Frigidaire AFFC1466DW3 Manuale utente

P08F0060.eps P08D0360.eps P08C0803.eps T08S0004.eps

Product No. AFFC1466DW3

Series 134A

Color white

Volts 115

Wiring Diagram 216993300

Owner's Guide 216993100

Market North America

Energy Guide 216993200

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995454724

05/11/28

(EN/SERVICE/MLR)

365

FREEZER CHEST

Model No.

AFFC1466DW

Publication No: 5995454724 AFFC1466DW3

11/05 2

DOOR

AFFC1466DW3 Publication No: 5995454724

# Functional Parts 3 11/05

* Non-Illustrated Parts

DOOR

POS. NO PART NO. DESCRIPTION

1 216481201 Gasket-door, white

2 5303925107 Lock Assy

* 5300114366 Washer-sealing

5 # 216702900 Key, lock

9 216829104 Panel-lid

10 216923001 Plug button, 1/4", white

11 216129932 Lid, white

* 216858000 Screw, TH#8-18x.500AB, #10

14 216822900 Switch, light/lamp, ramp

15 216846400 Light Bulb/Lamp

16 216817600 Socket, light/lamp, 25 W

18 216897600 Handle, white

23 216212700 Light-signal, amber

27 5303212828 Clip, panel mtg

27* 5304406520 Clip, panel mtg kit, (40)

34 216578504 Shield-light

35 216205400 Washer, signal light

40 216922700 Fastener, .330 dia stud, handle, (2)

47 # 216908000 Harness-lid

57 216899508 Overlay

* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995454724 AFFC1466DW3

11/05 4

CABINET

144

143

146

140

93F

93E

93D

5144

142

140

149

141

139

147

145

P08C0803

100

62A

59A

21 24

148

150

AFFC1466DW3 Publication No: 5995454724

# Functional Parts 5 11/05

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

1 216909800 Catch-lock, white

1A 216818900 Support, lock catch clip

5 # 216325600 Fan Blade

6 216955505 Breaker, hinge side

7 216955504 Breaker, lock side

11 216955500 Breaker, chest end, (2)

13 216934100 Motor, fan, 115 V

18 216965300 Knob, cold control

21 # 216995600 Control, temperature, with sleeve

22 216823500 Clamp, cap tube, cold control

* 5303916855 Tube, sensor sleeve, plastic, clear

24 5300052943 Screw-clamp, truss hd cr, control

25 216966000 Cover, evaporator, manual

27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

28 216035200 Hinge

30 216110700 Breaker, corners

32 5308005500 Drain

39 5303293767 Screw, truss head, 8-18 x 0.625, front, square drive

50 216964800 Bracket, fan motor mount

59 216916201 Basket, blue, upper, (2)

59A 216867401 Basket, blue, lower, (2)

61 216965600 Cover, airflow

62A 131420300 Screw, cr truss head, 8-18AB x 0.750

75 216034307 Panel-access, white

86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming

93D 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)

93E 216327800 Clip, wire

93F 08016582 Screw, hi-lo blunt, 8-18 X 1/2, handle

100 216995200 Track-basket

* 297048000 Screw, anchor, #8, white

139 216965800 Sleeve, suction line

140 216968300 Cover-screw

141 216968400 Trivet, floor vent

142 216989300 Spacer, left, with tape

143 216989400 Spacer, right, with tape

144 218362500 Screw, hex washer head, 8-18AB x 1.250, spacer, (2)

145 216968600 Drain, valve

146 216314500 Spacer, tube

147 216650200 Plug, foam

148 216964700 Bracket, cold control

149 216965700 Cover, molded, foam

150 216997400 Support, track-basket

* 216993200 Energy Guide

* 5303305324 Paint, touch-up, white

Publication No: 5995454724 AFFC1466DW3

11/05 6

SYSTEM

31A

15A

86 86

T08S0004

AFFC1466DW3 Publication No: 5995454724

# Functional Parts 7 11/05

* Non-Illustrated Parts

SYSTEM

POS. NO PART NO. DESCRIPTION

1 # 5303925238 Condenser

4 # 216938600 Drier-filter

5 # 297023000 Harness-main

14 # 216967700 Heater-defrost

15 # 216965200 Evaporator, 2 pass

15A 297031600 Heat Exchanger

16 5308000110 Strap-evap/heater, aluminum, (2)

20 216872200 Thermostat, defrost

22 216056400 Clip, compressor mtg, SPRING

23 # 216744500 Timer-defrost

24 216968500 Bracket-timer

27 5308002681 Grommet, compressor

28 5303212615 Support, compressor

29 # 297054400 Compressor, assy, w/electricals

30 # 297054500 Relay Combo

31A 216968800 Pan-drain, evaporator

42 216232700 Washer, flat, 1"OD x 0.531"ID

43 5303212614 Clip, harness mount

47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

60 216964900 Shield-heat

86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming

87 08037849 Screw, ph truss head, 6-32(T) x 0.500, thread cutting

* 5303298960 Spacer-tube, 0.237" ID
