Frigidaire FFC07K0AW Manuale utente

CHEST FREEZER

Model number

FFC07K0AW

FACTORY PARTS CATALOG

FREEZER

WIRING DIAGRAM - # 216787900

OWNER’S GUIDE - # 216802800

SERVICE DATA SHEET - #216787900

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FFC07K0AW1 FFC07K0AW 134A 115 115

FFC07K0AW2 FFC07K0AW 134A white 115

MARKET

North America

Publication No.

5995362158

011212

-EN/SERVICE /GS

365

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O BOX 212378, AUGUSTA , GA 30917

12/01 2

Publication No FFC07K0AW1/2

5995362158

DOOR

# = Fast-moving Parts 3 12/01

* = Non-Illustrated Parts

FFC07K0AW1/2 Publication No.

5995362158

DOOR

A = FFC07K0A (FFC07K0AW1)

B = FFC07K0A (FFC07K0AW2)

POS. NO PART NO DESCRIPTION

1 216480901 A B Gasket-door,white

9 216061602 A B Panel-inner lid,white

10 216141101 A B Plug button,white

11 216113114 A B Panel-outer door,white

27 5303212828 A B Clip,panel

* 5303917276 A B Insulation-door,fiberglass ,(bulk)

12/01 4

Publication No FFC07K0AW1/2

5995362158

CABINET

# = Fast-moving Parts 5 12/01

* = Non-Illustrated Parts

FFC07K0AW1/2 Publication No.

5995362158

A = FFC07K0A (FFC07K0AW1)

B = FFC07K0A (FFC07K0AW2)

POS. NO PART NO DESCRIPTION

6 216112800 A B Breaker-hinge,white

11 216105600 A B Breaker-ends,white

12A 240415201 A B Label-nameplate,white

18 216707200 A B Knob-control cold

21 # 216787700 A B Control-temperature

27 216337700 A B Screw,hex washer head ,10-24 x 0.500

28 216478800 A B Hinge Assy

30 216105500 A B Breaker-corners,white

71 5303302714 A B Screw,8-18x3/4 ,(2)

75 216329402 A - Panel-access,white

75 216782000 - B Panel-access,white

* 216802800 A B Owners guide

* 5303305324 A B Paint,touch-up ,white

CABINET

12/01 6

Publication No FFC07K0AW1/2

5995362158

SYSTEM

# = Fast-moving Parts 7 12/01

* = Non-Illustrated Parts

FFC07K0AW1/2 Publication No.

5995362158

SYSTEM

A = FFC07K0A (FFC07K0AW1)

B = FFC07K0A (FFC07K0AW2)

POS. NO PART NO DESCRIPTION

1 # 5300120780 A B Condenser

4 216634500 A B Drier-filter

5 216696400 A B Harness-electrical

22 216056400 A B Clip-spring mtg

27 5308002681 A B Grommet,compressor

29 # 216820500 A B Compressor,w/o electricals

30 216649305 A B Controller

32 216694500 A B Clip,controller

55 216696700 A B Capacitor-run,180 VAC ,15 microfarad

85 216533100 A - Wire,ground

85 216818300 - B Wire-ground

86 216707700 A B Screw,8-18 X 1/2
