Foxconn 45CS Manuale utente

45CS

Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information



itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.0 for 45CS motherboard.

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed



household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

CAUTION

All trade names are registered trademarks of respective manufacturers listed.



Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard 45CS

is in conformity with



accordance with 89/336 EEC-EMC Directive)

 

disturbance characteristics of information technology

equipment

 

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

 

Part 3: Limits

 

voltage supply systems for equipment with rated current

<= 16A

   

characteristics limits and methods of measurement

Signature : Place / Date : TAIPEI/2008

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name: 45CS45CS

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

 

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2008

Installation Precautions

Please carefully read the following procedures to install your computer :

 

to the motherboard and CPU due to high temperature. Never turn on the

computer if the CPU fan is not properly installed.

 We cannot guarantee that your system can operate normally when your

CPU/Memory is overclocked. Normal operation depends on the overclocking

capacity of your device.

 hen connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure

their pinouts are matching with the connectors on the motherboard. Incorrect

connections might damage the motherboard.

 When handling the motherboard, avoid touching any metal leads or connec-

tors.

 a PCI Express x16 graphics card installed in your system, we

recommend using a 24-pin ATX power supply to get the best performance.

 Before turning on the power, please make sure the power supply AC input



 To prevent damage to the motherboard, do not allow screws to come in contact

with the motherboard circuit or its components. Also, make sure there are no

leftover screws or metal components placed on the motherboard or within the

computer casing.

 If you are uncertain about any installation steps or have a problem related to



CAUTION

 



comes out as a spark which will quickly damage your electronic equipment.

Please wear an electrostatic discharge (ESD) wrist strap when handling

components such as a motherboard, CPU or memory.

 Ensure that the DC power supply is turned off before installing or removing

CPU, memory, expansion cards or other peripherals. It is recommended to

unplug the AC power cord from the power supply outlet. Failure to unplug

the power supply cord may result in serious damage to your system.

TABLE OF CONTENTS

Chapter 1 Product Introduction

 .................................................................. 2

Layout...........................................................................................4

Back Panel Connectors................................................................ 5

Chapter 2 Hardware Install

Install the Memory ........................................................................ 8

Install other Internal Connectors ..................................................9

Jumpers......................................................................................12

Chapter 3 BIOS Setup

Enter BIOS Setup....................................................................... 14

Main Menu..................................................................................14

System Information .................................................................... 16

Advanced BIOS Features...........................................................18

Fox Central Control UnitFox Central Control Unit............................................................. 20

Advanced Chipset FeaturesAdvanced Chipset Features ....................................................... 23

Integrated Peripherals ................................................................ 26

Power Management Setup......................................................... 29

PC Health Status........................................................................ 31

BIOS Security FeaturesBIOS Security Features..............................................................32

Load Optimal DefaultsOptimal DefaultsDefaults................................................................ 33

Save & Exit Setup ......................................................................33

Exit Without Saving ....................................................................33

Chapter 4 CD Instruction

Utility CD contentUtility CD content........................................................................35

Install driver and utility................................................................ 36

FOX ONE

Main Page............................................................................. 38

CPU Control.......................................................................... 42

Frequency Control ................................................................ 44

Limit Setting .......................................................................... 45

Voltage Control .....................................................................47

Fan Control ........................................................................... 48

FOX LiveUpdate

Local Update......................................................................... 49

Online Update ....................................................................... 51

  .............................................................................54

About & Help......................................................................... 56

FOX LOGO.................................................................................57

FOX DMI .................................................................................... 58

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnchannel.com/support/online.aspx

CPU, Memory, VGA Compatibility Supporting Website :

http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx

Support

Thank you for buying Foxcon 45CS motherboard. Foxconn products

are engineered to maximize computing power, providing only what

you need for break-through performance.

With a range of connectivity features for today multi-media computing

requirements, 45CS enables you to unleash more power from your45CS enables you to unleash more power from yourenables you to unleash more power from your

computer.

This chapter includes the following information:



Layout

Back Panel Connectors



CPU Intel®AtomTM processor mounted onboard

Front Side Bus 533 MHz FSB

Chipset North Bridge: Intel® 945GC

South Bridge: Intel® ICH7

Memory 1 x 240-pin DDR2 DIMM socket

Support up to 1GB of system memory

Single channel DDR2 800/667/533MHz architecture

Audio Realtek ALC662 codec

 

2/4/5.1-channel

LAN Realtek RTL8100C chip

Support 10/100Mb/s Ethernet

Expansion Slot 1 x PCI slot

Onboard Serial ATA 2 x SATA connectors

300MB/s data transfer rate

USB Support hot plug

Support up to 6 USB 2.0 ports (4 rear panel ports, 1 onboard USB

headers providing 2 extra ports)

Supports USB 2.0 protocol up to 480Mb/s

Internal Connectors 1 x 24-pin ATX main power connector

2 x SATA connectors

1 x USB 2.0 headers (supporting 2 x USB devices)

1 x Front panel connector

1 x Front audio connector

1 x S/PDIF_OUT connector

1 x TPM connector

1 x IrDA connector

Back Panel 1 x PS/2 keyboard port

Connectors 1 x PS/2 mouse port

1 x Serial port

1 x Parallel port

1 x VGA port

4 x USB 2.0 ports

1 x RJ-45 LAN port

6-channel Audio ports

Hardware Monitor System voltage detection

CPU/System temperature detection

System fan speed detection

CPU overheating shutdown

Green Function Low power consumption and power management features

 

Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4

(Suspend to disk), and S5 (soft - off)

Operating System Support for Microsoft®Windows® Vista/XP

Form Factor Mini-ITX Form Factor, 170mm x 170mm
