Node Pro - Prusa MK3S
Quick Start Tutorial
Last update 11.04.2022
Scope of this document
This setup document is unique to Prusa i3 MK3S/MK3S+
printers. We have not tested extensively on MK3 or earlier
version but we expect the steps to be similar.
Steps:
●What is in the box
●Preparation for installation
●Printing Case / Shells
●Linking up Node’s Cable
●Installing Case
●Setting up WiFi
●Connect to Node via Web Server
●Test Print
What is in the box
In the Node package you received you should
have the following components:
●A Node module
●A Type C data cable
●A 5V charging adapter (please use this
instead your existing ones)
●TF card to SD card converter
●8GB SD card(inserted in Node)
Node Layout
1. Reset button.
2. USB Host. (Printer)
3. USB-C power port.
4. SD socket slot.
5. GPIO expansion port.
6. I2C expansion port.
7. UART expansion port.
8. Status light.
9. SD card plug
10. OLED socket slot. (FPC
wiring)
Prepare to set up Node
Tools you need:
●MicroSD/TF card, best to be name brand.
●A computer that can read and write to SD card in FAT32 format (Windows / OSX / Linux)
●microSD/TF Card reader
●M4 hex key
●Utility knife
●Needle nose pliers
Printing Node holder (just for prusa mk3s /mk3s+)
We created a Node case holder for
MK3S/MK3S+ to make it easier to install and
organize. This is an optional but
recommended print.Please download Node
case holder here.
Print parameters:
●0.4mm Nozzle/Extrusion
●0.2mm layer thickness
●15% infill
●3 Top/Bottom Layers
●Print flat as seen on the right
Detect NodePro firmware version
Please confirm the firmware version of your
NodePro before you start using it.
We recommend that you update to the latest
version: 2022-10-19-2008-PRUSA-MK3S
Please refer this doc to update your firmware:
https://docs.google.com/presentation/d/16Nf5uY
kNyQBRbagg_cUlCnZcxTsM7C5II71hJjXmGPo/e
dit?usp=sharing
Remove the two screws
on the MK3 frame
Remove the two screws pointed by the yellow
arrows in the picture on the right.
You’ll need a M4 hex key to do this.
