EVOC EC0-1815V2NAR Manuale utente
EC0-1815V2NAR
ATX 单板
ATX Motherboard
Version: C01
Copyright Notice
Information offered in this manual is believed to be correct at the time of printing, and
is subject to change without prior notice in order to improve reliability, design and
function and does not represent a commitment on the part of the manufacturer. In no
event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of improper installation and/or use, or inability to
use the product or documentation.
This user manual is protected by copyright. No part of this manual may be reproduced,
stored in any retrieval system, or transmitted, in any form or by any means,
mechanical, electronic, photocopied, recorded or otherwise, without the prior written
permission from the manufacturer.
Trademarks
EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other
product names mentioned herein are used for identification purposes only and may be
trademark and/or registered trademarks of their respective companies.
Please visit our website: http://www.evoc.com for more information,
Hotline: 4008809666
Safety Instructions
1. Please read this manual carefully before using the product;
2. Leave the board or card in the antistatic bag until you are ready to use it;
3. Touch a grounded metal object (e.g. for 10 seconds) before removing the board
or card from the anti-static bag;
4. Before installing or removing a board, wear the ESD gloves or ESD wrist strap;
handle the board by its edges only;
5. Before inserting, removing or re-configuring motherboards or expansion cards,
first disconnect the computer and peripherals from their power sources to
prevent electric shock to human bodies or damage to the product;
6. Remember to disconnect the AC power cord from the socket before removing
the board or moving the PC;
7. For PC products, remember to disconnect the computer and peripherals from the
power sources before inserting or removing a board;
8. Before connecting or disconnecting any terminal, peripheral or any device, be
sure the system is powered off and all the power sources are disconnected;
9. After turning off the computer, wait at least 30 seconds before turning it back on.
Contents
Chapter 1 Product Introduction.....................................................................................1
Overview ..................................................................................................................1
Mechanical Dimensions, Weight and Environment .................................................1
Typical Consumption ...............................................................................................1
Microprocessor ........................................................................................................2
Chipset .....................................................................................................................2
System Memory .......................................................................................................2
Display Function......................................................................................................2
Network Function ....................................................................................................3
Audio Function ........................................................................................................3
Power Feature ..........................................................................................................3
Expansion Bus .........................................................................................................3
Watchdog Function ..................................................................................................3
Operating System.....................................................................................................3
On-board I/O............................................................................................................4
Chapter 2 Installation....................................................................................................5
Product Outline ........................................................................................................5
Locations of Connectors ..........................................................................................6
Structure...................................................................................................................7
Jumper Setting .........................................................................................................8
Serial Port ................................................................................................................9
Status Indicating and Control Connector..................................................................9
ATX Power Switch and Hard Disk Indicator Connector..........................................9
Power Indicator Connector.......................................................................................9
Loudspeaker Output Connector..............................................................................10
7pin SATA Connector.............................................................................................10
KB/MS Connector..................................................................................................10
USB Port ................................................................................................................10
Audio Connector ....................................................................................................11
GPIO Connector.....................................................................................................12
TPM Connector......................................................................................................13
LAN Port................................................................................................................13
2x8 Pin VGA Connector ........................................................................................14
Display Port ...........................................................................................................14
DVI Connector.......................................................................................................14
Motherboard Power Supply Connector..................................................................15
3-pin System Fan Connector ..................................................................................15
4-pin CPU Fan Connector......................................................................................16
Installing the CPU..................................................................................................16
Installing the CPU Fan...........................................................................................16
PCI Connector........................................................................................................18
PCIe x16 Connector ...............................................................................................19
PCIe x4 Connector .................................................................................................20
Hot-swap of SATA Hard Disk ................................................................................21
Chapter 3 BIOS Setup ................................................................................................24
UEFI Overview......................................................................................................24
UEFI Parameter Setup............................................................................................24
Basic Function Setting for UEFI............................................................................25
System Resource Managed by UEFI under X86 Platform .....................................41
Chapter 4 Installing the Drivers..................................................................................46
Appendix ....................................................................................................................47
BPI Overview.........................................................................................................47
Troubleshooting and Solutions...............................................................................48
Chapter 1 Product Introduction
EC0-1815V2NAR - 1 -
Chapter 1 Product Introduction
Overview
EC0-1815V2NAR is an ATX single board computer, developed based on Intel® Q77
chipset. It complies with Ivy Bridge/Sandy Bridge LGA1155 dual core/quad core
processor; supports 1600/1333/1066MHz DDR3 memory up to 16GB; six SATA high
speed connectors, supporting RAID0/1/5/10; various display connectors supporting
triple display function; two gigabit LAN ports; six RS232 ports (two support
RS232/485); four USB3.0 ports and four USB2.0 ports; PCIe x16, PCIe
x4(EC0-1815V2NAR-01 is not supported)and PCI bus expansion.
EC0-1815V2NAR mainly targets such application fields as railway transportation,
financing and telecom terminals, etc. Its high-end performance and abundant
functions will play an important role in various application fields.
Mechanical Dimensions, Weight and Environment
Dimensions: 304.8mm (L) x 190.5mm (W) x 80mm (H);
Net Weight: 0.56Kg;
Operating Environment:
Temperature: -5C ~ 60C;
Humidity: 10% ~ 90% (non-condensing);
Storage Environment:
Temperature: -20C ~ 80C;
Humidity: 10% ~ 90% (non-condensing);
Typical Consumption
The typical consumption is based on the following idle status values.
Chapter 1 Product Introduction
- 2 - EC0-1815V2NAR
Memory: Kingston DDR3 1066 4GB*2 ;
Operating System: Windows XP;
[email protected]；+5%/-3%；
[email protected]；+5%/-3%；
[email protected]；+5%/-3%；
Microprocessor
Intel® Core™ Ivy Bridge/Sandy Bridge CPU of LGA1155 package.
Note: different CPUs may have different requirements for memory and functions of
the motherboard.
Chipset
Intel® Q77
System Memory
Provides two 240Pin DDR3 memory slots, supporting Un-buffered
Non-ECC/Un-buffered ECC (requiring support from CPU) memory and dual-channel
function. The maximum memory capacity supported by a single bank is up to 4GB
while the total memory capacity is up to 16GB.
Display Function
Supports DVI, VGA and DP display: DVI and DP support hot swap function as
well as independent display, dual display clone mode, dual display expansion
mode, triple display clone mode or triple display expansion mode output;
VGA supports 2048x1536@75HZ, 32bit color depth in maximum, DVI
supports 1920x1200@60HZ in maximum, while DP supports
2560x1600@60HZ in maximum.
Note: triple display function only supports two DisplayPorts with VGA or DVI mode.
Chapter 1 Product Introduction
EC0-1815V2NAR - 3 -
Network Function
Provides two 10/100/1000Mbps LAN ports; LAN1 supports Wake-on-LAN, LAN
booting and AMT8.0 functions.
Audio Function
Adopts HDA standard, supporting rear panel MIC-IN/LINE-IN/LINE-OUT (default),
SPDIF (optional), 5.1 sound track (optional) or dual channel power amplifier function
(optional, power consumption for single channel is 2W).
Power Feature
Adopts standard ATX power supply; the board supports the status of S0, S1, S4 and
S5.
Expansion Bus
Provides four 32-bit PCI slots, complying with PCI Rev2.3 standard; one PCI Express
x16 slot, complying with PCI Express 1.0, 2.0 and 3.0 standards; one PCI Express x4
slot(EC0-1815V2NAR-01 is not supported), complying with PCI Express 1.0 and 2.0
standards.
Watchdog Function
255 levels, programmable by minute or second;
Supports watchdog timeout interrupt or reset system.
Operating System
Supported Oss: Windows xp, Windows 7, linux;
Note: it is recommended to use Windows 7 operating system, the driver program of
USB 3.0 only supports Windows 7.
Chapter 1 Product Introduction
- 4 - EC0-1815V2NAR
On-board I/O
Six serial ports: COM1/COM2 supports RS-232/RS-485 mode selection while
COM3/COM4 supports Pin9 12V/5V/RI selection;
Six SATA connectors (SATA1 and SATA2 support SATA3.0 standard) support
hot swap function (Please set the function in BIOS) and RAID0, 1, 5 and 10;
Four USB2.0 ports; the rear panel provides four USB3.0 ports (complying with
USB2.0);
One PS/2 keyboard/mouse connector;
One TPM connector;
One 16-channel digital I/O connector;
Tips: how to identify the alarms
1. Long “beep” indicates system memory error;
2. Short “beep” indicates to power on the computer.
