Edimax ES-1008PL Manuale utente

ES-1008PL / GS-1008PL

Quick Installation Guide

07-2014 / v1.0

this publication may be reproduced, transmitted, transcribed, stored in a

retrieval system, or translated into any language or computer language, in

any form or by any means, electronic, mechanical, magnetic, optical,

chemical, manual or otherwise, without the prior written permission from

Edimax Technology Co., Ltd.

Edimax Technology Co., Ltd. makes no representations or warranties,

either expressed or implied, with respect to the contents hereof and

specifically disclaims any warranties, merchantability, or fitness for any

particular purpose. Any software described in this manual is sold or

licensed as is. Should the programs prove defective following their

purchase, the buyer (and not this company, its distributor, or its dealer)

assumes the entire cost of all necessary servicing, repair, and any

incidental or consequential damages resulting from any defect in the

software. Edimax Technology Co., Ltd. reserves the right to revise this

publication and to make changes from time to time in the contents hereof

without the obligation to notify any person of such revision or changes.

The product you have purchased and the setup screen may appear

slightly different from those shown in this QIG. The specification is subject

to change without notice. Please visit our web site www.edimax.com for

the update. All brand and product names mentioned in this manual are

trademarks and/or registered trademarks of their respective holders.

Edimax Technology Co., Ltd.

Add: No. 3, Wu-Chuan 3rd Rd., Wu-Ku Industrial Park, New Taipei City,

Taiwan

Tel: +886-2-77396888

Email: sales@edimax.com.tw

PRODUCT INTRODUCTION

Model no.:

ES-1008PL: 8-Port Fast Ethernet PoE+ Switch

GS-1008PL: 8-Port Gigabit Ethernet PoE+ Switch

Package Contents

Before you start using this router, please check if there is anything missing

in the package, and contact your dealer to claim the missing item(s):

PoE switch x 1pcs

Quick installation guide x 1pcs

Power cord x 1pcs

Rubber feet x 4pcs

Rack-mount brackets and screws x 1 set

Safety Precautions

To avoid any device damage and bodily injury caused by improper use,

please observe the following rules.

*Keep the power off during the installation.

*Wear an ESD-preventive wrist strap, and make sure that the wrist strap

has a good skin contact and is well grounded.

*Use only the power cord provided with the Switch.

*Make sure that the supply voltage matches the specifications indicated

on the rear panel of the Switch.

*Ensure the vent hole is well ventilated and unblocked.

*Do not open or remove the cover of the Switch.

*Before cleaning the device, cut off the power supply. Do not clean it by

the waterish cloth, and never use any other liquid cleaning method.

Front Panel

Please refer to the following description for the front panel:

*ES-1008PL

*GS-1008PL

LED Definitions:

LED Name

Light

Status

Description

PWR

Switch on and correctly powered

Off

Switch not powered or not correctly powered

LINK/ACT

The port connected

Off

The port not connected

Flashing

The port is activating and transferring /receiving

data.

Gigabit

(GS-1008PL)

There is a 1000Mbps device connected to the

corresponding port.

Off

There is a 10/100Mbps device connected to the

corresponding port, or there is no device

connected to the corresponding port.

PoE

There is a PoE PD connected to the port, which

supply power successfully.

Off

No PD is connected to the corresponding port,

or no power is supplied according to the power

limits of the port.

Back Panel:

Power Connector:

Plug in the female connector of the provided power cord into this AC LINE

socket, and the male into a power outlet. Supported input voltages range

from 100-240V AC, and 50-60 Hz.

Product Specifications:

Note:

* PoE budget: Up to 30 Watts max per port, 75 Watts Total

* Please ensure you do not exceed the PoE power budget and overload the PoE switch.

For example:

7.7W

15.4W

30W

Max. PoE ports (up to)

8 ports

4 ports

2 ports

* Make sure the PDs that you connected to the Switch are compliant with IEEE802.3af/IEEE802.3at

standard.

Model

ES-1008PL

GS-1008PL

Standards

IEEE 802.3 10BaseT

IEEE 802.3u 100BaseTX

IEEE 802.3af/802.3at PoE

IEEE 802.3x Flow Control

IEEE 802.3az Energy Efficient

Ethernet

IEEE 802.3 10BaseT

IEEE 802.3u 100BaseTX

IEEE 802.3ab 1000BaseT

IEEE 802.3af/802.3at PoE

IEEE 802.3x Flow Control

IEEE 802.3az Energy Efficient

Ethernet

Interface

RJ-45

8 ports

PoE

8 ports

MAC Address

Buffer Memory

96KB

128KB

Jumbo Frames

N/A

Total Power budget

80W

150W

80W

150W

Power Consumption

5 Watts (Max. no PD connected)

Dimensions

280 x 179 x 44.5 (L x W x H)

Weight

1.5 kg

Operating

Temperature

0 to 40℃

Storage Temperature

-40 to 70℃

Humidity

Operating:10 to 90% RH (non-condensing)

1. PRODUCT INSTALLATION

There are two ways to install your switch, please select one that

suits you.

2. Desktop Installation

1. Install the switch on a level surface that can support the

weight of the unit and the relevant components, and attach

the rubber feet to the bottom. The rubber feet cushion the

switch and helps protect the case from scratches.

2. Plug the switch into an electrical source with the provided power

cord.

3. Rack-Mount Installation

Rack mounting allows for a more orderly installation

when a series of network devices is being installed.

1. Disconnect all the cables from the switch.

2. Place the unit the right way up on a hard, flat surface with the

front facing you.

3. Position a mounting bracket over the mounting holes on one

side of the unit.

4. Insert the screws and fully tighten with a suitable screwdriver.

5. Repeat the two previous steps for the other side of the unit.

6. Insert the unit into the rack and secure with suitable screws

7. Reconnect all the cables.

Regarding the installation environment, we strongly recommend:

1. The switch should be placed in an appropriately ventilation

environment. A minimum 25 mm space around the unit is

recommended.

2. The switch and the relevant components should be kept away from

sources of electrical noise such as radios, transmitters and

broadband amplifiers.

3. Avoid environments with higher than recommended moisture levels.

Troubleshooting

1. Power LED is not lit

Check if the power cord is properly connected to the plug and the

power outlet; make sure the power cord is firmly plugged into the

power socket of the switch.

2. LINK/ACT LED is not lit when connected to devices

Make sure the network device attached to the switch is turned on.

Make sure the network cable is properly connected to the switch

and the network device.

Make sure the network cable is a UTP cable that complies with

EIA/TIA 568 and Category 5 specifications.

[!] Contact your dealer if problem persist.

Appendix: The standard RJ-45 Introduction

RJ45 Pin:

Below is an indication of a standard RJ-45 socket and plug, and definition

for the pins.

RJ-45 Connector pin signal:

RJ-45 Connector pin signal

Pin no.

MDI-II signal

MDI-X signal

TX+

RX+

TX-

RX-

RX+

TX+

POE -

RX-

TX-

POE +

The following shows straight cable and crossover cable connection,

ordinary please use straight cable to connect switch/Hub or other devices:

Straight cable for the switch (uplink MDI-II port) to switch/Hub or other

devices connection

Cross over cable for switch (MDI-X port) to switch/hub or other network

devices (MDI-X port) connection.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This device and its antenna must not be co-located or operating in conjunction with

any other antenna or transmitter.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the authority to operate equipment.
