Owner’s Detailed Manual
Thank you for purchasing ELECKEY E6.
Please refer to this guide for all operation.
Please contact us freely if you need any help.
Email: eleckey@ieleckey.com
2/18
Table of Contents
Layout......................................................................................................................................3
Quick guide..........................................................................................................................4‐5
Menu operation.................................................................................................................6‐10
Audio Recording System.......................................................................................................10
Supplement lamp..................................................................................................................10
Automatic Recording............................................................................................................ 10
Emergency Record Lock........................................................................................................11
Auto LCD OFF........................................................................................................................ 11
In case of emergency............................................................................................................11
Playback on dash cam......................................................................................................11‐15
Take a photo with dash cam............................................................................................11‐15
Lock or Delete the video file manually................................................................................. 16
Parking Mode........................................................................................................................17
Reset..................................................................................................................................... 18
Installation............................................................................................................................ 18
Warranty...............................................................................................................................18
Contact us............................................................................................................................. 18
3/18
Layout
4/18
Quick Guide
1. Install microSD card into the card slot with correct direction.
Reminder:
No memory card, Samsung Evo 32GB card is recommended. If you
are using a 64GB card, please format it to FAT32 before use.
2. Slide the camera to the fixed plate and adjust proper vertical
and horizontal positions.
3. Remove protection tape from the fixed plate and install plate on
the windshield glass. (Rotate the position which showed on the
below picture to make it locked)
5/18
4. Connect the power cord to charging port of the camera.
5. Connect the car charger to the cigarette lighter socket in your
car. And then start your vehicle.
Wish you enjoy with E6 recording system. Signals of “Automatic
Recording Mode” show as below picture.
6/18
Menu Operation
E6 is turning into the “Automatic Recording Mode” when the power is
connected.
Under the “Automatic recording mode”, red led signal will flash on
the LCD.
Press to stop recording. ( red led signal will disappear)
And then press to active the Menu selection.
7/18
RESOULTION
2304*1296/30F
1920*1080/30F
1920*1080/30F(HDR)
1280*720/60F
1280*720/30F
2560*1080/30F
Default setting: 2304*1296/30F
VIDEO QUALITY
QUALITY:S.Fine / QUALITY: Fine / QUALITY:Normal
Default setting: QUALITY:S.Fine
RECORD OVERWRITE
1MIN /3MIN/5MIN/OFF
Default setting: 1MIN
MOTION DETECTION
OFF /ON
Default setting: OFF
POWER ON RECORD
ON/OFF
Default setting: ON
POWER OFF DELAY
30SEC /OFF/10SEC/20SEC
Default setting: 30SEC
POWER ON DELAY
OFF/10SEC/20SEC/30SEC
Default setting: OFF
MIC
ON/OFF
Default setting: ON
TIME LAPSE
OFF/1SEC/5SEC/30SEC
Default setting: OFF
LANGUAGE
Default setting: ENGLISH
8/18
CAR NUMBER SET
TV TYPE
NTSC/PAL
Default setting: NTSC
AUTO POWER OFF
3MIN/5MIN/OFF
Default setting: 3MIN
AUTO LCD OFF
3MIN/OFF/30SEC/60SEC
Default setting: 3MIN
TIME SETUP
Please active the Menu selection and then press to find the
“TIME SETUP”
Then press to active “TIME SETUP” operation.
Please set the Year, Month, Date and Time one by one. You can change
the setting by “up” and “down” button; And you can confirm it by
button.
9/18
STAMP
Default setting: DATE/TIME STAMP
BEEP SOUND
VOLUME:100%
OFF
VOLUME:20%
VOLUME:40%
VOLUME:60%
VOLUME:80%
Default setting: VOLUME:100%
FLICKER
50Hz /AUTO/60Hz
Default setting: 50Hz
CONTRAST
STANDARD /HARD/SOFT
Default setting: STANDARD
SHARPNESS
STANDARD /HARD/SOFT
Default setting: STANDARD
WHITE BALANCE
AUTO/SUNNY/CLOUDY/FLUORESCENT/INCANDESCENT
Default setting: AUTO
EV SETTING
0/0.3/0.7/1/1.3/1.7/2/-2/-1.7/-1.3/-1/-0.7/-0.3
Default setting: 0
G-SENSOR SET
OFF/1/2/3/4/5/6/7
Default setting: OFF
Recommended setting: 5 (Please set it to 5 before using)
WDR
ON/OFF
Default setting: ON
LDWS DETECT
10 /18
OFF/ON
Default setting: OFF
LDWS CALIBRATION
NO/YES
Default setting: NO
DEFAULT SETTING
NO/YES
Default setting: NO
FORMAT
NO/YES
Default setting: NO
FIRMWARE VERSION
Default setting: ELB03FMHZDNE.170221.V1.1
After finishing the setting, press to go back to “Recording
pause mode”.
And then press to start “Automatic Recording Mode”.
Audio Recording System
Under the “Automatic recording mode”, if press “down” button,
the audio recording system will pause. And you press “down” button
again, it will start.
Supplement lamp
Under the “Automatic recording mode”, if press “up” button, the
supplement lamp will turn on. And you press “up” button again, it will
turn off.
Automatic Recording
The E6 is automatically configured to start recording anytime the
power is received through the cigarette lighter plug. The camera will
shut off a few seconds after power is turned off. It is set to
automatically loop the SD card as well. The previous file will be
automatically overwritten with the newest once the SD card is full.
