EVGA Z97 Manuale utente
- 1 -
User Guide
EVGA Z97 Stinger
Specs & Initial Installation
(Part 1)
- 2 -
Table of Contents
Before you Begin………………………………………………………………………………..3
Parts Not in the kit……………………………………………………………………………...4
Intentions of the kit……………………………………………………………………………..4
Motherboard Spe ifi ations ...................................................................................................................... 5-6
Unpa king and Parts Des riptions ............................................................................................................... 7
Equipment ....................................................................................................................................................... 7
Hardware Legend ............................................................................................................................................ 8
PCI-E Slot Breakdown..…………………………………………………………..…....................9
Rear I/O Panel legend ...…………………………………………..................................................10
Preparing the Motherboard .........................................................................................................................11
Installing the CPU ................................................................................................................................... 11-12
Installing the Cooling Devi e ......................................................................................................................12
Installing System Memory (DIMMs) .........................................................................................................13
Complian e Information ..............................................................................................................................14
- 3 -
Before You Begin…
Wel ome to a new lass of high performan e motherboards that boast 4
th
and 5th
Generation Intel® Core™ Pro essor ompatibility. The Z97 platform takes you to a
new level of performan e and effi ien y. We have refined the GUI BIOS interfa e,
reimagined power VRM that fo uses on effi ien y, added MPCIE support and loaded
with features like Creative Sound Core3D quad- ore audio pro essor, Intel Gigabit LAN,
native SATA 6G/USB 3.0 and more. All sitting on a 10 layer PCB to improve
performan e and effi ien y.
Did we also mention that this motherboard is designed for the over lo ker? Built from
the ground up to give you all the essentials that you need for over lo king, with a GUI
BIOS that is fo used on fun tionality, ultra high quality omponents and robust PCI-E
3.0 and memory tra e layout.
With these features and more, it is lear that the EVGA Z97 motherboards are
engineered to ex eed the best.
- 4 -
Parts NOT in the Kit
This kit ontains all the hardware ne essary to install and onne t your new
EVGA Z97 Stinger Motherboard. However, it does NOT ontain the following
items that must be pur hased separately in order to make the system fully
fun tional and install an Operating System:
Intel Socket 1150 Processor
DDR3 System Memory
CPU Cooling Device
PCI Express Gr phics C rd
Power Supply
H rd Drive or SSD
Keybo rd / Mouse
Monitor
(Option l) Optic l Drive
EVGA assumes you have pur hased all the ne essary parts needed to allow for
proper system fun tionality. For a full list of supported CPUs on this
motherboard, please visit www.evga. om/support/motherboard
Intentions of the Kit
This kit provides you with the motherboard and all onne ting ables ne essary
to install the motherboard into a PC ase.
When repla ing a motherboard in a PC ase, you will need to reinstall an
operating system even though the urrent storage drive may already have one
installed.
- 5 -
EVGA Z97
Motherboard
Motherboard Specifications
Size:
mITX form fa tor of 6.7 in hes x 6.7 in hes
Microprocessor support:
Intel So ket 1150 Pro essor
Oper ting Systems:
Supports Windows 8 / 7
Cont ins Intel Z97 chipset
System Memory support:
Supports Dual hannel DDR3 up to 2666MHz+.
Offi ially supports up to 16GB of DDR3 memory.
USB 2.0 Ports:
6x from Intel Z97 PCH – 4x external
Supports hot plug
Supports wake-up from S1 and S3 mode
Supports USB 2.0 proto ol up to a 480 Mbps transmission rate
USB 3.0 Ports:
6x from Intel Z97 PCH – 4x external, 2x internal
Supports transfer speeds up to 5Gbps
Ba kwards ompatible USB 2.0 and USB 1.1 support
SATA Ports:
Intel Z97 PCH Controller
4x SATA 3 Ports up to 6G (600 MB/s) data transfer rate
- Support for RAID 0, RAID 1, RAID 0+1, RAID 5, AND RAID 10
1x eSATA port on rear I/O panel
- 6 -
Onbo rd LAN:
1x Intel i217 Gigabit Ethernet PHY
Supports 10/100/1000 Mb/se Ethernet
Onbo rd Audio:
Creative Core3D Quad-Core Audio Pro essor (CA0132)
Supports 6- hannel (5.1) audio
Supports Opti al Output
PCI-E 3.0 Support:
Low power onsumption and power management features
Power Functions:
Supports ACPI (Advan ed Configuration and Power Interfa e)
Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off)
Exp nsion Slots:
1x PCI-E 16x slot
1x MPCIE/MSATA slot
1x Displ y Port (Full size)
1x HDMI Port (Full size)
- 7 -
Unpacking and
Parts Descriptions
Equipment
The following a essories are in luded with the EVGA Z97 Stinger
Motherboard:
The EVGA Z97 Stinger Motherboard
This PCI-E motherboard contains the Intel Z97 chipset.
I/O Shield
Installs in the system case to block radio frequency
transmissions protect internal components from dust foreign
objects and aids in proper airflow within the chassis.
2x SATA 3G/6G Data ables
Used to support the SATA protocol and each one connects a
single drive to the motherboard.
I/O over
This optional cover attaches to the PCB and covers the I/O
area
Installation D
Contains drivers and software needed to setup the
motherboard.
User Manual
The user manual you are reading right now!
- 8 -
Intel Z97 Stinger Motherboard
The EVGA Z97 Stinger Motherboard with the Intel Z97 and PCH Chipset. Figure 1
shows the motherboard and Figure 2 shows the ba k panel onne tors
FIGURE 1. Z97 Stinger Motherbo rd L yout
- 9 -
1. CPU Socket 1150 7. Intel SATA 6G/3G Ports 13. Reset Button
2. Intel Z 7 Southbridge 8. Front Panel Connectors 14. PCI-E Slot 16x/8x
3. CPU Fan Header (1 amp PWM)
. Debug LED / CPU Temp Monitor 15. Mini PCI-E/mSATA
4. DDR3 Memory DIMM Slots 1-2
10. USB 3.0 Headers 16. Back Panel Connectors (Figure 2)
5. 24-pin ATX power connector 11. CMOS Battery 17. 8 pin EPS Connector
6. Fan Headers (1 amp DC) 12. Power Button 18. Removable BIOS Chip
PCI-E Slot Breakdown
PCI-E Lane Distribution
PE1 – x16
- 10 -
Figure 2. Ch ssis Re r P nel Connectors
1. USB 2.0 4. eSata 7. HDMI
2. USB 3.0 5. NIC Port 8. Optical Out
3. BIOS/CMOS Reset 6. Display Port . Analog Audio Output Jacks
Analog Audio Port Breakdown 2/2.1 (Channel) 4.0/4.1 (Channel) 5.1 (6 Channel)
Blue Line in Line In Line in
Green Line Out/ Front Speaker/ Front Speaker/
Speaker Out Speaker+Sub Out Speaker+Sub Out
Pink Mic In Mic In Mic In
Black
Rear Speaker Out Rear Speaker Out
Orange
Center/Voice channel
