EPH Controls CRTP2 Istruzioni operative

Installation and Operation Guide

Room Thermostat

CRTP2

Factory Default Settings

Specications

LCD Display

Buttons

Wiring

Mounting & Installation

Replacing the Batteries

Backlight

Mode Selection

Adjusting the Target Temperature

Locking the Keypad

Table of contents

Installation Instructions

Operating Instructions

Setting the Date, Time and Programming Mode

Holiday Mode

How your Programmable Thermostat works

Factory Program Setting

Programming Modes

Optimum Start Control (OS)

Menu Function P0 1 Operating Mode

Normal Mode (Nor)

Time Proportional Integral Mode (TPI)

P0 2 Setting High & Low Limits

P0 3 Hysteresis HOn & HOFF

Temporary Override / Permanent Override

P0 4 Calibrate

Boost Function

Resetting the Thermostat

Adjust the Program Setting in 5/2 Day Mode

Installation Instructions

Battery operated programmable Room Thermostat

EPH Controls Ltd.

Factory Default Settings

High and Low Temp. limitation: O

Keypad lock: O

Operating mode: Normal

Temperature indicator: ˚C

Frost protection: On (5˚C)

HYS On: 0.4˚C

HYS OFF: 0.0˚C

Daylight Saving Time (DST): On

Note:

Frost protection is built into this thermostat.

It will only be activated when the thermostat is in OFF position and the temperature

reaches 5˚C.

4CRTP2

Specications

Contacts: Volt Free

Power supply / Input: 2 x AA Alkaline batteries

Power consumption: Operating 30mW

Standby <0.5mW

Temperature range: 5…35˚C

Ambient temperature: 0…45˚C

Ambient admissible humidity: 5-95%RH

Contact rating: 8(3)A

Dimensions: 91 x 91 x 26mm

Internal Temperature sensor: NTC 100K

Backlight: White

IP rating: IP20

Pollution degree: 2

Hysteresis (Switching dierential): Adjustable from 0 to 1°C

0.1°C increments

Automatic action: 1C

EPH Controls Ltd.

LCD Display

[1]

[8]

[9][11] [9]

[3]

[4]

[2]

[5]

[6]

[7]

[13]

[12]

[10]

MonSet room temp Tue Wed Thu Fri sat sun

holiday to from

auto

off

man hi lo limit

[1] Displays when setting target temperature.

[2] Displays current room temperature.

[3] Displays current day of the week.

[4] Displays when batteries need to be replaced.

[5] Displays current / target temperature.

[6] Displays when the thermostat is calling for heat.

[7] Displays when keypad is locked.

[8] Displays when setting HIGH and LOW temperature limit.

[9] Displays current time and date.

[10] Displays current operating mode.

[11] Displays when setting

holiday mode.

[12] Displays when

thermostat is in

boost mode.

[13] Displays current

time program.

6CRTP2

Buttons

OK Button

Time

Button

+1h

Button

Down

Button

Menu button

Reset button

EPH Controls Ltd.

Wiring

OFF

321

COM

Terminal Connections

Terminal 1 OFF - N/C Normally closed connection

Terminal 2 ON - N/O Normally open connection

Terminal 3 COM - Common connection

8CRTP2

Mounting & Installation

Caution!

Installation and connection should only be carried out by a qualied person.

Only qualied electricians or authorised service sta are permitted to open the

thermostat.

If the thermostat is used in a way not specied by the manufacturer, its safety

may be impaired.

Prior to setting the thermostat, it is necessary to complete all required settings

described in this section.

Before commencing installation, the thermostat must be rst disconnected

from the mains.

This thermostat can be mounted in the following ways:

1) Directly mounted on wall

2) To a recessed conduit box

3) To a surface mounting box
