GarrettCom Magnum CSG14 Manuale utente

www GarrettCom com

Corporate Headquarters

GarrettCom, Inc.

47823 Westinghouse Drive

Fremont, CA 94539-7437

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

Email: [email protected]

Magnum CSG14 Gigabit Converter Switches

CSG14U

CSG14

Installation and User Guide

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

MagnumTM CSG14 Series Gigabit Converter Switch

Installation and User Guide

Part #: 84-00102Z Rev. F

Trademarks

GarrettCom is a registered trademark and Magnum, Dymec, DynaStar, Personal

Switch, Link-Loss-Learn, S-Ring, Convenient Switch and Converter Switch

are trademarks of GarrettCom, Inc.

Ethernet is a trademark of Xerox Corporation

NEBS is a trademark of Telcordia Technologies

UL is a registered trademark of Underwriters Laboratorie

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

Important: The Magnum CSG14 Series 10/100/1000 Mb/s Converter

Switches contain no user serviceable parts. Attempted service by unauthorized

personnel shall render all warranties null and void. If problems are

experienced with Magnum CSG14 10/100/1000 Mb/s Converter Switch

products, consult Section 5, Troubleshooting, of this User Guide.

be reproduced without prior written permission from GarrettCom, Inc.

Printed in the United States of America

GarrettCom, Inc. reserves the right to change specifications, performance characteristics

and/or model offerings without notice.

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

iii

www GarrettCom com

Federal Communications Commission

Radio Frequency Interference Statement

This equipment generates, uses and can radiate frequency energy and if not

installed and used properly, that is in strict accordance with the manufacturer's

instructions, may cause interference to radio communication. It has been tested and

found to comply with the limits for a Class A computing device in accordance with the

specifications in Subpart J of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause

interference, in which case the user, at his/her own expense, will be required to take

whatever measures may be required to correct the interference.

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

Electrical Safety requirements:

1. This product is to be installed Only in Restricted Access Areas

(Dedicated Equipment Rooms, Electrical Closets, or the like).

2. 48VDC products shall be installed with a readily accessible disconnect

device in the building installation supply circuit to the product.

3. This product shall be provided with a maximum 10A DC Listed fuse or

circuit breaker in the supply circuit when connected to a 48V

centralized source.

4. The external power supply for DC units shall be Listed, Direct Plug In

power unit, marked Class 2, or listed ITE Power Supply, marked LPS,

which has suitably rated output voltage (i.e. 24VDC or 48VDC) and suitable

rated output current.

5. Product does not contain user replaceable fuses. Any internal fuses can

ONLY be replaced by GarrettCom personnel through the RMA process.

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

Contacting GarrettCom, Inc

Please use the mailing address, phone and fax numbers and email address listed below:

GarrettCom, Inc.

47823 Westinghouse Drive

Fremont, CA 94539

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

Email: [email protected]

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

TABLE OF CONTENTS Page

1.0SPECIFICATIONS ............................................................................... 1

1.1Technical Specifications...................................................................... 1

1.2Summary of models and descriptions:............................................... 11

2.0INTRODUCTION ............................................................................... 16

2.1Inspecting the Package and the Product............................................. 16

2.2Product Description ........................................................................... 17

2.2.1CSG14H / CSG14P Product Description................................... 17

2.2.2CSG14UH / CSG14UP Product Description............................. 23

2.3Frame Buffering and Latency............................................................ 29

2.4Features and Benefits......................................................................... 32

2.5Applications for CSG14 Series Converter Switches.......................... 35

3.0INSTALLATION................................................................................. 44

3.1Locating the Converter Switch Unit ................................................. 44

3.2MC14-TRAY for Rack Mounting of CSG14 Series Switches .......... 46

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

vii

www GarrettCom com

3.3MC14-TR+PS9 and MC14-TR+PS9X2 for Rack Mounting Media

Converters.......................................................................................... 47

3.4 DIN-Rail mounting option................................................................. 49

3.5Power Requirements for CSG14 Series Switches.............................. 50

3.6Powering the CSG14 with 12V, 24V or –48VDC power input......... 51

3.7CSG14 Series, DC-powered, -48, 24 and 12VDC Installation........ 53

3.8Connecting Ethernet Media ............................................................... 55

3.8.1Connecting Twisted Pair (RJ-45, CAT 3, CAT 5 or CAT 6,

Unshielded or Shielded)............................................................ 56

3.8.2Connecting Fiber Optic LC-type, “Small Form factor (SFF)”... 57

3.8.3Connecting Fiber Optic SC-type, "Snap-In".............................. 58

3.8.4Installing LC-type SFP module,“Small Form Pluggable (SFP)”58

3.8.5Connecting Single-Mode Fiber Optic........................................ 58

3.8.6Power Budget Calculations for CSG14 Series, Fiber Media..... 59

3.8.7Connections to NICs which support Auto-Negotiation............. 61

4.0OPERATION....................................................................................... 62

4.1Triple-Speed Functionality, and Switching ....................................... 62

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

viii

www GarrettCom com

4.2Auto-cross (MDIX), Auto-negotiation and Speed-sensing................ 64

4.3Dual LEDs, Top-front and in End with ports .................................... 65

5.0TROUBLESHOOTING...................................................................... 66

5.1Before Calling for Assistance............................................................ 67

5.2When Calling for Assistance ............................................................. 68

5.3Return Material Authorization (RMA) Procedure............................. 70

5.4Shipping and Packaging Information................................................. 72

APPENDIX A: WARRANTY INFORMATION......................................... 73

Revisions

Rev F 04/09: revised Fiber Port connector spec. to “Single-mode” for “LX10” and

“LX25” on pages 12 and 13

Rev E 02/09: updated 100Base-FX SFP part nos. (page 15)

Rev D 12/08: added CSG14U model

Rev C 11/08: removed PCSG14P model,

added mounting hole location drawing (page 43)

Rev B 08/08: added PCSG14P (PoE version)

Rev A 05/08: Initial release of this user manual for CSG14 Converter Switches

CSG14 Series Gigabit Converter Switch Installation and User Guide (12/08)

www GarrettCom com

1.0 SPECIFICATIONS

1.1 Technical Specifications

Ports Performance

Data Rate: 10Mbps, 100Mbps, 1000Mbps

Network Standards

1000Mb: Ethernet IEEE 802.3ab and 802.3z

1000Base-T, -SX, -LX and -ZX

100Mb: Ethernet IEEE 802.3u, 100BASE-TX, 100BASE-FX

10 Mb: Ethernet IEEE 802.3, 10BASE-T

Auto-sensing for speed: IEEE 802.3z

Packet-Processing Between Domains

Filter and Forward Rate from 1000Mbps ports: 1,488,000 pps max.

Filter and Forward Rate from 100Mbps ports: 148,800 pps max.

Filtering and Forwarding Rate from 10 Mbps ports: 14,880 pps max.

Processing type: Store and Forward, non-blocking

Auto-learning: 1K-address table

Address buffer age-out time: 300 sec.
