Fujitsu MBA3073RC SERIES Manuale utente

C141-C013-01EN

MBA3073RC, MBA3147RC, MBA3300RC SERIES,

MBB2073RC, MBB2147RC SERIES,

MBC2036RC, MBC2073RC SERIES

DISK DRIVES

SERIAL ATTACHED SCSI INTERFACE

SPECIFICATIONS

FOR SAFE OPERATION

Handling of This Manual

This manual contains important information for using this product. Read thoroughly before using

the product. Use this product only after thoroughly reading and understanding especially the

section "Important Alert Items" in this manual. Keep this manual handy, and keep it carefully.

FUJITSU makes every effort to prevent users and bystanders from being injured or from suffering

damage to their property. Use the product according to this manual.

This product is designed and manufactured for use in standard applications such as office work,

personal devices and household appliances. This product is not intended for special uses (atomic

controls, aeronautic or space systems, mass transport vehicle operating controls, medical devices for

life support, or weapons firing controls) where particularly high reliability requirements exist,

where the pertinent levels of safety are not guaranteed, or where a failure or operational error could

threaten a life or cause a physical injury (hereafter referred to as "mission-critical" use). Customers

considering the use of these products for mission-critical applications must have safety-assurance

measures in place beforehand. Moreover, they are requested to consult our sales representative

before embarking on such specialized use.

First Edition February 2007

The contents of this manual may be revised without prior notice.

The contents of this manual shall not be disclosed in any way or reproduced in any media without

the express written permission of Fujitsu Limited.

C141-C013

Revision History

(1/1)

Edition Date Revised section (*1)

(Added/Deleted/Altered) Details

01 2007.02.28 — —

*1 Section(s) with asterisk (*) refer to the previous edition when those were deleted.

C141-C013

This page is intentionally left blank.

Preface

This manual explains concerning the hard disk drives with internal Serial Attached

SCSI (SAS) controller.

The purpose of this manual is to provide the specifications and functions of SAS

for use of these magnetic disk drives incorporated into user systems, and to present

the information necessary for creating host system software. This manual is written

for users who have a basic knowledge of hard disk drives and their use in computer

systems.

The composition of manuals related to these disk drives and the range of subjects

covered in this manual are shown in "Manual Organization," provided on a

subsequent page. Please use these other manuals along with this manual as

necessary.

The organization of this manual, related reference manual and conventions for alert

messages follow.

Overview of Manual

This manual consists of the following six chapters, glossary, abbreviation, and

index:

Chapter 1 SAS Interface

This chapter describes the topology, physical and electrical requirements, interface

protocol, and other operations of the interface.

Chapter 2 Command Processing

This chapter describes the basic logical specifications related to command

processing.

Chapter 3 Data Buffer Management

This chapter describes the data buffer configuration, data transfer processing

functions and cache operations.

Chapter 4 Command Specifications

This chapter describes detailed command specifications and how to use them.

Chapter 5 Parameter Data Format

This chapter describes the parameter data formats provided by the disk drives and

how to use them.

C141-C013 1

Preface

Chapter 6 Sense Data and Error Recovery Methods

This chapter describes the configuration and contents of sense data which report to

the host system when an error occurs, etc., key information necessary for error

recovery, recommended procedures for error recovery to be executed through host

system software and retry processing.

Chapter 7 Disk Media Management

This chapter describes the procedure for initializing the disk media, methods of

treating media defects and data recovery methods.

Glossary

The glossary explains technical terms which are necessary to the reader's

understanding when reading this manual.

Acronyms and Abbreviations

This list shows the full spelling of abbreviations used in this manual.

Index

2 C141-C013

Preface

CONVENTIONS USED IN THIS MANUAL

The model names of the disk drives covered by this manual differ depending

on their device types and capacity (*1). In addition, these disk drives are called

Hard Disk Drive (HDD), "drive" or "device" in this manual.

Note: Model Name

M BA 3 147 RC

Interface type

Formatted capacity [One gigabyte (GB) = one billion

bytes; accessible capacity will be less

and actual capacity depends on the

operating environment and

formatting.]

Disk size 3: 3.5 inch

2: 2.5 inch

Type BA: 3.5-inch, 15,000rpm

BB: 2.5-inch, 10,025rpm

BC: 2.5-inch, 15,000rpm

Decimal numbers are represented normally.

Hexadecimal numbers are represented as shown in the following examples:

X'17B9', 17B9h, 17B9H, or 17B9H.

Binary number is represented as "010", 010b.

An X is used to represent mode parameters that are ignored by the MODE

SELECT and MODE SELECT EXTENDED commands. An X is also used

to represent mode parameters reported by the MODE SELECT and MODE

SELECT EXTENDED commands and that vary depending on conditions at

the time.

C141-C013 3

Preface

Conventions for Alert Messages

This manual uses the following conventions to show the alert messages. An alert

message consists of an alert signal and alert statements. The alert signal consists of

an alert symbol and a signal word or just a signal word.

The following are the alert signals and their meanings:

This indicates a hazardous situation likely to result in

serious personal injury if the user does not perform

the procedure correctly.

This indicates a hazardous situation could result in

serious personal injury if the user does not perform

the procedure correctly.

This indicates a hazardous situation could result in

minor or moderate personal injury if the user does

not perform the procedure correctly. This alert signal

also indicates that damages to the product or other

property, may occur if the user does not perform the

product correctly.

This indicates information that could help the user

use the product more efficiently.

In the text, the alert signal is centered, followed below by the indented message. A

wider line space precedes and follows the alert message to show where the alert

message begins and ends. The following is an example:

(Example)

It is possible to use bit 7 and bit 6 of the control byte as an inherent

control field in future product specifications. It is recommended that

the INIT specify zero in this field.

Attention

Please forward any comments you may have regarding this manual.

To make this manual easier for users to understand, opinions from readers are

needed. Please write your opinions or requests on the Comment at the back of this

manual and forward it to the address described in the sheet.

4 C141-C013

Preface

MANUAL ORGANIZATION

Product Maintenance

Manual

1. General Description

2. Specifications

3. Data Format

4. Installation Requirements

5. Installation

6. Diagnostics and Maintenance

7. Error Analysis

Interface Specifications

(This Manual) 1. Serial Attached SCSI (SAS) Interface

2. Command Processing

3. Data Buffer Management

4. Command Specifications

5. Parameter Data Formats

6. Sense Data and Error Recovery

7. Disk Media Management

C141-C013 5

Preface

REFERENCED STANDARDS
