Golden Baby Ambulo Manuale utente
Golden Baby
Ambulo
2 | P a g e
Ambulo
CONTENTS
INSTRUCTION MANUAL
SEAT AND BASSINET
Important Safety Information
Primary features
Opening the frame
Fitting and removing the rear wheels
Fitting and removing the front wheels
Operating the break
Operating the front wheels
Adjusting the shock absorber
Assembling the seat unit
Assembling the canopy
Assembling the hand rail
Adjusting the handle height
Adjusting the seat unit
Adjusting the bassinet
Using the safety harness
Folding the stroller/chassis
CARRY COT
Important Safety Information
Primary features
Assembling the carry cot
Fitting the carry cot
Operating the carry cot hood
Removing the carry cot
CAR SEAT
Fitting the car seat to the chassis
Removing the car seat from the chassis
Car seat options
ACCESSORIES
Rain cover
Mosquito net
Foot muff
Apron
GENERAL
Care and Maintenance
Warranty
Page
.....................................................................…...3
……………………………….……………………………………4
…………………………………………………………………..5
………..……………………………………5
…………………………………………….6
…………………………………………………………………6
…………………………………………………………7
……………………………………………………...7
……………………………………………………………8
……………………………………………………………..9
………………………………………………………….10
………………………………………………………10
…………………………………………………………….11
……………………………………………………………..12
………………………………………………………….13
………………………………………………………..14
……………………………………………………..15
…………………………………………………………………….16
………………………………………………………….17
………………………………………………………………..18
…………………………………………………….18
……………………………………………………………18
………………………………………………..19
………………………………………..20
…………………………………………………………………...20
…………………………….……………………………………………21
……………………………………………………………………….22
……………………………………………………………………………23
……..………………………………………………………………………...25
…………………………………………………………….26
…………………………………………………………………………….27
3 | P a g e
Ambulo
Important Safety Information
"Important – Keep these instructions for future reference
WARNING Never leave your child unattended
WARNING Ensure that all the locking devices are engaged before use
WARNING To avoid injury ensure that your child is kept away when
unfolding and folding this product
WARNING Do not let your child play with this product
WARNING Use a harness as soon as your child can sit unaided
WARNING This seat unit is not suitable for children under 6 months
WARNING Always use the restraint system
WARNING Check that the pram body or seat unit or car seat
attachment devices are correctly engaged before use
WARNING This product is not suitable for running or skating
This pram/stroller is intended for children from newborn (1 month) and up to
maximum weight 15.0kgs.
Adult assembly required. Never allow children to fold, assemble or
disassemble the pram/stroller.
Do not use your pram/stroller if any part is broken, torn or missing.
To avoid injury to fingers, take care when unfolding and folding the
frame.
To avoid injury, never attempt to remove or adjust the seat unit when a
child is occupying the seat.
Put the brake on whenever you park the pram/stroller.
Do not let children play unattended near the pram/stroller.
The pram/bassinet is only suitable for a child who cannot sit up unaided.
Do not add a mattress other than the Ambulo mattress provided with the
product.
Any load attached to the handle, affects the stability of the pram/stroller.
The maximum load for the seatback storage pockets is 1Kg. Maximum
weight for storage basket is 2.5Kg. The pram/stroller may become
unstable if any of the manufacturer’s recommended loads are
exceeded.
Do not inflate the rear wheels to more than 40PSI.
Never use this pram/stroller for more than 1 child simultaneously.
For car seats used in conjunction with a chassis, this vehicle does not
replace a cot or a bed. Should your child need to sleep, then it should
be placed in a suitable pram body, cot or bed.
Only replacement parts supplied or recommended by the
manufacturer/distributor shall be used.
4 | P a g e
Ambulo
Handle
Canopy Support
Bars
Handrail
Canopy Bases
Seat Unit
Shock Absorber
40 PSI Tyre
Wheel Hub
Adjusting Spring
Rod
Handrail release Button
Frame release locks
Handle Adjustment
Button
Velcro Straps
Bassinet
Frame
Rear Wheel
Front Wheel
Storage Basket
Hinge
Central Adapter
Release Button
Seat Adjustment
Button
Canopy Cover
6Primary Features
5 | P a g e
Ambulo
Opening the Frame
Open the frame clip on the strap.
Place your foot on the rear axle tube to stabilise the chassis as
you lift the handlebar.
Lift the handlebar until you hear an audible “click”. Confirm that
the frame is locked in the open position.
Close the red frame safety lock to avoid unexpected folding of
the chassis.
Fitting and Removing the Rear Wheels
Lift the brake to allow the wheel to be fitted.
Insert the rear wheel axle until you hear an audible “click” to
confirm that the wheel is locked into position. Repeat for the
second wheel.
Pull the wheel in the opposite direction to confirm that the wheel
has been fitted properly.
Red frame
Safety lock
Brake connecting lever
Frame Clip
6 | P a g e
Ambulo
Fitting and Removing the Front Wheels
Insert the front wheel axle until you hear an audible “click” to
confirm that the wheel is locked into position. Repeat for the
second wheel
Pull the wheel in the opposite direction to confirm that the
wheel has been fitted properly.
Operating the Brake
To engage the brake, firmly press down with your foot on the
brake connecting lever.
Check that the brake is fully engaged into the rear wheel before
letting go of the handle.
To release the brake, lift up the brake connecting lever with your
foot until the wheels move freely.
7 | P a g e
Ambulo
Operating the Front Wheels
The front wheels can be used in a swivel or fixed mode.
To switch from swivel to locked, Press down the swivel wheel
lock levers with the wheels pointing as illustrated below.
Lift the lever to return to the swivel-wheel position.
Adjusting the Shock Absorber
Press down on the adjustable spring rods with your thumbs while
your forefingers are lifting against the wheel cover.
Push the adjustable spring rods to the needed position.
1
2
3
Swivel position
Locked position
8 | P a g e
Ambulo
Assembling the Seat Unit
Place the frame and seat cover as illustrated below.
Unzip the zippers on each side.
Place the central adapters through the holes on the seat cover.
Close the 4 zippers
Press and secure the Velcro straps at each end.
Always secure the fasteners to the bassinet support bar.
Close the 3 clips under the bottom of the seat unit as pictured.
To fit the seat unit to the chassis: lower the central adapters into
the attachment devices and push down until it locks into position.
1
2
3
9 | P a g e
Ambulo
Assembling the Canopy
Distinguish the inner and outer sides of the canopy bases.
Install the canopy bases, as illustrated below.
Insert the 2 canopy supports bars through the canopy cover.
Insert the 2 canopy supports simultaneously to the canopy
bases.
Fix the canopy cover to the seat with the elastic loops as
illustrated.
Secure the back of the canopy cover over the top of the frame.
To avoid injury remove the two canopy bases from the stroller
when the canopy is not in use.
Outer Inner
10 | P a g e
Ambulo
Assembling the Hand Rail
Fit the handrail cover to the handrail.
Install the handrail into the handrail posts until you hear an
audible “click”.
Pull the hand rail in the opposite direction to confirm that it has
been fitted properly.
To release the handrail press the handrail release button as
illustrated below.
Adjusting the Handle Height
The handle height is adjustable to multiple positions.
To adjust the handle height, press-in and hold in the handle
adjustment buttons on the outside of the handle.
Rotate to the desired position.
To enable the stroller to stand independently when folded, put
the handle in the parking position before folding the chassis.
Parking
Position
