Frigidaire FFC18K1CW0 Manuale utente

CHEST FREEZER

Model number:

FFC18K1CW0

FACTORY PARTS CATALOG

FREEZER

WIRING DIAGRAM - # 216801000

OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794305

SERVICE DATA SHEET - # 216801000

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FFC18K1CW0 FFC18K1CW 134A white 115

MARKET

North America

Publication No.

5995385951

030217

-EN/SERVICE /MLR

365

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

02/03 2

Publication No FFC18K1CW0

5995385951

DOOR

# = Fast-moving Parts 3 02/03

* = Non-Illustrated Parts

FFC18K1CW0 Publication No.

5995385951

DOOR

POS. NO PART NO DESCRIPTION

1 216481301 Gasket-door,white

9 216893203 Panel-inner door,frzr

10 216141101 Plug button,white

11 216130019 Panel-lid,white

14 216822900 Switch,light/lamp ,ramp

15 216846400 Light Bulb/Lamp

16 216817600 Socket,light/lamp ,25 W

18 216140200 Handle,recessed ,white

27 5303212828 Clip,panel mtg

31 08009392 Gasket,white

34 5303296969 Shield,lid lamp

47 # 216898800 Harness-lid

* 5303925098 Insulation

02/03 4

Publication No FFC18K1CW0

5995385951

CABINET

# = Fast-moving Parts 5 02/03

* = Non-Illustrated Parts

FFC18K1CW0 Publication No.

5995385951

POS. NO PART NO DESCRIPTION

2 216269500 Adapter,drain hose

3 216502600 Plug,drain ,interior

4 216073900 Plug,drain ,exterior

6 216111100 Breaker

11 216110800 Breaker,chest end ,(2)

12A 216892800 Nameplate

18 216707200 Knob,temp control

21 # 216714600 Control-temperature

27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping

28 216035300 Hinge

30 216110700 Breaker,corners

59 216867300 Basket,upper ,(2)

62 131420300 Screw,cr truss head ,8-18AB x 0.750

75 216034301 Panel,access ,white

94 216140400 Lens,frost indicator ,blue

* 5303305324 Paint,touch-up ,white

CABINET

02/03 6

Publication No FFC18K1CW0

5995385951

SYSTEM

# = Fast-moving Parts 7 02/03

* = Non-Illustrated Parts

FFC18K1CW0 Publication No.

5995385951

SYSTEM

POS. NO PART NO DESCRIPTION

1 # 5303280307 Condenser

4 216634500 Drier-filter

5 216806900 Harness-main

22 216056400 Clip,compressor mtg ,SPRING

27 5308002681 Grommet,compressor

28 5303212615 Support,compressor

29 # 216784500 Compressor,w/o electricals

30 216649300 Controller-regulator LP

32 216649100 Clamp,elec cont mtg ,compressor

42 216232700 Washer,flat ,1"OD x 0.531"ID

43A 5303212614 Clip,harness mount

47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping

55 # 218909901 Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad

86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming

* 5303298960 Spacer-tube,0.237" ID
