Folger Technologies FT-6 Manuale utente

FT-6

Assembly Guide v0.05 Alpha

Table of Contents

ALPHA WARNING..........................................................................................................................1

Introduction.....................................................................................................................................2

Contacting Folger Tech..................................................................................................................3

Preparation and Tip ......................................................................................................................4

ACM Part Li t...............................................................................................................................5

T-Nut U age...................................................................................................................................8

A embly

Z A embly.................................................................................................................................9

Frame A embly.......................................................................................................................13

X A embly...............................................................................................................................18

Y A embly...............................................................................................................................20

Bed A embly...........................................................................................................................26

None/Single Extruder...............................................................................................................31

Carriage................................................................................................................................32

Dual Extruder...........................................................................................................................36

Carriage................................................................................................................................37

Z Belt A embly........................................................................................................................38

Configuration................................................................................................................................40

Community ran re ource (unofficial)..........................................................................................40

ALPHA WARNING

Thi i an Alpha ver ion of the a embly guide. It ha only been

relea ed a a preview of the completed guide.

Thi guide i not meant to be u ed to a emble the kit. Do not

following anything within thi guide a it may be wrong.

U e a beta or better guide ver ion for a embly of the kit.

Introduction

Congratulation ! If you are looking over thi guide it mean that you are the proud owner of a Folger Tech

FT-6 3D printer.

Our goal a a company i to provide affordable 3D printer to con umer worldwide. On top of thi , we want

everyone’ fir t printing experience to be a great one. So thi guide wa a embled to provide guidance in

a embling and under tanding common procedure while u ing thi printer. It cover everything from

a embly to the maintenance required to keep the printer performing like new.

Contacting Folger Tech

We under tand that thi guide only cover the ba ic of your Folger Tech kit. If at any time you need more

a i tance, vi it our upport page at Folger Tech Support to end u a me age or give u a call at (888)

397–8160 and we will be happy to addre your que tion or concern.

DISCLAIMER OF LIABILITY: FOLGER TECHNOLOGIES LLC pecifically DISCLAIMS LIABILITY FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES and a ume no re pon ibility or liability for any lo or

damage uffered by any per on a a re ult of the u e or mi u e of any of the provided information or product.

FOLGER TECHNOLOGIES LLC a ume or undertake NO LIABILITY for any lo or damage uffered a a

re ult of the u e, mi u e or reliance on the information and or product. USE AT YOUR OWN RISK: Never

leave your printer unattended.

Preparation and Tips

•Unwrap and lay out all of the part in the box.

•Pull off all of the protective film on the ACM part and verify with the li t on the next page.

•Verify that all of the hardware li ted on the hardware bag are included (there will be extra ).

• We recommend orting the hardware into container to make identification fa ter during the build.

(egg carton can be u eful for thi )

•Pull off the film and remove all of the cutting particle from the 2020 and 2040 beam .

•Make ure you have a large, clear, and flat urface to build on.

•Go low and check your work, ru hing could cau e i ue in print quality and operation.

•Make ure there i no damage on any part and report any i ue to u right away.

•Be careful when handling the ACM part , the edge are harp.

•A deburring tool work great for knocking down the harp edge of the ACM.

•Gather the part called out in each tep and read through all of the text before performing the tep.

•Pay clo e attention to the image in each tep, orientation i very important.

•Printing out the ACM part li t make it quick and ea y to reference during a embly.

•To help with orientation: X i ide to ide, Y i front to back, and Z i up and down.

ACM Parts List

(8) BFP-01 (4) BFP-02 BFP-03 BFP-04

BFP-05 BFP-06 BFP-07 BFP-08

BFP-09 BFP-10 (2) BFP-11 BFP-12

ACM Parts List continued)

BFP-13 BFP-14 BFP-15 BFP-16

(2) BFP-17 BFP-18 BFP-19 BFP-20

LCD, Hotend, and extruder ACM parts

are listed in their separate sections.

Please go through the ACM parts list above and the labels

on the hardware packages to check your kit s contents.

If anything is missing or damaged, contact Folger Tech

within (14) days of delivery for replacements.

Now let s get this kit built!

T-Nut Usage

1) nsert the bolt through the hole in the panel then turn the t-nut on a few turns.

2) nsert the t-nut into the slot of the extrusion making sure it is centered.

3) Tighten down the bolt making sure the t-nut turns to lock into the slot.

Bolt T-Nut
