Giant XTC 29ER 1 - DATASHEET 2 Manuale utente

XTC 29er 1

Spec Features

— FOX 32 F29 100 FIT RL tapered 15QR fork w/ 100mm travel

— Shimano SLX/Deore XT 10-speed component group w/ hydraulic disc brakes

— Giant Contact handlebar, Connect stem & seatpost

*Seat angle is actual

**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube

***Standover height is based on the largest size tire that will ﬁt the bike, not necessarily the included size tire

frame

SIZES S,M,L,XL

COLOUR Black / Silver

FRAME ALUXX SL-grade aluminum

FORK FOX 32 F29 RL, tapered, 15QR,

100mm travel

SHOCK N/A

componentS

HANDLEBAR Giant Contact ﬂat 31.8mm

STEM Giant Connect

SEATPOST Giant Connect 30.9x375mm

SADDLE Giant Performance MTB

PEDALS Nylon “test ride” pedals

DriVetrain

SHIFTERS Shimano SLX

FRONT DERAILLEUR Shimano SLX

REAR DERAILLEUR Shimano Deore XT Shadow long cage

BRAKES Shimano M445 F:180mm / R:160mm

hydraulic disc

BRAKE LEVERS Shimano M505

CASSETTE Shimano HG81 11-36T 10SPD

CHAIN Shimano HG74

CRANKSET Shimano SLX 24/32/42T

BOTTOM BRACKET Shimano external

WHeeLS

RIMS Giant P-XC 29 32H

HUBS F:Giant Tracker 15QR / R:Shimano M529

SPOKES Stainless Steel 14g

TIRES Maxxis Aspen 29x2.1”

EXTRAS

Speciﬁcations and availability subject to change without notice.

Specifications

Actual

Frame Size Part

Number Head

Angle Seat

Angle* Toptube** Headtube Chainstay Wheelbase Standover

Height***

inches degrees degrees inches inches inches inches inches

S 16 2114000 71.0 73.0 22.4 3.5 17.3 41.8 28.5

M 18 2114001 71.5 72.5 23.4 3.9 17.3 42.4 29.6

L 20 2114002 71.5 72.5 24.2 3.9 17.3 43.2 30.5

XL 22 2114003 71.5 72.5 25.0 4.7 17.3 44.0 31.6

frame geometry

A B C D E F G H

$

OFF-road | PERFORMANCE | Competition/ XC

105
