Foxconn H61M-S Manuale utente
H61M Series Motherboard
User’s Manual
Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for H61M Series motherboard.
Symbol description:
Caution: refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning: indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard H61M-S/H61M
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current
<= 16A
■ EN 55024/A2:2003 Information technology equipment-Immunity
characteristics limits and methods of measurement
Signature : Place / Date : TAIPEI/2011
Printed Name : James Liang
Declaration of conformity
Trade Name: FOXCONN
Model Name: H61M-S/H61M
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2011
Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU is overclocked. Normal operation depends on the overclocking capac-
ity of your device.
■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or
S/PDIF cables to the internal connectors on the motherboard, make sure
their pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!
TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications..............................................................................2
Layout.......................................................................................................4
Back Panel Connectors............................................................................5
Chapter 2 Hardware Install
Install the CPU and CPU Cooler ..............................................................8
Install the Memory..................................................................................11
Install an Expansion Card ......................................................................14
Install other Internal Connectors ............................................................15
Jumpers..................................................................................................19
Chapter 3 BIOS Setup
Main........................................................................................................23
F-Center .................................................................................................25
Advanced ...............................................................................................30
Boot........................................................................................................36
Power .....................................................................................................37
Health.....................................................................................................39
Security ..................................................................................................40
Exit .........................................................................................................41
Chapter 4 CD Instruction
Install driver and utility............................................................................43
FOX ONE
Main Page ........................................................................................46
CPU Control .....................................................................................50
Frequency Control............................................................................52
Limit Setting......................................................................................53
Voltage Control.................................................................................55
Fan Control.......................................................................................56
FOX LiveUpdate
Local Update ....................................................................................57
Online Update ..................................................................................59
Congure .........................................................................................62
About & Help ....................................................................................64
FOX LOGO.............................................................................................65
FOX DMI ................................................................................................66
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnsupport.com/inquiry.aspx
CPU Support List :
http://www.foxconnsupport.com/cpusupportlist.aspx
Memory, VGA Compatibility List :
http://www.foxconnsupport.com/complist.aspx
Support
Thank you for buying Foxconn H61M/H61M-S Series motherboard.
Foxconn products are engineered to maximize computing power,
providing only what you need for break-through performance.
With a range of connectivity features for today multi-media computing
requirements, H61M-S/H61M enables you to unleash more power
from your computer.
This chapter includes the following information:
■ Product Specications
■ Layout
■ Back Panel Connectors
1
2
CPU
Support LGA1155 for Intel Sandybridge series CPU
Max processor power up to 95W
Support 32nm CPU
For the latest CPU information,
please visit：
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset
Intel®
H61
Memory* 4 x 240-pin DDR3 DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1333/1066MHz architecture
Expansion Slots 1 x PCI Express 2.0 x16 slots
1 x PCI Express x1 slots
2 x PCI slots
Storage H61 chipset:
- 4 x SATA 2.0 connectors 3Gb/s data transfer rate
Asmedia ASM1061:
- 2 x SATA 3.0 connectors 6Gb/s data transfer rate (only for H61M-S)
LAN Realtek 8111E Gigabit LAN chip
Audio Realtek ALC662 audio chip:
- High Denition Audio
- 2/4/5.1-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB H61 chipset:
-
Support up to 10 x USB 2.0 ports (6 rear panel ports, 2 onboard
USB headers supporting 4 extra ports)(H61M)
- Support up to 10 x USB 2.0 ports (4 rear panel ports, 3 onboard
USB headers supporting 6 extra ports)(H61M-S)
Etron EJ168A:
- Support up to 2 x USB 3.0 ports(H61M-S)
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 2.0 connectors
2 x SATA 3.0 connectors(H61M-S)
3 x USB 2.0 header (supporting 6 x USB devices)(H61M-S)
2 x USB 2.0 header (supporting 4 x USB devices)(H61M)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel header
1 x Front Audio header
1 x SPDIF_OUT header
1 x Speaker header
1-1 Product Specications
1
3
Internal Connectors 1 x Chassis intrusion alarm header
1 x COM1 header
1 x TPM header
1 x CLR_CMOS header
1 x Parallel header
1 x ME Jumper
Back Panel 1 x PS/2 Keyboard/Mouse port
Connectors 1 x VGA port
1 x DVI-D port
1 x HDMI port
6 x USB 2.0 ports(H61M)
4 x USB 2.0 ports(H61M-S)
2 x USB 3.0 ports (H61M-S)
1 x RJ-45 LAN port
3-ports Audio jacks
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
PCI Express x1 Support 250MB/s (500MB/s concurrent) bandwidth
Low power consumption and power management features
PCI Express x16 Support 2.5GT/s (5GT/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4 (suspend to disk), S5 (soft - off)
Support EuP Function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
SMART CHARGER
Operating System Support for Microsoft® Windows® 7/XP
Form Factor Micro ATX Form Factor, 9.6 inches x 8.8 inches (24.4cm x 22.4cm)
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Foxconn Scheda madre
Foxconn
Foxconn A78AX 3.0 Series Manuale utente
Foxconn
Foxconn G45M Series Manuale utente
Foxconn
Foxconn Destroyer Manuale utente
Foxconn
Foxconn P9657AB User's Manuale utente
Foxconn
Foxconn M61PML Series Manuale utente
Foxconn
Foxconn A7DA-S 3.0 Manuale utente
Foxconn
Foxconn A88GM Deluxe Manuale utente
Foxconn
Foxconn A7GM-S Manuale utente
Foxconn
Foxconn P43AL Series Manuale utente
Foxconn
Foxconn 975X7AB Manuale utente
Foxconn
Foxconn 661FX7MF series Manuale utente
Foxconn
Foxconn A78AX-K Manuale utente
Foxconn
Foxconn 6497MC series Manuale utente
Foxconn
Foxconn H61A Series Manuale utente
Foxconn
Foxconn P35AX-S Manuale utente
Foxconn
Foxconn 755FXK8AA series Manuale utente
Foxconn
Foxconn A75MX Series Manuale utente
Foxconn
Foxconn Renaissance Manuale utente
Foxconn
Foxconn G41MD Manuale utente
Foxconn
Foxconn G41MXP Series Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
