Evolution Digital HD Set-Top Box Manuale utente
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong is provided for your safety. When the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus. Ensure that the
power cord receptacle is accessible such that power can
be easily disconnected if required.
11. Only use the attachments/accessories specified by
the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Evolution Digital HD Set-Top Box
Important Safety Instructions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO
NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT.
APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFERS SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
NO NOT OPEN
FCC Information
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or
television reception which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connecttheequipmentintoanoutletonacircuitdifferent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Onlyshieldedinterfacecableshouldbeused.
Finally, any changes or modifications to the equipment by the
user not expressly approved by the grantee or manufacturer could
void the user’s authority to operate such equipment.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defective. And please call a repair man in your location.
When used outside of the U.S., it may be used HAR code with fittings of an approved agency is employed.
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not
perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HD
Thank You for choosing the Evolution Digital High-
Definition Set-Top Box (HD STB). You can now enjoy
viewing Standard-Definition (SD) or High-Definition
(HD) programming on an analog or digital television
set. When connecting the Set-Top Box with an HDMI
cable to your HDTV, you will be able to view HD
programming with easy-to-use on-screen menus
and navigation.
Setup your HD STB by
following the connection
diagrams on page 3.
Activate your HD STB
by calling your cable
provider or going online
(if available).
Pair your remote with your
HD STB and TV by following
the directions on page 6.
1 setup 2 activate 3 pair remote
Let’s get started! è
2
Chapter 1 | Getting Set Up
HD In the user guide ê
Cable Connections 4
HDTV or SD Coaxial A/V
Activation 5
Remote Control 6
Pair your remote control 7
Remove remote control pairing 7
Menu 8
FAQs 10
In the box ê
HD Set-Top Box
Power Cord
Adhesive
Velcro
Remote with
Batteries
HDMI Cable
TV
M enu
Exit
Last
Pg Pg
Info
VOL CH
3
1
Setup: Cable Connections
HDMI Set-up
To TV
HDMI (IN)
To TV
To ElectricalOutlet
To Coaxial Wall Outlet
CABLE IN
To TV
To ElectricalOutlet
To Coaxial Wall Outlet
HDMI Connection è
HDMI allows you to take full advantage
of the Evolution Digital HD Set-Top Box
high-definition digital features.
1. Connect the coaxial cable to the
cable wall outlet and the “CABLE IN”
port on the cable box.
2. Connect the HDMI cable to the
“HDMI” port on HD Set-Top Box and
the “HDMI” port on your HDTV.
3. Connect the power cord to the
electrical wall outlet and the “DC 5V
IN” port on the HD Set-Top Box.
Note: HDMI cables carry audio and video to the TV.
SD Coaxial Audio/Video
Connection ç
1. Connect the RF coaxial cable to the
cable wall outlet and the “CABLE IN”
port on the HD Set-Top Box.
2. Connect the smaller RF coaxial
cable to the “RF OUT” port on the
HD Set-Top Box. Connect the other
end to the input port on the TV.
3. Connect the power cord to the
electrical wall outlet and the “DC 5V
IN” port on the HD Set-Top Box.
Note: Make sure the channel 3/4 switch matches the
channel on your TV. For example, if your cable box is
set to “3”, make sure your TV is on channel “3”.
OR
4
2
Before you activate
1. Complete the Cable Connection steps
prior to activating.
2. Have the HD Set-Top Box Serial Number
available. This can be found on the bottom of
the HD Set-Top Box or on the side panel of the
product packaging.
3. Have your cable provider customer account
number accessible. This is typically found on
your cable provider billing information.
Now you are ready to activate!
4. Activate your HD STB by calling your cable
provider directly.
Note: Installation and activation will not impact your current
existing cable service.
Activation
Why do I need to activate my HD Set-Top Box?
Activation essentially “turns on” your digital box in your home and on your cable provider’s network.
5
Remote Control
TV Input*
Toggle TV Input
Info
View the channel name
and number, date and time
Page Up
For future use
Menu
Display the Main Menu
OK
Select a highlighted item within
Menus. Display channel name
and number, date and time
Volume
Audio up & down
Guide
For future use
Yellow A
Toggle to secondary language
(if available)
*TV must be programed with the remote
LED Indicator
Button press and special
command indication
TV Power*
Turn your TV on or off
Last
Return to the previous channel or menu
Exit
Return to watching TV
Page Down
For future use
Channel
Channel up & down
Mute
Sound on & off
Red C
Toggles through available closed captioning
Setup
Program your remote control to your STB
and TV
NOTE
• Wheninserting
batteries,makesure
thatthepolarity(+/-)
iscorrect.
• TheLEDonthetopof
theremoteisavisual
indicatorthatconrms
theremotehas
powerwhenabutton
ispressed.
• Yourremotemayvary
slightlyfromtheone
picturedhere.
However,basic
functionsshould
remainthesame.
