Erbauer ESP18-Li Manuale utente
MNL_ESP18-Li_V03_BX220IM_200825
ESP18-Li
EAN. 3663602440116
ORIGINAL INSTRUCTIONS
2
Safety instructions
Product description
Assembly
Use
Care & maintenance
Guarantee
Declaration of Conformity
3
WARNING! Please read all safety warnings carefully and be sure
that they are fully understood before handling the tool.
x1
4
PRODUCT DESCRIPTION
7
8
9
5
11
12
13
10
4
32
6
1
A1
1
2
A2
5
B C
D E
F G
H
6
SAFETY INSTRUCTIONS
GENERAL PRODUCT SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this
product. Failure to follow all instructions listed below
may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
This product can be used by children aged from 8 years and
above and persons with reduced physical,sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the product in a
safe way and understand the hazards involved. Children shall not
play with the product. Cleaning and user maintenance shall not be
made by children without supervision.
Never expose the product to dripping or splashing ,no objects lled
with liquids, such as vases, shall be placed on it.
No ame sources, such as lighted candles, should be placed on it.
Never disassemble or modify this product in any way. Refer all
servicing to qualied service personnel.
7
BATTERY PRODUCT USE AND CARE
a. Recharge only with the charger specied by the manufacturer.
A charger that is suitable for one type of battery pack may create a
risk of re when used with another battery pack.
b. Use product only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
c. When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
e. Do
not use battery pack or tool that is damaged or
modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk of
injury.
f. Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130 °C
may cause explosion.
g. Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specied in the instructions. Charging improperly or at
temperatures outside the specied range may damage the
battery and increase the risk of re.
8
ADDITIONAL SAFETY WARNINGS FOR BATTERY
a. Do not connect the positive terminal and negative terminal of
the battery to each other with any metal object (such as wire).
b. Do not carry or store battery together with necklaces, hairpins
or other metal objects.
c. Do not pierce the battery with nails, strike the battery with a
hammer, step on the battery or otherwise subject it to strong
impacts or shocks.
d. Do not solder directly onto the battery.
e. Do not expose battery to water or salt water, or allow the
battery to get wet.
f. Do not disassemble or modify the battery.
g. Do not place the battery in or near re, on stoves or other
high temperature locations. Do not place the battery in direct
sunlight, or use or store the battery inside cars in hot weather.
h. Do not place the battery in microwave ovens, high-pressure
containers or on induction cookware.
i. If you intend to store a battery for a period without use then
store battery at room temperature (19°C to 25°C), charged
to about 30 – 50% of capacity. When storing for very long
periods boost charge the battery once per year to prevent over
discharge.
j. Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorized
service providers.
9
PRODUCT DESCRIPTION
1. Volume + button
2. Volume - button
3. ON/OFF button
4. Play/Pause Button
5. Bluetooth Pairing Button/Indicator Light
6. Built-in microphone
7. Aux Input Port
8. USB Output Port
9. Dustproof Cover
10. Power bar button
11. Battery pack (not included)
12. Battery pack release button
13. Aux Cable
01 TECHNICAL SPECIFICATIONS
Rated voltage: 18 Vdc
USB output voltage: 5 Vdc
USB output current: 2.1 A
RF frequency range: 2402-2480MHz
Max RF power output: 3.09dBm
Protection degree: IPX0
Net weight : 0.7 kg (without battery pack)
Ambient temperature range for speaker and battery use: -10°C to 40°C
For use with battery pack and charger as below:
Battery pack model: EBAT18-Li-2 / EBAT18-Li-4 / EBAT18-Li-5 / EHPB18-Li-4
EHPB18-Li-8
Charger model: EC18-Li / EFC18-Li / EMC18-Li
RATING LABEL EXPLANATION
ESP18-Li = MODEL NUMBER E = ERBAUER
SP = SPEAKER
18 = 18 V d.c.
Li = LITHIUM ION
10
ASSEMBLY
01 SYMBOLS
Caution / Warning.
Read the instruction manual.
Switch the product off and remove the battery pack to disconnect
from the power supply before assembly, cleaning, adjustments,
maintenance, storage and transportation.
Do not expose to rain or wet conditions.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re. They will explode and
cause injury.
Do not expose battery packs to heat in excess of 40°C
Keep Cool Battery Technology
USB output port
