fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

fi-71X0/fi-72X0 CONSUMABLE REPLACEMENT

AND CLEANING INSTRUCTIONS INSTRUCTIONS

CG00002-285801RevisionA

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Kit Contents

F1 Cleaner

Low VOC Qty 1 Cotton Swabs

Qty 1 100/pack

Lint Free

Cleaning Cloths

Qty 1 20/pack

Cleaning Paper

Qty 1 10/pack

Brake Roller

Qty 1

Pick Rollers

Qty 2

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

ConsumablesList

Thefollowing table showsthe specifications ofconsumables and their

standard replacement cycle. It is recommended that you stock extra

consumablesbefore theonesin thescanner reach theend of theirservice

life. The consumables must be replaced periodically. You can check the

number of scanned pages for the Brake roller unit and the Pick roller unit

byreferring toeach counteron thisscanner.

Description Qty Life Fujitsu P/N

Pick Roller 2 200,000 PA03670-0002

Brake Roller 1 200,000 PA03670-0001

Pick Roller

Brake Roller

Note: ReplacementCycles areestimatedguidelines establishedby

testingwithA4/Lettersizedwoodfree and woodbased 17 lbpaper. NCR

orCarbonless paperhaschemical compositionwhichdamages thepad

andthe pickroller. Cleaningof theconsumables willbe required more

frequentlyto avoid feedprobelms. Consumablelife willbereduced if

NCRor Carbonless paperisscanned.

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

CLEANING OF THE SCANNER

TheScannersAutomaticDocumentFeeder(ADF) shouldbecleaned at

leastevery 5000pages. This is verydependant onthe types ofpaper

beingscanned, whenscanning documents withtonner that hasnot fused

wellor have ink,the scanner mayrequire more frequentcleaning.

Open theADF by pressing

theADFOpenLeverand

pullingtheADF towardsthe

front of the scanner in the

directionof the arrowshow

in the drawing to the right.

ADF Open

Lever

Cleanthe Brake Rollers

(1) byremoving them from

thescanner and cleaning

with a lint free cloth

moistendwith F1cleaner.

Using the same lint free

cloth moistend with F1

cleanthe Feed Rollers(2),

EjectRollers(3), Glass(4)

andUltrasonicSensor(7).

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Clean the Pick Rollers(5) by

removingthemfromthe

scannerand cleaningwitha

lint free cloth moistend with

F1 cleaner. Using the same

lint free cloth moistend with

F1 clean the Glass(4),

PlasticRollers(6) and

UltrasonicSensor(7). Clean

thepaper pathof any loose

debris using a soft cloth or

vacuum.

Caution: When cleanning the paper path in the ADF avoid damaging the document

sensors shown below(1)

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

REPLACING CONSUMABLES

From the [start] menu, select [All Programs] ([Scanner Utility for

MicrosoftWindows]([SoftwareOperationPanel].

Fromthe SoftwareOperator Panel selectionson the leftselect [Device

Settings]

Click on the [Clear] button next to the Pick Roller or Brake Roller counter

to clear it to 0 once you have replaced them. This will start the count over

for the new pick roller or brake roller installed in the following steps.

Click the [OK] button to close the Software Operator Panel Dialoge box.

If this message appears you may be able to scan a bit longer but you

should replace consumables as soon as possible.

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Note:

Afterreplacement ofany consumable resetthe counter forthat

consumableby followingtheinstructions inyour Operator’s Guide.

Detailedinstructions can befoundunder the“Replacing Consumables”

section of the Operator’s Guide as well as at the begining of this section

ofthisfi-71x0/fi-72x0Consumable Replacement andCleaning

Instructions.

REPLACING THE PICK ROLLER

Removeall documentsfromtheADFpaperchute (feeder)

Remove theADF paper chute (feeder).

Hold both ends of theADF paper chute (feeder), then lift it in the direction

of arrow 1 and pull it out in the direction of arrow 2

Pull theADF release tab towards you and then open theADF

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Liftup theshaft indirection 1 (about5mm), andslide theshaft

indirection 2to pullout theleading endfrom theslot, thenlift

theshaft indirection 3to remove it.

Openthe sheetguide bylifting thetab

Rotatethe bushingon the shaftto releasethe pickshaft

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Remove the two Pick Rollers from the shaft one

at a time.

Pulloutthe pickroller fromtheshaft asyou liftthe

retainingclip.

Pullout the otherpick rollerfrom theshaftas

youliftthe retainingclip.

fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Attach the two new Pick Rollers onto the shaft one at a

time.

Insert the retaining clip of the pick roller into the slot

Insert the retaining clip of the other pick roller into the slot.

Re-install the pick shaft by inserting the left end into the slot, and

gradually lower the other end.
