Introduction
This User Guide is written as general guide on how to set up the Grandstream phone model
GXP-2140 to work with PBXware 5.3.6.
Requirements
Identifying phone model
To start and successfully complete registration of your Grandstream phone you need to know
which phone model you will setup.
At the back of each Grandstream phone there are exact model information that you should
check. Although different phone models can have exactly the same requirements and
installation procedure, phone models can also have significantly different requirements and
installation procedure, so that ignorance of your own model may result in the inability to
successfully set up your phone.
Phone firmware
Make sure that your phone is loaded with appropriate firmware version, 1.0.11.3.
■
To find out the firmware version of your Grandstream phone model open a new browser
■
window and enter your phone IP address in order to access the phone web administration
interface login screen. Example: http://192.168.1.22.
Login to phone web administration interface with your username and password. Please note,
■
factory default login details are username: admin and password: admin.
Click on System Info link in the left hand navigation menu. Firmware version is shown under
■
the Software Version-Prog.
DHCP server
Fully configured and operational DHCP server.
PBXware version
In order to find out the PBXware version, please login to PBXware and navigate to Settings:
About. On the top of About page is a code similar to this one "PBXware Edition: Business,
Release: 5.3.6 (041373f), Running: 1.4.24-gc-75ee203", where "Release" denotes the exact
version of your PBXware.
Installation
This chapter describes how to install and connect the phone to the electrical power and data
network as well as how to apply factory settings.
The following topics are covered:
Power adapter
■
Power over Ethernet (PoE)
■
Factory settings
■
Power adapter
Connect the Network and Power
Connect the DC plug on the power adapter to the DC port on the phone and connect the other
■
end of the power adapter into an electrical power outlet.
Connect the ethernet cable between the Internet port on the phone and the network port on a
■
router or switch to access LAN.
NOTE: If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter.
Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.
Power over Ethernet (PoE)
Connect the Network (only)
Using a regular ethernet cable your phone can be powered from a Power over Ethernet (PoE)
compliant router or switch.
Connect the Ethernet cable between the Internet port on the phone and an available port on
■
the in-line power router or switch.
NOTE: If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter.
Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.
Find the phone IP address
Find out your Grandstream phone IP Address.
Press the Middle navigation key.
■
Go to Status->Network Status and the IP address will be displayed on the display.
■
Reset to factory settings
Reset to factory settings.
This step is not required for out-of-the-box phones, however, if the phone has been already used
then it is a must.
Press the Middle navigation key.
■
Go to System and navigate to the Factory Reset and press the Select button.
■
Confirm your action by pressing the Yes button.
■
Registering phone
This chapter describes how to register the phone using manual configuration or auto
provisioning.
The following topics are covered:
Manual configuration
■
Auto provisioning
■
Manual configuration
This chapter describes how to set UAD settings, create PBXware extension and register the
phone.
The following topics are covered:
UAD settings
■
Creating extension
■
Registering phone
■
UAD Settings
UAD settings
Login to PBXware web administration interface.
Open a new browser window and enter the IP address in order to access the PBXware web
■
administration login screen. Example: http://192.168.1.10
Login to PBXware with your e-mail address and password.
■
UAD settings
Navigate to Settings:UAD.
■
Make sure Grandstream UAD is enabled. To check the UAD status click on the edit icon
■
corresponding to your Grandstream phone.
Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
■
Click on the Save button to save changes.
■
Creating extension
Creating Extension
Add extension.
Navigate to Extensions. Click on Add Extension.
■
The standard options window will be shown below.
■
Select Grandstream phone model from the UAD select box.
■
Select Location: Local or Remote.
■
Local is for all extensions registered on the LAN and Remote is for all extensions
registered from remote networks, WAN, Internet etc.
Click on the Next step button.
■
Extension values.
Enter values into the required field text boxes.
REQUIRED FIELDS:
Name
■
Enter a name for the extension being created. Example: John Smith.
E-mail
■
Enter the e-mail address associated with this extension. This e-mail address will receive all
system notification messages. Example: [email protected].
Click on the Save button.
■
Registering phone
This chapter describes how to register Grandstream phone using Hostname or IP Address, or
DNS SRV.
The following topics are covered:
Hostname or IP Address
■
Registering your device
Line configuration from devices web interface.
To access the web interface of your Grandstream phone, first you must know it's IP address on
your network.
To find the IP address of your device please:
Press the Home button.
■
Go to Status and press the Select button.
■
Go to Network status and press the Select button.
■
IP address is displayed under IPv4: e.g. 192.168.8.198
■
NOTE: Depending on your Grandstream device and its firmware, web interface settings may
vary.
Once you have entered the IP address a log in menu will pop up, the user name is: admin and
■
the password: admin.
After you log in, under Accounts tab you should select Account 1 -> General Settings.
■
Enter your Extension name into the Account Name field.
■
Enter your server address into the SIP Server field.
■
Enter extension Username into the Authenticate ID field.
■
Enter extension Secret into the Authenticate Password field.
■
Press Save and Apply button to preserve changes. Your phone should register after couple of
■
seconds, if not, please reboot your phone.
If everything is done as above described, you should have successfully registered your phone
■
to PBXware. Dial *123 to verify registration.
Auto provisioning
This chapter describes how to set UAD settings, create PBXware extension and register the
phone using DHCP or Static IP address.
The following topics are covered:
UAD settings
■
Creating extension
■
Registering phone
■
UAD Settings
UAD settings
Login to PBXware web administration interface
Open a new browser window and enter the IP address in order to access the PBXware web
■
administration login screen. Example: http://192.168.1.10.
Login to PBXware with your e-mail address and password.
■
UAD settings
Navigate to Settings:UAD.
■
Make sure Grandstream UAD is enabled. To check the UAD status click on the edit icon
■
corresponding to your Grandstream phone.
Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
■
Click on the Save button to save changes.
■
Creating Extension
Creating Extension
Add Extension
Navigate to Extensions. Click on Add Extension.
■
The standard options window will be shown below.
■
Select Grandstream phone model from the UAD select box.
■
Select Location: Local or Remote.
■
Local is for all extensions registered on the LAN and Remote is for all extensions
registered from remote networks, WAN, Internet etc.
Click on the Next step button.
■
Extension values
Enter values into the required field text boxes.
REQUIRED FIELDS:
Name
■
Enter a name for the extension being created. Example: John Smith.
E-mail
■
Enter the e-mail address associated with this extension. This e-mail address will receive all
system notification messages. Example: [email protected]
Auto Provisioning
■
Set to Yes.
MAC Address
■
Enter Grandstream phone MAC address. Example: 0004F2FF1536. MAC address can be
found at the back of the phone.
Registering phone
This chapter describes how to register Grandstream phone using DHCP, TFTP, HTTP &
HTTPS or DNS SRV.
The following topics are covered:
DHCP
■
TFTP or HTTP & HTTPS
■
DNS SRV
■
DHCP
Configure DHCP
Make sure your DHCP router is configured to use option 66 to automatically instruct phones
■
with the URL for auto provisioning. For more information refer to your router documentation
or contact your network administrator.
Phone first boot or user initiated reboot
Auto provisioning process will start during phone first boot or after reboot process has been
■
initiated by user. DHCP server will instruct the phone where from to pickup appropriate
configuration file. If everything is done as above described, you should have successfully
registered your phone to PBXware. Dial *123 to verify registration.
TFTP or HTTP & HTTPS
Open a new browser window and enter your phone IP address, e.g. http://192.168.1.22.
■
Enter username and password and press Confirm button. NOTE: Factory default login
■
details are username: admin and password: admin.
Click on Maintenance at the top navigation menu.
■
Click on Upgrade and Provisioning link in the left hand navigation menu.
■
Scroll down to Config section.
■
Choose what server type you intend to use in the Config Upgrade via field: HTTP, HTTPS
■
and Trivial FTP. NOTE: Our recommendation is to use the HTTP.
If the Server Type is HTTP or HTTPS enter Hostname or IP Address, followed
then by /prov.
Example for Hostname using HTTP: abc.bicomsystems.com/prov
Example for Hostname using HTTPS: abc.bicomsystems.com/prov
Example for IP Address using HTTP: 192.168.1.10/prov
Example for IP Address USING HTTPS: 192.168.1.10/prov
Enter Auto Provisioning username and password into Config HTTP/HTTPS User Name
■
and Config HTTP/HTTPS Password fields.
If you choose to use server type TFTP enter Hostname or IP Address
Example for Hostname: voip.bicomsystems.com
Example for IP Address: 192.168.1.10
Click on Save and Apply button.
■
Click on Reboot button on the top navigation menu.
■
You will have to wait couple of seconds for the configuration to be updated. NOTE: Do not
■
power off your phone.
Auto provisioning process will start during phone reboot process, phone will pickup
■
appropriate configuration file from PBXware. If everything is done as above described, you
should have successfully registered your phone to PBXware. Dial *123 to verify registration.
DNS SRV
DNS SRV
This chapter describes how to use a DNS SRV record which specifies the location of the
PBXware.
Altri manuali per GXP2140
7
Indice
Altri manuali Grandstream Networks Telefono IP
Grandstream Networks
Grandstream Networks GXP Series Manuale utente
Grandstream Networks
Grandstream Networks GXP2130 Series Manuale utente
Grandstream Networks
Grandstream Networks GXP1625 Guida
Grandstream Networks
Grandstream Networks Grandstream GXP-2010 Manuale utente
Grandstream Networks
Grandstream Networks GRP2614 Manuale utente
Grandstream Networks
Grandstream Networks GXP2135 Manuale utente
Grandstream Networks
Grandstream Networks GHP620 Manuale utente
Grandstream Networks
Grandstream Networks GXP21 Series Manuale utente
Grandstream Networks
Grandstream Networks WP822 Manuale utente
Grandstream Networks
Grandstream Networks Grandstream GXP-2000 Manuale utente
Grandstream Networks
Grandstream Networks GRP260X Series Manuale di istruzioni
Grandstream Networks
Grandstream Networks GXP1620 Manuale utente
Grandstream Networks
Grandstream Networks GRP2604 Manuale utente
Grandstream Networks
Grandstream Networks GXV-3140 Manuale utente
Grandstream Networks
Grandstream Networks GXP1610 Manuale di istruzioni
Grandstream Networks
Grandstream Networks GRP2613 Manuale utente
Grandstream Networks
Grandstream Networks GXV3275 Manuale utente
Grandstream Networks
Grandstream Networks GXV3275 Manuale utente
Grandstream Networks
Grandstream Networks GXP2130 Series Manuale di istruzioni
Grandstream Networks
Grandstream Networks GXP2130 Series Manuale di istruzioni
