Endress+Hauser Teqwave T Manuale utente

Basic safety instructions

• Read and understand the instructions in the Operating Instructions pertaining to

thedevice.

• Followinstructionsandcomplywithgeneralpolicies.

• Authorizedqualiedspecialists:trainedandfamiliarwithnationalregulations.

• Non-designatedusecompromisessafety.

• Themanufacturerdoesnotacceptanyliabilityfordamagesresultingfromimproperor

non-designateduse.

• Operatethedeviceonlyifitisinpropertechnicalcondition,freefromerrorsandfaults.

• Ensuretheresistanceofalluid-wettedmaterialsintheprocess.

• Staywithinthespeciedtemperaturerange.

• Hot uids can present a burn hazard. Ensure appropriate touch protection at the

handheldsensor.

• Riskofinjuryfromhotsensorwhenchangingtheuid.Considertheashpointofthe

liquidtobemeasured.

• Riskofinjuryfromresidueofpreviousliquidswhenchangingtheuid.Removeall

residueofpreviousliquids.

• Onlyreleasethepush-pullconnectionbypullingtheconnectoroutofthesocket.

• Potentialspreadofmalicioussoware:alwaysuseanti-virussowarewhenconnecting

toacomputer.

Operation

Operating options

• Congurationviathe„TeqwaveMobileViewer“operatingtool

• Operationviaportabletransmitter

Operating keys

IOn/O Back/Repeat

Conrm RFID EnableRFID(notavailable)

Teqwave T Quick Guide

SD02145D/06/EN/01.17

71386262

Technical data

USB port

Connection USBsocket,TypeB

Supply voltage DC5V

Battery

Battery type Lithiumionbattery

Capacity 2300mAh

Charging time Approx.2.5h

Battery life Approx.8h,atleast40measuredvaluerecordings

Degree of protection

Sensor IP68(withsensorconnected)

Sensor IP65

Performing the measurement

RFID

Inserttheconnectorsoftheconnecting

cable into the sockets at the position

indicateduntiltheyengagewithaclick.

2. IPresstheOn/Obuttontoswitchonthe

measuringdevice.

3. Select the measuring point by tapping

thetouchscreen.

Themeasuringdevicedisplaysthemea-

suringconditions.

4. Immersethesensingareaofthesensor

completelyintotheliquidtobemeasured.

Themeasuringdevicechecksthemeasu-

ringconditions.



Themeasuringdevicedisplaysthemea-

surementresult.

5. Press the Conrm button to save the

measuredvalue.

Themeasuringdevicedisplaysthesaved

measuredvaluealongwiththelastfour

measuredvalues.

 If a dosage recommendation is

congured, the measuring device

displays a dosage recommendation.

For detailed information, see the

OperatingInstructionsforthedevice.

6. PresstheBack/Repeatbuttontoreturn

tothestartscreen.
