Field Controls Eliminator Manuale utente
©2008 Field Controls Co. Form #4317 Printed in U.S.A. (2008 CP)
Eliminator Foundation Vent Fans were installed in homes
with high wood moisture content in the 28% to 30%
range. Over a thirty day period, the moisture content was
measured at weekly intervals. Homes with the Eliminator
installed saw a reduction of moisture levels to as low as
16% and 17%. A wood moisture level of 20% or less is
considered ideal. Homes without the Eliminator showed no
reduction in moisture content.
“The Eliminator performed well, even under severe moisture
problem conditions… the amount of air moved is sufficient to
correct the problems present.”
Cliff Consulting
Columbia, S.C.
Independent Test Results
Moisture Content Level
week 1 week 2 week 3 week 4
10
20*
30
0
*Ideal wood moisture level= 20% or less
Homes with the Eliminator Foundation Vent Fans installed
Homes without the Eliminator Foundation Vent Fans installed
“The Eliminator effectively reduces radon
gas and moisture levels in the typical
crawl space.”
Voltage 115VAC
Amps .60 Amps
Cubic feet per minute 100 CFM
Housing Material Galvanized Steel
Number of Units Required One per 1,000 square feet of
crawl space
Temperature Switch
Operation Above 50°F
De-humidistat (Optional) Adjustable from 20%-80%
Mounting Plate Dimensions 14
3
⁄
8
” x 6
7
⁄
8
”
Specifications
252.522.3031 • fieldcontrols.com
©2011 Field Controls Co. Form #4317 Printed in U.S.A. (2011 RS)
Introducing the Healthy Home System™
Field Controls has developed the premier system that
simply and inexpensively transforms the heating and
cooling system in any home into a Healthy Home
System. The Healthy Home System goes beyond
traditional technology to ensure that indoor air is Fresh,
Clean, and Pure.™ Creating a custom Healthy Home
System is easy. Start with a Healthy Home System
Control and select the appropriate Fresh Air Damper,
Media Air Cleaner, and UV-Aire model that’s right for
your heating and cooling system.
Healthy Home
System™ Control
Media Air
Cleaner™ UV-Aire®
Air from all rooms
RETURN To all rooms
FRESH, CLEAN, PURE AIR
Fresh Air
Damper
Upgrade any heating and cooling system with a Healthy Home System
delivering air that is Fresh, Clean, and Pure.
FRESH
Fresh Air Ventilation CLEAN
Media Air Cleaners PURE
UV-Aire® Purification
Eliminator®
Helps eliminate moisture, mold, and
radon gas from crawl spaces
Foundation Vent Fan
• Reduces moisture content and mold
potential in crawl spaces, floor joists,
flooring, and other support wood
• Circulates air in crawl space
• Removes radon gas
• Automatic operation
• Temperature or humidity activated
• Reduces potential for airborne mold
infiltration into home
• Reduces termite potential
The Eliminator Foundation Vent Fan is a motorized
fan designed to circulate fresh air in a home or
building crawl space to eliminate cancer-causing
radon gas and reduce moisture that can lead
to mold formation and termite infestation. The
Eliminator attaches to virtually any standard
foundation vent. It is wired for automatic operation
when the temperature exceeds 50oF. An optional
de-humidistat activates the fan when humidity
exceeds the owner-determined setting (20%–80%)
in conjunction with the built-in temperature control.
The temperature control is shielded from the sun
to prevent false readings that could lead to costly
operation during cold weather.
Note: The de-humidistat is designed
to be installed remotely, so it can
be placed in the crawl space where
moisture is most likely to accumulate.
www.fieldcontrols.com
Optional De-humidistat
The Eliminator®
Foundation Vent Fan
EL-1
Crawl space
The Eliminator®
Foundation vents
De-humidistat
Typical crawl space under home with mold growth
Facts about radon, mold, and moisture.
Mold
1. The Eliminator is attached to any standard foundation
vent, and then wired to a 120v source.
2. Optional de-humidistat is placed in center of crawl
space area.
3. When temperature in crawl space exceeds 50oF
and/or when humidity exceeds de-humidistat setting,
the Eliminator is engaged.
4. Moist air and radon gases are pulled from crawl
space and replaced with fresh, outside air.
5. When thermostat or de-humidistat are satisfied, the
Eliminator is deactivated.
Typical installation
Radon
Radon is a radioactive gas that is considered to be a
health hazard affecting indoor air quality worldwide.
Radon gas is the second most common cause of lung
cancer in the United States. One in fifteen homes in
the U.S. has a high level of radon.
Mold
According to a study by the Mayo Clinic, nearly all
chronic sinus infections are a result of mold. Since up
to 40% of the air we breathe in the home can come
from the crawl space, mold in the crawl space means
mold in the home. The EPA recommends to keep
humidity levels in the crawl space to 40%–50% to
reduce the likelihood of mold formation.
Moisture
Excess moisture in a crawl space can have serious
consequences. Not only can it lead to mold formation,
it also increases termite potential and can increase the
potential for rot in floor joists, cross members, and sub-
flooring. Moisture level in wood should be less than
20%. In high humidity areas, that number can easily
exceed 30%. To maintain safe moisture levels, experts
recommend a plastic moisture barrier on the ground in
combination with a vent fan such as the Eliminator.
How it works
