Frigidaire FFC13C4AW2 Manuale utente

CHEST FREEZER

Model numbers:

FFC13C4AW2

FFC15C4AW2

FACTORY PARTS CATALOG

FREEZER

WIRING DIAGRAM - # 216803900

OWNER’S GUIDE - # 216802800

SERVICE DATA SHEET - # 216803900

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FFC13C4AW2 FFC13C4A 134A white 115

FFC15C4AW2 FFC15C4A 134A white 115

MARKET

North America

Publication No.

5995378535

020919

-EN/SERVICE /MLR

365

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

09/02 2

Publication No FFC13C4AW2, FFC15C4AW2

5995378535

DOOR

# = Fast-moving Parts 3 09/02

* = Non-Illustrated Parts

FFC13C4AW2, FFC15C4AW2 Publication No.

5995378535

DOOR

A = FFC13C4A (FFC13C4AW2)

B = FFC15C4A (FFC15C4AW2)

POS. NO PART NO DESCRIPTION

1 216481101 A - Gasket-door,white

1 216481201 - B Gasket-door,white

2 5303925107 A B Lock Assy

5 # 216702900 A B Key,lock

9 216828904 A - Panel-lid

9 216829104 - B Panel-lid

10 216141101 A B Plug button,white

11 216129821 A - Panel-lid

11 216129920 - B Lid,white

12A 216816801 A B Nameplate

14 216822900 A B Switch,light/lamp ,ramp

15 216846400 A B Light Bulb/Lamp

16 216817600 A B Socket,light/lamp ,25 W

18 216446600 A B Handle

23 5308002706 A B Light-signal,amber

27 5303212828 A B Clip,panel mtg

34 5303296969 A B Shield,lid lamp

40 5309948647 A B Fastener,handle

47 216819900 A B Wiring Harness,lid/defrost ,with light

56 216694200 A B Cap,sig light seal

* 5303925098 A B Insulation

* 5309948955 A - Clip-panel

09/02 4

Publication No FFC13C4AW2, FFC15C4AW2

5995378535

CABINET

# = Fast-moving Parts 5 09/02

* = Non-Illustrated Parts

FFC13C4AW2, FFC15C4AW2 Publication No.

5995378535

A = FFC13C4A (FFC13C4AW2)

B = FFC15C4A (FFC15C4AW2)

POS. NO PART NO DESCRIPTION

1 5303208488 A B Latch,lid catch

1A 216818900 A B Support,lock catch clip

3 216502600 A B Plug,drain ,interior

4 216073905 A B Plug-drain,exterior

6 216110900 A - Breaker

6 216111000 - B Breaker,hinge side

7 216111500 A - Breaker,lock side

7 216111600 - B Breaker,lock side

11 216110800 A B Breaker,chest end ,(2)

18 216707200 A B Knob,temp control

21 # 216714601 A B Control temperature

27 216629600 A B Screw,hex washer head ,10-16 x 0.500 ,tapping

28 216039600 A - Hinge

28 216035200 - B Hinge

30 216110700 A B Breaker,corners

59 216080300 A B Basket

71 5303302714 A B Screw,8-18x3/4 ,(2)

75 216034301 A B Panel,access ,white

* 5303305324 A B Paint,touch-up ,white

CABINET

09/02 6

Publication No FFC13C4AW2, FFC15C4AW2

5995378535

SYSTEM

# = Fast-moving Parts 7 09/02

* = Non-Illustrated Parts

FFC13C4AW2, FFC15C4AW2 Publication No.

5995378535

SYSTEM

A = FFC13C4A (FFC13C4AW2)

B = FFC15C4A (FFC15C4AW2)

POS. NO PART NO DESCRIPTION

1 5303925238 A B Condenser

4 216634500 A B Drier-filter

5 216806900 A B Harness-main

22 216056400 A B Clip,compressor mtg ,SPRING

27 5308002681 A B Grommet,compressor

28 5303212615 A B Support,compressor

29 # 216856700 A B Compressor,w/o electricals

30 216649319 A B Controller

32 216694500 A B Clip,controller

42 216232700 A B Washer,flat ,1"OD x 0.531"ID

47 216629600 A B Screw,hex washer head ,10-16 x 0.500 ,tapping

55 # 218909901 A B Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad

85 216533500 - B Wire,ground

86 216036600 A B Screw,ph washer head ,8-32CA x 0.500 ,thread forming

* 5303212614 A B Clip,harness mount
