Gymstick PRO20.0 Manuale utente
PRO20.0 TREADMILL
USER MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future
reference. The specications of this product may vary from this photo, subject to change without notice.
2PRO20.0 TREADMILL
BEFORE YOU BEGIN
Thank you for choosing the Gymstick PRO20.0 Treadmill. We take great pride in producing this
quality product and hope it will provide many hours of eective exercise to make you feel better,
look better and enjoy life to its fullest.
TABLE OF CONTENT
1. SAFETY INSTRUCTIONS...................................................................................................3
2. EXPLODED DRAWING....................................................................................................... 4
3. PARTS LIST.........................................................................................................................5
4. ASSEMBLY INSTRUCTIONS ............................................................................................8
5. MOVING THE TREADMILL................................................................................................. 14
6. CONSOLE INSTRUCTIONS............................................................................................... 15
7. TROUBLESHOOT............................................................................................................... 29
8. PROGRAM SPEED TABLE................................................................................................. 31
9. IMPORTANT ELECTRICAL INFORMATION....................................................................... 33
10. HOW TO USE......................................................................................................................34
11. MAINTENANCE AND CARE............................................................................................... 34
12. LUBRICATING THE TREADMILL....................................................................................... 36
13. IMPLIED WARRANTY......................................................................................................... 37
READ AND FOLLOW THE SAFETY INSTRUCTIONS. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN RESULT IN SERIOUS INJURY.
!
NOTIFICATION!
3PRO20.0 TREADMILL
!
WARNING!
SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following safety instructions when using
this equipment: Read all instructions before using this equipment.
• Never leave the treadmill unattended. Unplug the unit from the power outlet when it is not in use.
• Do not allow children or those unfamiliar with its operation on or near the treadmill. Do not leave children or
persons with reduced physical or mental capabilities unsupervised around the treadmill.
• Please wear proper clothes and shoes when using this equipment; do not wear clothes that might catch
any part of the equipment.
• If you feel any chest pains, nausea, dizziness, or short of breath, you should stop exercising immediately
and consult your physician before continuing.
• Keep children and pets away from the equipment. This machine is designed for adults only.
• Only one person should be on the equipment while in use.
• Please make sure all parts are not damaged and xed well before use.
• Never operate the unit if it is damaged, if it is not working properly
• This equipment should be placed on a at surface when using. Using a mat or other covering material on
the ground is recommended. The minimum free space required for safe operation is 0,5 meter.
• Never block the air openings on the hood while operating the treadmill. Never drop or insert objects into
any opening.
• Use the treadmill only for its intended purpose as described in this manual.
• If the power cord of the machine is damaged, it must be replaced. Do not use the machine until the power
cord has been changed and properly attached.
• Do not use the equipment outdoors.
• This appliance is designed for use with ~220 - ~240 Volt rated voltage.
• The maximum weight capacity for this product is 160kgs.
BEFORE BEGINNING THIS OR ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN FIRST.
THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH
PRE-EXISTING HEALTH PROBLEMS.
4PRO20.0 TREADMILL
EXPLODED DRAWING
43
42
44
5PRO20.0 TREADMILL
PARTS LIST
Item Description Specication QTY
1 base frame 1
2 Incline motor frame 1
3 upright post left 1
4 upright post right 1
5 console frame 1
6 screen frame 1
7 motor base 1
8hand pulse frame left (PVC coated) 1
9hand pulse frame right (PVC coated) 1
10 xed base t25×120×60(zinc plating-white) 2
11 front roller Φ150×Φ85×Φ25×715 1
12 rear roller Φ85×Φ25×638×705 1
13 running board 1410×680×25 1
14 running belt 3460×580×t3.2 tyre pattern 1
15 motor belt 270J10 1
16 motor A.C 3.0HP 1
17 Incline motor 1
18 inverter 1
19 cylinder cushion pad φ30×30×M8×8 4
20 cushion pad with base 80×54×40(red) 4
21 aluminium side rail 128×49×1400 2
22 rubber pad of side rail 100×8×700 4
23 motor cover 810×595×68 1
24 Front cover of motor cover 810×114×192 1
25 hand pulse set cylinder length 133(hand pulse
bracket included) 2
26 upright post cover left 1
27 upright post cover right 1
28 Rear cover 855×163×195 1
29 Rear cover accessory left 78×34×155 1
30 Rear cover accessory right 78×34×155 1
Item Description Specication QTY
31 foot pad Φ74×86×M12 2
32 PU hand bar left 1
33 PU hand bar right 1
6PRO20.0 TREADMILL
PARTS LIST
Item Description Specication QTY
34 console upper housing 924×403×117 1
35 console lower housing 926×377×129 1
36 fan mounting board 404×28×57 1
37 console mounting seat 432×208×227 1
38 TFT panel 588×22×360 1
39 display back cover 586×82×359 1
40 console back cover 5550EA/408×123×316 1
41 power connected base
250V/10A/red L-60/black L-150/
yellow green L-320 1
42 fuse seat with wire FP-ZHY-8(6.35×30)/15A 1
43 switch XW604（20A）1
44 power cord 3×1.5mm2×2000 1
45 Powder metallurgical sheath Φ35×Φ30×Φ20×27 2
46 wheel φ78×φ12.2×t23 4
47 safety key press piece 83.5×42.7×33.2 1
48 round bushing 2
49 hexagon lock nut M12 3
50 at washer Φ12 3
51 allen c.k.s half thread screw M12×80×20 2
52 allen c.k.s half thread screw M12×70×20 1
53 allen c.k.s half thread screw M10×40×20 1
54 allen cylinder full thread screw M8×75 3
55 allen cylinder full thread screw M8×25 8
56 allen cylinder full thread screw M10×35 4
57 allen cylinder full thread screw M8×80 8
58 allen cylinder full thread screw M8×10 8
59 allen c.k.s full thread screw M8×20 12
60 allen cylinder full thread screw M8×15 4
Item Description Specication QTY
61 allen cylinder full thread screw M8×55 2
62 at washer Φ8 16
63 spring washer Φ10 4
64 at washer Φ10 8
7PRO20.0 TREADMILL
PARTS LIST
Item Description Specication QTY
65 hexagon lock nut M10 4
66 safety key mounting board 106×54×24 1
67 safety key plug piece 60.5×42×12 1
68 compressed spring φ11.8×φ0.8×24 1
69 Connected wire (earth) L-150mm
70 incline quick switch 32×25×52 1
71 speed quick switch 32×25×52 1
72 philips c.k.s full thread screw M5×15(steel nail) 2
73 philips c.k.s self-tapping screw ST4×20 8
74 philips c.k.s self-tapping screw ST4×16 72
75 philips c.k.s full thread screw M4×16(steel nail) 24
76 philips self-drilling full thread screw M3×28 4
77 quick switch wire L-700mm 2
78 communication wire 5552EA/L-900mm 1
79 communication wire 5552EA/L-1200mm 1
80 communication wire 5552EA/L-800mm 1
81 power connection wire L-800mm/1.5mm2/ red 1
82 power connection wire L-800mm/1.5mm2/black 1
83 wire (earth) L-200mm/1.5mm2 3
84 serrated lock washers Φ5 6
85 lter 10A(F7252) 1
86 magnet ring φ35×φ22×t15.0 1
87 power connection wire L-450mm/1.5mm2/black 1
88 power connection wire L-450mm/1.5mm2/red
89 Power board
L-150mm/1.5mm2/6.3# terminal /
Ф6 terminal 1
8PRO20.0 TREADMILL
WARNING: Use extreme caution when assembling this treadmill. Failure to do so could result in
injury.
NOTE: Each step number in the assembly instructions tells you what you will be doing. Read and
understand all instructions thoroughly before assembling the treadmill.
UNPACK AND VERIFY THE CONTENTS OF THE BOX:
●Lift up and remove the box that surrounds the Treadmill.
●Check the following items are present. If any of the parts are missing, contact with the dealer.
Platform frame
Upright posts Console rear cover
Left upright post cover Right upright post cover
Console frame
LED-panel
ASSEMBLY INSTRUCTIONS
UNPACKING AND ASSEMBLY
PACKAGE CONTENTS
9PRO20.0 TREADMILL
User manual
Rear cover
Running board
Rear roller
Silicone oil
Motor
Side rail
Motor belt Incline motor
Hardware bag
Motor cover
Running belt
Front roller
说明书
M8X65
M8X65
M8X65
M8X65
M8X15
ASSEMBLY INSTRUCTIONS
PACKAGE CONTENTS
MAIN PARTS
10PRO20.0 TREADMILL
59
70
69
44
45
57
29
30
42
37
24
25
27
27
27
27
27
27
27
27
19
19
67
54
47
48
36
36
21
36
36
21
20
50
5
61
27
27
27
27
27
27
27
27
27
27
27
27
27
27
49
60
44
2
1
3
4
6
8
7
7
14
13
11
11
12
12
15
15
15 32
16
16
17
17
17
17
18
18
19
31
75
31
31
75
31
21
21
23
23
23
23
23
23
23
23
26 26
26 26
67
37
24 37
37
24 37
24
24
25
25
25
25
25
25
25
25
24
24
28
28
28
27
27
32
32
32
32
33
33
34
34
35
34
35
35
35
38
38
39
39
39
40
40 41
41
46
51 53
53
52
56
56
58
62
62
63
64
66
66
68
68
68
68
71
72
55
55
9
10
19
22
22
28
10
10
10
73
73
73
73
75
75
34
34
34
76
77
27
27
27
27
65
78
80
27
79
24
24
27
27
32
48
32
32
32
32 32 32
32
32
32
32
32
32
32
47
54
86
89
87 88
28
91
92
93
90
94
1817 26
49
28
28
28
9695
81
25
74
74
82
83
84
85
65
65
65
65
65
65
T-shaped wrench L-shaped spanner Cross open wrench
Philips C.K.S self-tapping screw
(ST4*15) 10 pcs
Allen C.K.S. half thread screw
(M8*20) 8pcs
Philips C.K.S full thread screw
(ST4*16) 4pcs
Allen socket full thread screw
(M8*80) 8pcs
ASSEMBLY INSTRUCTIONS
HARDWARE BAG
