EtherWAN EL100 Manuale utente

User’s Guide

EL100 / EL200 Series

10/100BASE-TX to 100BASE-FX Media Converter

10/100BASE-TX to 100BASE-BX WDM Media Converter

Dissemination or reproduction of this document, or its contents, is not authorized except where expressly

registration.

Disclaimer of Liability

The information contained in this document is subject to change without notice. EtherWAN is not liable for any

errors or omissions contained herein or for resulting damage in connection with the information provided in this

manual.

Warranty

For details on the EtherWAN warranty replacement policy, please visit our web site at:

www.etherwan.com

Products Supported by this Manual:

EL100, EL200

iii

EL100/200 Media Converter

Preface

Audience

This guide is designed for the person who installs, configures, deploys, and maintains the Ethernet

network. This document assumes the reader has moderate hardware, computer, and Internet skills.

Document Revision Level

This section provides a history of the revision changes to this document.

Revision

Document Version

Date

Description

Version 1

02/04/2021

First version in this format

Safety and Warnings

This guide uses the following symbols to draw your attention to certain information.

Symbol

Meaning

Description

Note

Notes emphasize or supplement important points of the main text.

Tip

Tips provide helpful information, guidelines, or suggestions for

performing tasks more effectively.

Warning

Warnings indicate that failure to take a specified action could result in

damage to the device, or could result in serious bodily injury.

Electric Shock

Hazard

This symbol warns users of electric shock hazard. Failure to take

appropriate precautions such as not opening or touching hazardous

areas of the equipment could result in injury or death.



iv
EL100/200 Media Converter
Contents
Preface..................................................................................................................... iii
Safety and Warnings.................................................................................................iii
Contents.................................................................................................................. iv
Introduction.............................................................................................................. 5
Unpacking.................................................................................................................6
Select Installation Location........................................................................................6
Connect Power..........................................................................................................8
Ports and Port Settings..............................................................................................8
LED Indicators...........................................................................................................9
DIP Switches...........................................................................................................10
Link Fault Pass Through (LFPT)........................................................................10
CLASS 1 LASER PRODUCT.............................................................................10
Specifications..........................................................................................................11
Manufacturer’s Information......................................................................................12

Introduction

EL100 / EL200 Media Converter

10/100BASE-TX to 100BASE-FX Media Converter

10/100BASE-TX to 100BASE-BX WDM Media Converter

The EL100 / EL200 Series provide media conversion between 10/100BASE-T(X) and 100BASE-FX

Fiber. Easy plug-and-play design facilitates network infrastructure construction. Through DIP switch

selection, Link-Fault-Pass-Through (LFPT) function can be activated or disabled.

The EL100 series is designed for SC or ST fiber connection applications, while the EL200 series is

designed for WDM fiber connection. These commercial grade media converters support the EtherWAN

EMC1600 chassis system for easy group installation.

EL100/200 Media Converter

Unpacking

Open the carton and unpack the items. Your package should include an EL100 or EL200 media

converter, and this Quick Install Guide. If items are missing or damaged, notify your EtherWAN

representative.

Select Installation Location

Place the equipment where it will not be subjected to extreme temperatures, humidity, or

electromagnetic interference. Specifically, the site you select should meet the following requirements:

The ambient temperature should be between 32 and 113 degrees Fahrenheit (0 to 45 degrees

Celsius).

The relative humidity should be less than 95 percent, non-condensing.

Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards for

IEC 801-3, Level 2 (3V/M) field strength.

Make sure that the equipment receives adequate ventilation. Do not block the ventilation holes

on each side of the equipment.

The power outlet should be within 1.8 meters of the product.

EL100/200 Media Converter

Chassis Installation

The converter can be installed into any of the expansion slots in a compatible chassis.

Install the converter onto a carrier supplied with the chassis.

Unscrew the carrier from the desired expansion slot on the chassis.

Fit the converter onto the carrier, and insert the carrier to the guide rails of the expansion slot.

Tighten the retaining screws to fix the carrier in the chassis.

NOTE: Never insert any converter into the chassis directly without using the supplied carriers.

The carriers allow secure and consistent placement of the converters into the chassis’ backplane

without causing any damage.

EL100/200 Media Converter

Connect Power

This Converter is a plug-and-play device. Connect the supplied AC to DC power adaptor to the

receptacle on the rear panel of the converter, and then attach the plug into a standard AC outlet.

If installing into a chassis, then no additional power connection is required.

Ports and Port Settings

The EL100 provides one TX port and one FX/BX port. For the FX/BX port, it provides options of:

Multi-mode fiber using SC, ST, VF-45, MT-RJ or LC connector or Single-mode fiber using SC or ST

connector.

The TX port uses RJ-45 connector and auto senses the speed of 10/100Mbps.

The EL200 provides a WDM-A/B fiber port.

Port settings are made by means of a DIP (Dual Inline Package) switch at the rear panel of the

module.

EL100/200 Media Converter

LED Indicators

LED

State

Indication

PWR

Steady

Power on

Off

Power off

100

(Mbps)

Steady

Connection at 100Mbps

Off

Connection at 10Mbps

LNK/ACT

Steady

Valid network connection established

Flashing

Transmitting or receiving data

Off

Neither valid network connection established nor transmitting/receiving

data

FDX/COL

Steady

Connection in full-duplex mode

Flashing

Collision occurred

Off

Connection in half-duplex mode

EL100/200 Media Converter

DIP Switches

There are six pins on the DIP switch for port settings. Refer to the table below for more details.

DIP

Switch

No.

Down

Enable LFPT (link-fault-pass-through)

Disable LFPT (link-fault-pass-through)

Enable auto negotiation for TX port

Enable forced mode for TX port

TX port forced to 100Mbps

TX port forced to 10Mbps

TX port forced to full duplex mode

TX port forced to half duplex mode

FX port forced to full duplex mode

FX port forced to half duplex mode

Store-and-forward mode

Converter mode

The default settings for all six dip switches are “Down”.

Disconnect the converter from the power source before changing any of the DIP switch settings.

NOTE: In order for converter mode to work, both TX and FX must be set to the same speed.

Otherwise, the device will automatically switch to store-and-forward mode.

Link Fault Pass Through (LFPT)

LFPT (Link Fault Pass Through) is a feature that will pass a link fault through the device at each

segment. If either of the copper TX links fail, the media converter will pass the fail state on throughout

the link, taking down the middle fiber as well as the copper link on the opposite end. This prevents the

connected switches from sending packets that would end up lost. LFTP is designed for use with media

converters arranged in pairs, and both devices must support LFPT.

CLASS 1 LASER PRODUCT

Each laser product complies with US FDA regulations of 21 CFR 1040.10 and 1040.11 or complies

with those regulations except for deviations pursuant to Laser Notice No. 56 dated May 8, 2019.
