GoMax Electronics CV-511 Manuale utente

CV-511

HDMI to DVI & Audio Converter

User Manual

Made in Taiwan

Safety and Notice

The CV-511 HDMI to DVI & Audio Converter has been tested for conformity to safety regulations and

requirements, and has been certified for international use. However, like all electronic equipments, the CV-511

should be used with care. Please read and follow the safety instructions to protect yourself from possible

injury and to minimize the risk of damage to the unit.

Follow all instructions and warnings marked on this unit.

Do not attempt to service this unit yourself, except where explained in this manual.

Provide proper ventilation and air circulation and do not use near water.

Keep objects that might damage the device and assure that the placement of this unit is on a stable

surface.

Use only the power adapter and power cords and connection cables designed for this unit.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

Warning!

This device is served purely for conversion between video formats.

This device CANNOT convert the input/output video resolutions.

This handy device provides an easy and instant approach for converting digital HDMI to digital video

(DVI-D) and both digital audio (S/PDIF) and analog stereo audio. With this module, HDMI based devices such

as Blu-ray Disc players, PS3, DVD players, camcorders, or set-top boxes can readily connect to your PC LCD

monitor and PC speakers at lowest cost. This device also enables users to connect full digital video and audio

to DVI enabled monitor and S/PDIF equipped audio receiver and amplifier, and make the highest compatibility

to your home theater devices.

Features

Fully HDCP compliant

DVI video up to 165MHz

RCA S/PDIF audio input

Stereo analog audio output

Front panel LED indicators

Easy installation

Introduction

Specifications & Package Contents

Technical

CV-511

Role of usage

Digital-to-digital format converter

HDMI compliance

HDMI

DVI compliance

DVI 1.0

Video Bandwidth

Single-link 225MHz [6.75Gbps]

Video support

Up to 1080p60, WUXGA [1920x1200@60Hz], UXGA [1600x1200@60Hz]

Audio support

Stereo audio

Output TMDS signal

1.2 Volts [peak-to-peak]

Output DDC signal

5 Volts [peak-to-peak, TTL]

ESD protection

[1] Human body model —± 19kV [air-gap discharge] & ± 12kV [contact discharge]

[2] Core chipset —± 2kV

PCB stack-up

4-layer board [impedance control —differential 100; single 50]

Input

1x HDMI

Output

1x DVI

1x RCA digital audio

1x 3.5mm analog audio

HDMI connector

Type A [19-pin female]

DVI connector

DVI-I [29-pin female digital only]

RCA connector

Coaxial S/PDIF digital audio [PCM 48kHz]

3.5mm connector

Analog stereo audio

Control Switch

8-level rotary switch for audio & EDID settings

Mechanical

CV-511

Housing

Metal enclosure

Dimensions

[L x W x H]

Model

126 x 93 x 26mm [5"x3.7"x1.0"]

Package

270 x 175 x 80mm [10.6"x6.9"x3.1"]

Carton

450 x 370 x 300mm [1'6"x1'3"x11.8"]

Weight

Model

339g [12 oz]

Package

650g [1.4 lbs]

Fixedness

Wall-mounting case with screws

Power supply

Interlocking power jack to prevent power loose

Power consumption

3.5 Watts [max]

Operation temperature

0~40C [32~104F]

Storage temperature

-20~60C [-4~140F]

Relative humidity

20~90% RH [no condensation]

Package Contents

1x CV-511

1x 5V power supply unit

1x User Manual

Front Panel

1. S/PDIF: connect to S/PDIF digital stereo audio speaker

2. Stereo: connect to analog stereo audio speaker

3. DVI OUT: connect to digital DVI display

Rear Panel

4. HDMI IN: connect to an HDMI source device

5. STATUS: Status indicator

[Normal operation] −lights up means the HDMI device is connected

[EDID learning mode] −lights off means the start of EDID learning mode; flashes means the learning the

EDID from connected display; lights up means the completion of the EDID learning

6. MODE: 8-level rotary switch for audio and EDID settings

0 = Pair 1 of 7.1ch analog audio output 4 = Reserved

1 = Pair 2 of 7.1ch analog audio output 5 = Reserved

2 = Pair 3 of 7.1ch analog audio output 6 = Restore Default EDID

3 = Pair 4 of 7.1ch analog audio output 7 = Learn EDID from connected display

7. POWER: power indicator [light: power on; dim: power off]

8. +5V DC: connect to 5V interlocking power supply unit

Panel Descriptions

1. Connect your HDMI source device to the HDMI IN port.

2. Connect your DVI display or projector to the DVI-I OUT port.

3. Connect your S/PDIF AV receiver to the S/PDIF RCA port.

4. Connect your PC speaker to the Stereo 3.5mm earphone jack.

5. Power up the CV-511.

* S/PDIF format is dependent upon the embedded digital audio part in the input HDMI stream. The S/PDIF receiver

must be able to recognize the input S/PDIF format. This CV-511 only separates the digital audio in HDMI stream,

and bypasses this decoded audio to the output.

* The function of the rotary switch is reserved and please keep the rotary switch at 0.

1. Power up the CV-511. Connect DVI display to the DVI OUT.

2. Turn the rotary switch counterclockwise [] from 0 to 7.

3. The green LED will flash a few times to indicate the EDID is learned.

4. Turn the rotary switch clockwise [] from 7 to 0. DO NOT let the rotary switch arrow pass 6, which will

erase the just learned EDID and reset to default EDID.

1. Analog stereo audio output can merely support 2-channel audio. This version does NOT support

8-channel analog audio applications.

2. S/PDIF audio output supports main 2-channel audio output only.

Hardware Installation

Notice

EDID Learning

The SELLER warrants the CV-511 HDMI to DVI & Audio Converter to be free from defects in the material

and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this

product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or

replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized

modifications including static discharge and power surge. This warranty is offered by the SELLER for its

BUYER with direct transaction only. This warranty is void if the warranty seal on the metal housing is broken.

Unit that fails under conditions other than those covered will be repaired at the current price of parts and

labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment to the

BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss or

damage in transit. Under no circumstances will a unit be accepted without a return authorization number.

The warranty is in lieu of all other warranties expressed or implied, including without limitations, any

other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly

disclaimed.

Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible for

shipping charges to and from the SELLER. Cables and power adapters are limited to a 30 day warranty and

must be free from any markings, scratches, and neatly coiled.

The content of this manual has been carefully checked and is believed to be accurate. However, The

SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The SELLER will

NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or

omission in this manual, even if advised of the possibility of such damages. Also, the technical information

contained herein regarding the CV-511 features and specifications is subject to change without further notice.

Limited Warranty
