Endon 56410 Manuale utente

Mode Photocell IP54 Outdoor Wall Light

Safety Warnings

INSTRUCTION MANUAL

• Thisproductissuitableforconnectionto240V~50Hzsupply,outdoorandbathroomuse.

• Beforeinstallingyourlightttingalwaysswitchoffthemainssupplyandremovetheappropriatefuseor

switchofftheappropriatecircuitbreakerbeforecommencinginstallation.

• ItisrecommendedthatthislightbeinstalledbyaqualiedelectricianinaccordancewithcurrentIEEWiring

RegulationsandBuildingRegulations(PartP).

• ThisisaClassItting,andmustbeconnectedtoEarth.Theterminalblocksaresuppliedaccordingto

requirementsofthetting.

• Nevertbulbsofahigherwattagethanthosespeciedonthelabel(asthesemaycauseoverheatingand

damagethetting).

• Thisproductcontainsdelicateparts.Takecareduringinstallationandmaintenancetoavoidbreakages

• Ifyouareinanydoubtaboutyourcompetencepleaseconsultaqualiedelectrician.

• Ifanymodicationismadeitwillinvalidatethewarrantyandmayrendertheproductunsafe.

• If the glass or diffuser isbroken or cracked it must be replaced, please consult your retailer.Thisis the

symbolwhichdenotesthisrequirement:

Outdoor Use:

• Runsupplywirefroma5-ampelectricalsupplyusingdoubleinsulated3-corecableoftypeH05RN-F1.0mm2

(notsupplied)toselectedsite,ensuringitisadequatelyprotectedthroughthefulllengthofthecablerun,it

mustcomeoutoftheatsurfaceofthewallorstepsinlinewiththeentrytothetting.

• Exceptwhereinstalledinaconduitorductwhichprovidesequivalentprotectionagainstmechanicaldamage,

acableburiedinthegroundshallincorporateanearthedarmourormetalsheathorboth,suitableforuseas

aprotectiveconductor,orbeofinsulatedconcentricconstruction.Buriedcablesshallbemarkedbycable

covers or a suitable marking tape. Buried conduits and ducts shall be suitably identied. Buried cables,

conduitsandductsshallbeatasufcientdepthtoavoidbeingdamagedbyanyreasonablyforeseeable

disturbanceoftheground.

Bathroom Use:

• Thislightmayalsobeinstalledin“Zones1and2andOutsideZones”ofabathroomwherewaterjetsare

notusedforcleaningpurposes.ThesezonesarereferencedinBS7671:2008“RequirementsforElectrical

Installations”,IEEWiringRegulations17thEdition.Alldimensionsmustbecheckedinconjunctionwiththe

Regulations-Pleaseseediagrambelow.

EndonLighting,LS90SE 56410-ModePhotocell-WB20150930

• ThesupplycircuitmustbeprotectedbyanRCD.Ifinstalled

in a bathroom an RCD must be used/ OR the casing

of the light must be connected to the “Supplementary

EquipotentialBonding”pointsinthebathroom.

• An electrician must be consulted if in any doubt about

yourowncompetencyormeaningofbathroom“Zones”or

“EquipotentialBonding”.

Care Information

Allow10minutestocoolbeforereplacing,adjustingorcleaning.Cleanwithadryclothonly.Donotuseliquid

orabrasivecleanersonthisproduct.

OUTSIDE ZONES

ZONE

0.6m

2.25m

Ceiling

56410-ModePhotocell-WB20150930

EndonLighting,LS90SE

1. Decideonthepositionofthelighttting/orremoveexistinglighttting.Takeanoteofthepositionofthe

electricalconnections.Ensurethereisasolidmountingsurface,preferablyawoodenjoistorjoistbridgeto

supporttheweightofthelighttting.

2. Usethebackplateasatemplatetomarkthescrewholes,andsecuretothewallwithappropriatescrew

xings,makingsurethebracketishorizontal.Ensurethattheholeintherubbergrommetsealscorrectly

roundthecabletoguaranteeagoodseal.

3. Supportyourttingandconnectthehousewiringtotheterminalblock-seewiringdiagrambelow.When

youaresureoftheconnectionswraptheTerminalBlockandoverlapthewiringbothsideswith2layersof

insulationtape.NOTE: This is a Class I tting and must be earthed.Anylooseterminalblocksshould

alwaysbecoveredwith2layersofgoodqualityinsulationtape.Re-tthebackboxensuringnowiresare

damaged,trappedorleftexposed.Checktheseal,usesealantifrequired

4. Fitthebulb.NOTE: Never t bulbs of a higher wattage than those specied on the label (as these may

cause overheating and damage the tting).

5. Pushthediffuserintoposition,guidingthespringlugsintotheirslots.Ensurethediffuserisseatedcorrectly

togivetherequiredsealagainstwateringress.

6. LockthediffuserbyttingtheAllenkeyboltsasintheinsetdiagram.

7. Turnonthepowerandtestbycoveringthephotocell.Pleaseseethetablebelowforthephotocell’ssettings.

Before you start

Pleasereadtheseinstructionscarefullybeforettingandretainforreference.Checkthepackagingandmake

surethatyouhavealltherequiredparts.Followeachassemblystepinordertopreventincorrectassembly.

Ensurethattheproductisfullyassembledasillustratedbeforeuse.

The Light pack contains:

Lighttting.

Terminalconnectionblock(s).

Fixingpack.

The following tools may be required:

Selectionofcrossandatheadscrewdrivers.

Electricdrillandassorteddrillbits.

Wirestrippers.

Electricalinsulationtape.

Assembly/ User Instructions

These assembly diagrams are intended as a guide – if in doubt consult a qualied electrician.

Ambient Light Amounts Light State

Lessthan60Lux Thelightwillturnonautomatically.

60Luxto120Lux Thelightwillstayon.

Morethan120Lux Thelightwillturnoffautomatically.
