GE GSH22JFX Manuale

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

†Water hook-up fits in back air clearance when calculating

installation depth.

If installed against a wall, allow clearance of 14-3/16" on freezer

side to remove bin.

Clearance required to remove fresh food full-size pan without

disassembling is 18-15/16".

Allow additional space for any necessary leveling adjustments.

"94 SxS Refer

A

Front View

Top View

G

D

C

F

BE

H

GSH22JFX

GE®22.1 Cu. Ft. Side-By-Side Refrigerator with Dispenser

Overall

Dimensions

Height to top of hinge (in.) A67-1/2

Height to top of case (in.) B66-1/2

Case depth without door (in.) C†28

Case depth less door handle (in.) D†31-1/4

Case depth with door handle (in.) E†33-5/8

Depth with fresh food door open 90° (in.) F†49-3/8

Width (in.) G33-1/2

Width with door open 90° inc. door handle (in.) H36

Air

Clearances

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Listed by

Underwriters

Laboratories

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Revised 5/09 310284

GSHC2IFX

GSHC5IFX

Features and Benefits

• ExternalTemperatureControlswithChildLock-Combinestheeaseof0-9temperature

settings, with the sophistication of electronic controls

• AdjustableHumidityVegetable/FruitCrispers-Provideidealstorageenvironmentforfruits

and vegetables

• AdjustableTemperatureDeliDrawer-Keepmeatsandcheesesdelicious

• SnackPan-Convenientlystoresre-wrappedmeats,cheesesandothersnacks

• AdjustableGallonDoorBins-Providesadditionalstoragespaceformilkandothergallon-

size containers

• AdjustableSpillproofGlassShelves-Raisededgeshelpcontainspillstomakecleanup

quick and easy

• GEWaterFiltrationSystem-Deliverscleangreat-tastingwaterandicethroughthe

LightTouch!Dispenser

•  F r o s t G u a r d ™Technology - Protects frozen items from freezer burn by monitoring freezer

door openings and defrosting only when needed

• AutoEnergySaver-Sensesfreezerandfreshdooropeningsandadjustsrefrigeration

operation cycles accordingly

• NeverClean™Condenser - Condenser coils are encased, so they don't require cleaning in

normal operating environments

• ModelGSH22JFXWW-Whiteonwhite

• ModelGSH22JFXCC-Bisqueonbisque

• ModelGSH22JFXBB-Blackonblack

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

GSH22JFX

GE®22.1 Cu. Ft. Side-By-Side Refrigerator with Dispenser

Specification Revised 5/09 310284

*
