Epson TM-C3500 Series Manuale utente

USER MANUAL

Roll to roll system

for EPSON TM-C3500

this product is certified:

The Unwinder and the Rewinder can handle media up to 127mm (5”) on rolls having 76mm

(3”) inside diameter and up to 250mm (9.84”) outside diameter. All devices are equipped with

an external auto switching 100/240VAC - 2,5A at 24V power supply and an electronic circuit

controls all functions.

INSTALLATION

STEP 1

Attach the printer plate (EPS35-JPL) to the

unwinder (U).

Do not fasten the knobs for the moment.

Place the printer on the plate using the guide.

ATTENTION:

If you don’t have the printer plate EPS35-JPL,

connect the second base and put the printer

over.

STEP 2

Load the media roll and outside disk then tight

the knob.

Push the media under the tension arm and

then feed it into the printer (look at the printer’s

manual how to load media).

STEP 3

Make sure to align the unwinder with the

printer and turn it on. Use the knob to set the

unit at its maximum speed.

EPS35-JPL

STEP 5

Load a cardboard core onto the core holder.

Load the outside disk making sure it adheres

to the cardboard.

STEP 6

Push the media under the tension arm and

stick it on the cardboard core. Make sure to

align the rewinder with the printer.

STEP 7

Turn the unit on, use the knob to set it at its

maximum speed.

The system are ready to works.

STEP 4

Attach the rewinder to the printer plate.

smart solutions for the labeling industry

Label rewinder, label unwinder, electronic label dispenser and more...

- FOR MORE INFO CONTACT YOUR RESELLER -
