3-Axis Video Stabilized Handheld Gimbal for iPhoneGuilin Feiyu Technology Incorporated CompanyV 2.0ENUser Manual

1. Product Overview*The showing smartphone is only for referenceFunction buttonJoystick1/4 inch screw holeBluetooth shutterUSB portPanning axisSmartphone adapterTilting axisRolling axis1/4 inch screw holeHandleTrigger buttonKnob ring1Status indicator

Double tapTrigger ButtonTrigger ButtonLong pressLong press + joystick up and down*Never submerge the gimbal in waterWater Splash Proof2Lock ModeControl the App Lens ZoomPanning Reset

Small camera( For reference )Enclosed:How to use the compatible accessoriesPortable bag X1Compatible accessoriesX2Package ListUSB cable X1Battery (Type:22650)X1After installation:3

2. User Guide21Install the batteryRemove the handle and insert one 22650 battery into it.Attach the smartphone with the quick-release adapter, and ensure it is secure.Install the smartphone Tips: Please take o󽗈 the protective casing of the smartphone before installation.(1) Please install the smartphone before powering on the gimbal(2) When not in use, turn o󽗈 the gimbal and then remove the smartphoneAttention !!4

34!Power on / o󽗈Power on: Long press function button and release it until the green light is on.Power o󽗈: Long press function button and release it until the red light changes from quick 󽗊ashing to constant.In case of low battery, the indicator will 󽗊ash red 3 times every 5 seconds. Please charge SPG or replace the battery.Attention: Make sure the smartphone is secure before power on the Gimbal.How to balance adjustmentIf the smartphone tilted to the left, then loose the knob ring, move the cross arm to the right, try to adjust to the best balance and tight it.If the smartphone tilted to the right, then loose the knob ring, move the cross arm to the left, try to adjust to the best balance and tight it.LTCross armKnob ringLTCross armKnob ringT=TightL=LooseBest BalanceBalance Adjustment5

3. Download and connect App1Download App2App Store(1) iOS version:(2) Android version:Google playConnecting AppStart the App on your smartphone,follow the instructions to connect the smartphone with gimbal via bluetooth.*Please scan the two-dimensional code via the browser.Download "Feiyu ON" and install it.TIME-LAPSE

OM-OLS

VIDEOPHOTOSQUAREFANC

SPG seriesSPG ConnectSPG series 2000FY_SPG _XXFY_XXX_XXFY_XXX_XXFY_XXX_XX×ConnectChoose a gimbal6Feiyu ONDownloadGuiLin FeiYu Technology Incorporated CompanyFeiyu ONFeiyu ONDownloadGuiLin FeiYu Technology Incorporated CompanyFeiyu ON

4. Mode / Function Operation InstructionsFunction ButtonDouble tapDouble tapSingle tapFunction Function Trigger ButtonExplanationExplanationPanning Mode / Lock ModeLock ModeControl the App Lens ZoomPanning ResetPanning and Tilting ModeSingle tap to switch between panning mode and lock modeUnder panning and tilting mode, single tap to switch to lock modeMake the lens rotate 180 °Triple tapLong pressLong press + joystick up and downRotate 180°in horizontalReset the tilting axis of the gimbal to initial orientation andEnter the lock mode, release it to return to before modeRestore the initial follow state of the panningJoystick up and down to control the App lens zoom; left and right to control the panning initial modeQuadruple tapResetLong press until the red light 󽗊ashes quicklySingle tap again to awake the gimbal, or triple tap to initialize the gimbalStandby7

Bluetooth shutter

Explanation of LED indicator statusVertical Shooting5. Operation

Explanation of joystick controlOther functionsPower on / o󽗈Identify the current mode of thegimbal by the indicatorFunction Button

UpDownLeftRight

Indicator

statusMode / Status

Blue light 󽗊ashes onceBlue light 󽗊ashes twicePanning modePanning and Tilting modeLock mode / Initialize the gimbalBlue light constant onBlue light keeps 󽗊ashingInitialization failure / MalfunctionBlue light 󽗊ashes for three timesStandbyLow battery Red light 󽗊ashes three timesRed light keeps 󽗊ashingEntering standby / Entering power o󽗈

Switch the working mode

Bluetooth name: FY_SPG_xx

Tips: App or Bluetooth connection, you can click the Bluetooth shutter to shoot.

Status indicator
