Flycam Vista-II Manuale utente
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Vista-II Stabilizer Arm & Vest (VSTA-II-AV)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
Vista-II Vest back (Part-1a)
Vista-II Arm (Part-3)
Storage Bag (Part-5)
Vista-II Vest front (Part-1)
2x Heavy
Tension Springs
3/16mm,2.5mm,
1.5mm Allen Key
Hip Pad (Part-2)
2x Bush (Part-4)
2
Safety Hints
ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO
THE GEAR!
BE WATCHFUL OF THE HANDS
Cauously operate to avoid pinching your hand/ngers inside the arm.
ALWAYS ESTABLISH THE CORRECT BALANCE
Adjust the weight balance before telescoping the length.
NEVER LEAVE THE FIXTURES LOOSE
All the knobs/screws must be locked ghtly to avoid unbalancing of the whole
camera setup.
BE HIGHLY VIGILANT WHILE ASSEMBLING
Lack of aenon while aaching Stabilizer, Arm & Vest together can cause
substanal damage to equipment.
NEVER LEAVE THE ARM UNATTANDED
Don’t let an unloaded arm swing about as it may hit you or someone near you.
FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE
OPERATION.
SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS
AVAILABLE ‘ONLINE’ BY CONTACTING OUR SALES REPRESENTATIVE.
3
1. Aach both parts of Jacket by aaching the
top shoulder buckles (Part-1a) with
(Part-1).
2. Follow same step on other side. Then wear
the jacket/vest.
3. Aer wearing the Vest, aach the waist
buckles (Part-1a) with (Part-1) of both side.
4. Now aach the Hip Pad (Part-2) from both
sides by aaching the buckles with (Part-1)
5. Then ghten the strap properly.
Vista-II Vest Setup
8. You can also adjust the height of the Socket
Block (Part-1).
9. Adjust the Height provided with the knob.
6. Length of chest plate (Part-1) can be adjusted
according to the height of person.
7. Then Using the pin & knob (Part-1), as shown
in image.
10. You can also remove the Socket Block (Part-1)
11. Adjust to le and right posion with the pro-
vided knob as shown in the image.
1 2
3
4 5
7 6
11
10
9
8
4
12. Loosen the knobs of Socket Block on Vest
(Part-1).
13.Then Insert male connecng socket of Arm
(Part-3) into Socket Block of Vest (Part-1).
14. Aer ghtening the both knobs of Socket
Block on Vest (Part-1) to secure the secon.
15. You can adjust the tension of Arm (Part-3)
with mounted Stabilizer, by provided knob,
according to your setup requirement.
16. Adjust the li with Arm angled slightly up,
and the knob will turn easily. Both Arm
secons should track together.
17. Insert bush (Part-4) on arm mounng post
(Part-3)
18.Then insert into the handle of your stabilizer.
NOTE: 17. For aaching the Stabilizer to Arm & Vest, keep the handle of Stabilizer straight in accordance
to the pin of Arm.
18. There is a 16mm mounng post and we are giving 19 and 22mm bush, so you can easily mount the
stabilizer (Not Included) on mounng post of arm according to your requirement.
Vista-ll Arm Setup
NOTE: It can be operated eciently either right or le handed.
NOTE: Adjust the ‘forearm’ (secon nearest to Stabilizer) rst, then the ‘upper arm’ secon.
14
13
18
12
15
17
16
5
To Use As Single Arm Conguraon
19. Pull the pin from middle jointer.
20. Remove one secon of the Arm (Part-3).
23. Finally, single arm (Part-3) properly aached
as shown in the image.
21. Now, aach the single arm (Part-3)
22. Insert the pin from middle jointer to secure
with it.
19
21
20
22
23
The arm tension is adjusted for the heaviest camcorder it can hold, so it does not bottom-out when you
put the camcorder and sled on it for the first time.
Now adjust Arm for the weight of your camcorder:
With the Vest On, attach Arm & unlock the rig.
Move Arm to the middle of its booming (up and down) range and let go (If it stays where it is, you are
probably close to the right adjustment).
Keep making small adjustments until the camcorder does not rise or fall when you let go of it in the
middle of its booming range.
Arm Adjustment
Posion arm
Move the camcorder to your left so the arm crosses your body.
Adjust the arc of your arm so the rig feels comfortable to you.
Keep the camcorder close to your body.
For Interchanging the Spring, Follow this video
https://bit.ly/3eYzHs6
6
YOUR VISTA-II STABILIZER ARM & VEST
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Bearing Maintenance
If aer some period of me the bearings stop running smoothly as when new, you can oil it with light
lubricang oil. We recommend using only a few drops, anything more than a lile will end up dripping
from bearing and onto the rest of your Arm. Be sure to keep the oil away from your Camera, and clean up
any over-spill when done.
Cleaning
Do not use solvents or harsh cleaners of any kind on Vista-II Arm & Vest. If the unit becomes dirty, use
only a cloth or sponge with water and a very mild detergent to gently rub the unit clean. Rinse well.
Storage
If you are going to store Flycam Vista-II Arm & Vest for a long period of me, then we recommend storing
it up-right in a dry or low-to-normal humidity area.
If you are unable to nd an environment like this, then we suggest you store the unit in an airght plasc
container or bag. Keeping the unit upright helps to lessen stress on the system.
Maintenance
7
Warranty: We oer one year warranty for our products from date of purchase. Within this period of
me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor
does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to
inspecon and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
