Geberit DuoFresh Manuale utente
968.605.00.0
Geberit DuoFresh
User Manual
USER MANUAL
Plumbers, please ensure a copy of the installation
instructions is left with the end user for future reference.
Published 28/07/2021 Page 1 of 11
Page 2of 11
Geberit DuoFresh
Target group
This document is intended for all users of the Geberit DuoFresh
modules with automatic activation and insert for Geberit DuoFresh
stick.
Children and adults who are not familiar with its use should be given
appropriate instructions and may need to be supervised.
Intended use
The integrated odour extraction unit is designed to neutralise
unpleasant odours in toilets.
Operation, care and maintenance work may only be performed by the
operator or user as described in this user manual.
Use for any other purpose is deemed improper. Geberit accepts no
liability for the consequences of improper use.
Safety notes
•
Impurities in the filter could lead to contamination of the breathing
air. In order to preclude any health risks and ensure proper
functioning, the filter must be replaced annually.
•
This machine may be used by children as well as persons with
reduced physical, sensory or mental capabilities or a lack of
experience with and knowledge about the machine, provided that
they are supervised or taught how to use the machine safely and
that they understand the hazards that may result from this. Children
must not play with the device. Children must not carry out cleaning
or user maintenance without supervision (in accordance with
EN60335-1:2012).
•
Do not perform any changes or additional installations.
•
Repairs may only be carried out by a skilled person using original
spare parts and accessories.
User Manual
Page 3of 11
Geberit DuoFresh
EN
Product description
The odour extraction unit neutralises unpleasant odours in the toilet via a filter. Suitable
Geberit DuoFresh sticks can be inserted into the cistern via a drawer.
The Geberit DuoFresh module is equipped with user recognition and an orientation light.
The settings can be modified with the Geberit Home app.
The actuator plate featured in these instructions corresponds to the Sigma20 type and
also applies analogously for other compatible types.
Operation
Starting the odour extraction
unit
▶When a user approaches the toilet,
the orientation light lights up and the
odour extraction unit starts up.
The odour extraction unit shuts off
automatically after approx. 2minutes
(factory setting).
User Manual
Page 4of 11
Geberit DuoFresh
Modifying settings
The settings for the odour extraction unit and the
orientation light can be modified with the
GeberitHome app. The status of the odour
neutralisation filter is also shown.
The GeberitHomeapp is available free of charge
for Android and iOS smartphones in the
respective App Store.
Android: iOS:
In order to operate the product with the
GeberitHome app, a one-time pairing process
must be carried out to establish a connection with
the app.
To do this, open the actuator plate and read the
QR code with the app.
1Gently pull the actuator plate
forwards (1) and swivel it to the right
(2).
2Read the QR code with the app or
enter the printed four-digit number
(e.g. 1234).
For detailed Geberit Home
App operation, please scan
the QR code below:
User Manual
Page 5of 11
Geberit DuoFresh
EN
Inserting a Geberit DuoFresh
stick
Prerequisite
– The Geberit DuoFresh stick colours the
water blue. Only insert a new stick when
you notice a permanent decline in the
colouring effect.
One DuoFresh stick will last approximately
120 flushes, corresponding to a duration of
approximately 2 weeks.
Only use original Geberit DuoFresh
sticks. These can be ordered as
part of the DuoFresh Annual
Servicing Kit (product code:
1804984) from your local Reece
Bathroom stores.
1Gently pull the actuator plate
forwards (1) and swivel it to the right
(2).
✓ The odour extraction unit stops
automatically.
1804984
Geberit DuoFresh Annual Servicing Kit:
1. Geberit DuoFresh drawer and filter unit
2. Geberit DuoFresh stick (8) x 3 packs
User Manual
Page 6of 11
Geberit DuoFresh
2Pull out the drawer with the filter.
The film on the Geberit DuoFresh
stick is water-soluble and does not
need to be removed.
3Insert the Geberit DuoFresh stick into
the holder.
User Manual
Page 7of 11
Geberit DuoFresh
EN 4Push in the drawer until the holder
noticeably locks into place.
✓ The Geberit DuoFresh stick
detaches from the holder and
falls into the cistern.
5Swivel the actuator plate to the left
(1) and gently push it backwards (2)
until it noticeably locks into place.
Troubleshooting
Malfunction Cause Rectification
The LED behind the actuator
plate is flashing red. Filter spent
▶ Replace the filter. → See
"Replace the filter", page
8.
The device does not work at
all or partly incorrectly. Device failure
▶ Read the message in the
GeberitHome app.
▶ Contact a skilled person.
User Manual
Page 8of 11
Geberit DuoFresh
Maintenance
Replace the filter
Prerequisite
– The odour neutralisation effect has
weakened.
– The LED behind the actuator plate is
flashing red.
– Prompt in the Geberit Home app.
CAUTION
Possible health hazard
Impurities in the filter could lead to
contamination of the breathing air.
▶ Replace the filter annually.
1Gently pull the actuator plate
forwards (1) and swivel it to the right
(2).
✓ The odour extraction unit stops
automatically.
2Pull out the drawer with the filter.
3Dispose of the drawer with the filter
and have a new drawer ready.
1804984
Order the DuoFresh Annual
Servicing Kit (product code:
1804984) from your local Reece
Bathroom stores.
Geberit DuoFresh Annual Servicing Kit:
1. Geberit DuoFresh drawer and filter unit
2. Geberit DuoFresh stick (8) x 3 packs
User Manual
Page 9of 11
Geberit DuoFresh
EN
4Push in the drawer until the holder
noticeably locks into place.
5Confirm the filter replacement:
a) in the Geberit Home app
or
b) within one minute, swivel the
actuator plate to the left (1), then to
the right (2), then to the left again (3)
and gently push it backwards (4) until
it noticeably locks into place.
✓ The LED behind the actuator
plate goes out.
User Manual
Page 10 of 11
Geberit DuoFresh
Technical data and conformity
Technical data
Protection class III
Protection degree IPX4
Operating voltage 12 V DC
Power consumption 7 W
Power consumption on
standby ≤0.5W
Wireless technology Bluetooth® Low Energy1) Short-range device
Frequency range 2400–2483.5MHz 24.000–24.250GHz
Maximum output power 0dBm ≤ 10mW
1) The Bluetooth® brand and its logos are the property of Bluetooth SIG, Inc. and are under
licence by Geberit.
Power Supply Conformity
Hereby, Geberit Pty Ltd AU declares conformity of Geberit DuoFresh power supply unit in
compliance with AS/NZS 61558.16:2010+A1+A2+A3 and AS/NZS 61558.1:2008+A1+A2.
Please contact Geberit Pty Ltd on 1800 432 3748 or support.au@geberit.com should you
require a copy of the Conformity certificate.
Disposal
Disposal of old electrical and electronic equipment
In accordance with Directive 2012/19/EU(WEEE-Waste Electrical and Electronic Equipment)
manufacturers of electrical equipment are obliged to take back old equipment and to dispose
of it appropriately. The symbol indicates that the product cannot be disposed of with non-
recyclable waste. Old equipment should be returned directly to Geberit where it will be
disposed of appropriately. Addresses to which equipment can be returned can be requested
from the relevant Geberit sales company.
