US Toll Free 1-800-576-7944 • Tel: 510-732-1000 • fax: 510-732-1095

www.earthquakesound.com
