Giada IB4-271 Manuale utente
Statement
The copyright of this manual belongs to Shenzhen JIEHE Technology Development Co., Ltd. (Giada,
JIEHE’s global brand) and all rights are reserved. The company reserves the right to change this
manual at any time without notification. Specifications here are for reference only, please take the
real product as standard.
Without official authorization of Giada, other companies or individuals may not copy, plagiarize,
translate or disseminate this manual for commercial purpose.
The information provided in this manual is accurate and reliable. The company does not take any
legal responsibility for the consequences of infringement use of this manual.
Safety Notice
• Read the user manual carefully before setting up the Giada product.
• Disconnect the power cord before installing the internal components
• Most electronic components are sensitive to static electrical charge, please wear a wrist-grounding
strap when installing the internal components.
• Don’t disconnect the power cord when the system is running to avoid damage to the sensitive
components by instantaneous surge voltage.
Contact Information
Shenzhen JIEHE Technology Development Co., Ltd.
Website: www.giadatech.com
Phone: +86-755-3330 0336
Email: support@giadatech.com
Address: 1~3/F, Block A, Tsinghua Information Harbor, North Section, Shenzhen Hi-tech
Park, Nanshan District, Shenzhen, China
- 3 -
Table of Contents
1. Product Introduction ..................................................................................... 6
1.1 Brief Introduction ....................................................................................... 6
1.2 Motherboard Picture .................................................................................. 6
1.3 Spec ............................................................................................................ 6
2. Hardware Usage Instruction ........................................................................ 8
2.1 Dimensions Chart ....................................................................................... 8
2.2 Interface Definition .................................................................................... 8
2.2.1 Board Jumper, Header And Interface Diagram ................................ 8
2.2.2 Board Jumper And Header Definition .............................................. 9
3. Accessories Installation Steps ..................................................................... 13
3.1 Memory Installation ..................................................................................13
3.2 WIFI/3G/4G (M.2) Installation ................................................................ 14
3.3 SSD (M.2) Installation ............................................................................. 15
3.4 SIM Card Installation ............................................................................... 16
4. Bios Setup ..................................................................................................... 17
4.1 Main (Standard CMOS setting) ............................................................... 20
4.2 Advanced (Advanced BIOS setup) .......................................................... 21
4.2.1 ACPI Setting ................................................................................... 21
4.2.2 CPU Configuration ......................................................................... 23
4.2.3 Trusted Computing ......................................................................... 25
- 4 -
4.2.4 Hardware Monitor .......................................................................... 26
4.2.5 IT8786 Super IO Configuration ..................................................... 30
4.2.6 OEM Configuration ....................................................................... 33
4.2.7 OEM ME Configuration ................................................................ 34
4.2.8 System Devices Configuration ....................................................... 35
4.2.9 WakeUp Configuration ................................................................... 38
4.2.10 F81866 Super IO Configuration ................................................... 39
4.2.11 Serial Port 1 Configuration ........................................................... 40
4.2.12 PC Health Status .......................................................................... 41
4.2.13 CPU Configuration ....................................................................... 41
4.2.14 CPU Configuration ....................................................................... 42
4.2.15 PPM Configuration ...................................................................... 43
4.2.16 IDE Configuration ........................................................................ 44
4.3 Security (set the administrator/user password) ........................................ 45
4.4 Boot Menu ............................................................................................... 46
4.5 Save & Exit .............................................................................................. 47
5. JAHC Introduction ..................................................................................... 48
5.1 How to set up Auto power on function .................................................... 48
5.2 JAHC software ......................................................................................... 51
5.2.1 JAHC software functions ............................................................... 51
- 5 -
5.2.2 JAHC software installation guide .................................................. 51
5.2.3 Startup & shutdown time setup ...................................................... 53
5.3 Watchdog API and instruction .................................................................. 55
- 6 -
1. Product Introduction
1.1 Brief Introduction
Giada IB4-271 Thin Mini-ITX motherboard adopts Intel®Elkhart Lake J6412 (quad-core) processor,
which has a long life cycle up to 7+ years life cycle. It is featured with HDMI +DP +LVDS display
outputs, 8 ×USB, 6 ×COM and dual LAN ports; The motherboard is a ideal choice for IOT
applications, like kiosk, smart locker, AIO and gaming machine etc.
1.2 Motherboard Picture
1.3 Spec
Processor
CPU
Intel®Celeron J6412
Frequency
2.00GHz (Up to 2.60GHz)
BIOS
AMI Source Code
Chipset
SOC
Memory
Type
Up to 32GB
Socket
2×SO-DIMM DDR4-3200Mhz
Graphics
GPU
Intel®UHD Graphics for 10th Gen Intel®Processors
Graphic Engine
Direct X, OpenGL, OpenCL, Intel®Quick Sync Video
Audio
Controller
Realtek ALC897
Network
Controller
2×Realtek RTL8111H®
Interface
2×RJ45
- 7 -
WiFi+BT
1×M.2(2230) for WiFi / BT module
Mobile Network
1×B-Key M.2 (3042) for 3G/4G module
1×SIM Slot
Storage
SATA
2×SATAIII
M.2
1×M-Key M.2(2280) for PCle SSD
JAHC
JAHC
Watchdog Timer / Auto Power On / RTC
External
I/O Interface
USB
2×USB 3.2 Gen.2, 2 ×USB 2.0
Audio
1×2-in-1 Headset ( MIC-IN, AUDIO-OUT)
Display Output
1×HDMI (Max.4096 ×2160@60Hz)
1×DP (Max.4096 ×2160@60Hz)
Ethernet Interface
2×RJ45
Internal
I/O Interface
USB Pin
2×USB3.2 Gen1, 2 ×USB2.0
LVDS Pin
1×30pin dual channel 24bit LVDS
eDP
1×20pin eDP colay with LVDS
J-HDMI
1×16pin J_HDMI colay with HDMI
Serial Port
4×RS232，2 x RS232/422/485
Audio
1×10pin FP_AUDIO, 1 x 4pin SPEAKER
GPIO
4×GPI, 4 ×GPO
F_Panel
1×10pin F_PANEL
Inverter
1×8pin INVERTER
Clear CMOS
1×3pin CLR_CMOS
Fan
1×4pin SYS_FAN, 1 ×4pin CPU_FAN
Power
1×4pin ATX PWR_IN, 2 x 4pin SATA_PWR
PCB
Dimension (W x D)
170mm x 170mm
Power
DC-IN
12V~24V
Operation
System
Windows/Linux
Win10(64bit) / Win11(64bit) / Linux Ubuntu(64bit)
Environment
Operating Temperature
0°C ~ 60°C (32 ~ 140°F)
-20°C ~ 75°C (-4 ~ 167°F)
Relative Humidity
5% ~95% @ 45°C (non-condensing)
- 8 -
2. Hardware Usage Instruction
2.1 Dimension Chart
2.2 Interface Definition
2.2.1 Board Jumper, Header And Interface Diagram
- 9 -
2.2.2 Board Jumper And Header Definition
No.
Jumper
/Header
Function
PIN Definition
1
F_AUDIO1
Front Audio
2
SPK_6W1
Speaker
3
SYS_FAN1
System Fan
4
CPU_FAN1
CPU Fan
5
HD1
Front HDMI
- 10 -
6
F_USB2_1
Front USB2.0
7
CLR_CMOS1
CMOS
8
J1
Front USB3.0
9
ESPI1
DEBUG Pin
10
LVDS1
LVDS Pin
