Haier XQG50-RC1000TXB Guida rapida

Operational Manual

Haier

Automatic Drum Washing Machine

Model: XQG50-RC800TXBS

XQG50-RC600TXBS

XQG50-RC1000TXB

Patent No.: 196.000.017.00

• Please read this manual

carefully before use

• Keep this manual in a safe

place.

TableofContents

BeforeUse

Washing Machine Diagram ..… Inside front cover

Matters Needing Attention ……………... 1-3

Installation ……………………………….. 4

Control Panel …………………………..… 7

Operational Functions ……………………. 8

DuringUse

Operational Programming Guide ………… 9

Preparation ……………………………… 10

Washing Methods ……………………….. 11

Hints for Saving Energy ………………… 12

Maintenance

Maintenance …………………………….. 13

Troubleshooting ……..…………………. 14

Electric Circuit Diagram ………………… 15

Specifications ..………………… Back cover

Washing Machine Diagram

Detergent distribution drawer Top

Operational buttons Programming knob

Door Door button

Porthole Wash temperature knob

Powercable Anti-vibrationUsteel

Spare earth terminal Drainage hose clip

Back plate screw (×3) Packing bolt (×3)

Drainage hose Back plate

Safety Signs

For your safety, any

instructions in this

manual with this

“Warning” sign shall

be strictly followed.

For your safety and

to prevent damages to

the washing machine,

any instructions in

this manual with this

“Stop” sign shall be

strictly followed.

Matters Needing Attention

Safety

1. A separate earthed socket is required

for the power supply. The socket

should be reachable by the power

cable of the machine.

2. Hold the plug and not the electric

cable when unplugging the washing

machine.

3. Fuses in the power circuit should be

rated for 15A. Refer to a washing

machine technician or a Haier

designated service point for power

cable replacement.

4. Do not touch or use the washing

machine bare-footed or when the

hands or feet are wet.

5. Do not use flammable detergent or

dry cleaning agent; do not use

flammable spray in close vicinity to

the washing machine; do not remove

or insert the plug in the presence of

flammable gas.

6. The door of the washing machine

will become hot during the heating

process. Avoid contact with the door

during the heating process. For

safety, keep children away from the

washing machine.

7. Keep children away from the packing materials after unpacked.

Matters Needing Attention

8. The washing machine should not be

installed outdoors or in a damp place. In

the event of water leakage or splashes

allow the machine to dry naturally.

9. Do not place the washing machine

directly on a carpet, or close to a wall

or furniture.

10. Keep away from heat sources and

direct sunlight to prevent plastic and

rubber components from aging.

11. During installation, ensure that the

electric cable is not trapped by the

washing machine and avoid damage to

the electric cable.

During Use

1. Before use, check the discharge hose, the

tap and the joints for possible problems

from water pressure fluctuations. If joints

are loose or there is leak, turn off the tap

and repair. Do not use the washing

machine until the hoses are properly

fixed.

2. After turning the power off, turn the

programming knob clockwise to select a

washing mode.

Matters Needing Attention

3. Do not place heavy, heating source or

wet articles on the top of the washing

machine.

4. Do not hot wash foam rubber or

sponge-like materials.

5. Before washing, do up zippers,

buttons and clothes straps and put

small articles, such as socks, laces or bras,

into a washing bag or a pillow.

Steel wires in bras

will pop out during

washing; never wash

bras containing steel

wires.

6. Bleaching powder should be put into

the designated box.

7. Do not open the detergent

distribution drawer during the wash

cycle.

8. The door is fitted with a self-lock

device and will not open until 2~3

minutes after the washing machine

stops. Do not force the door open. Do

not open the door if water level can

reach the porthole.

9. After washing, turn off the tap to

prevent leakage; unplug the washing

machine and wipe clean the lower

part of the porthole.

10. Keep the door slightly open when the

washing machine is not in use to

prevent the formation of odors; do

not cover the washing machine with

plastic cover so that inside dampness

cannot be kept in.

Installation

As shown in Fig. 1, remove all the

packing materials (including the foam

base).

Fig.1

Check attachments and materials with reference to the Packing List, as

shown in Fig. 2.

Name

Qty

Model

Service

manual

User

istr

car

Quality

certificate

Reminding

card

Guarantee

car

anne

Friendly

reminding

car

Inlet hose

ssembla

Drainage

hose holde

Earth cable

Anti-splash

Distribution

box

XQG50-

RC800T

XBS

1 1 1 1 1 1 1 1 1 1 3 1

XQG50-

RC600T

XBS

1 1 1 1 1 1 1 1 1 1 3 1

XQG50-

RC1000T

1 1 1 1 1 1 1 1 1 1 3 1

1)Drainage hose

holder

2) Quality

certificate

3)Guarantee card

4)User registry card

5)Spanner

6)Operational

manual

7)Reminding card

8)Anti-splash

plastic plug

9)Friendly

Reminding card

10) Distribution

box

11) Inlet hose

assemblage

12) Earth cable

(Fig. 2)

Dismantle the packing bolts as shown in Fig. 3.

The packing bolts are designed for clamping anti-vibration

components inside of the washing machine during the

transportation process. Before use:

1. Remove the back plate;

2. Remove the three packing bolts on the back plate and take

out the rubber hose;

3. Reinstall the back plate;

4. Fill the holes left by the packing bolts with plastic plugs.

(Attention: The packing bolts and rubber hose should be kept in a

safe place for later use)

(Fig. 3)

 Adjusting the washing machine

There are adjustable feet under the bottom of the washing

machine. Before use, the washing machine should be adjusted, as

shown in Fig. 4, so that it is level.

(Fig. 4)

Joining the inlet hose to the washing machine

1. Connect the nut on the inlet hose to the connector on the water valve.

2. Tighten the nut to secure the hose

nut

connector

Drainage hose

The height of the drainage outlet must be 80cm ~ 100 cm. To prevent the drainage hose from

dropping off, fix it to the drainage hose clip at the back of the washing machine.

Use the drainage holder to keep the end of the drainage hose retained and prevent the outflow of

water. It is recommended that the length of the drainage hose not be increased; if an increased length

hose is required, please consult a serviceman. The additional hose should be no more than 250

cm (overextended hoses could lead to siphonage). Note: The drainage hose should not be submerged

in water and should be securely fixed and leak-free.

Connecting to the power supply

Before connecting to the power supply, check:

The socket is adequate for the maximum power of the washing machine (For safety, fuses in the

power circuit should be rated for no less than 15A).

The voltage should meet the requirement.

The power outlet should be capable of accepting the washing machine plug.

The washing machine must be earthed before use.

If the power socket is earthed, no need to use the spare earth cable.

If the power socket is not earthed, use the spare earth cable. Connect one end of the earth cable to

the terminal at the back of the washing machine, and make sure another end is earthed properly.

Caution: Never connect the earth cable to water pipes or heating pipes.

Control panel

<W1>

Programming (after the power is cut)

Intense -- Cotton fabrics Normal -- Chemical fiber fabrics Delicate -- Woolen fabrics

1 Pre-wash 5 Soften A Standard wash ·Anti-crease soaking I Standard wash IV Spinning

2 Standard wash 6 Spinning B Quick wash E Spinning II Rinse V Drain

3 Quick wash ·Finish C Rinse ·Finish III Soften ·Finish

4Rinse DSoften ·Anti-cease soaking

D: Super delicate E: Half load F: Without spinning G: Power

I: The door can only be opened 3 minutes after the power is turned off or the operation is finished

Programming (after the power is cut)

Intense -- Cotton fabrics Normal -- Chemical fiber fabrics Delicate -- Woolen fabrics

1 Pre-wash 5 Soften A Standard wash ·Anti-crease soaking I Standard wash IV Spinning

2 Standard wash 6 Spinning B Quick wash E Spinning II Rinse V Drain

3 Quick wash ·Finish C Rinse ·Finish III Soften ·Finish

4Rinse DSoften ·Anti-cease soaking

D: Super delicate E: Half load F: Without Spinning G: Power

I: The door can only be opened 3 minutes after the power is turned off or the operation is finished

<W2>

Programming (after the power is cut)

Intense -- Cotton fabrics Normal -- Chemical fiber fabrics Delicate -- Woolen fabrics

1 Pre-wash 5 Rinse A Standard wash E Soften I Standard wash IV Spinning

2 Standard wash 6 Soften B Quick wash ·Anti-crease soaking II Rinse V Drain

3 Quick wash 7 Spinning C Super quick wash F Spinning III Soften ·Finish

4 Super quick wash ·Finish D Rinse ·Finish ·Anti-cease soaking

K: No soaking J: Speed E: Half load G: Power

I: The door can only be opened 3 minutes after the power is turned off or the operation is finished

Operational Functions

A Wash programming knob

By turning the knob clockwise, the required program can be selected

(Refer to Operational Programming Guide).

Caution: Turn off the power before setting a program; turn the program knob

clockwise; never turn it counterclockwise.

B Wash temperature knob

By turning the knob clockwise, the required temperature can be selected.

Temperatures between 30℃-90℃or 30℃-60℃can be selected.

(Refer to the programming guide).

Cold wash is selected when the knob is set at “*”.

C Swing-type detergent distribution drawer

There are instructions on the handle of the distribution drawer. Swing out the drawer,

three compartments can be seen.

Compartment 1: Pre-washing detergent

Compartment 2: Detergent for standard wash – super quick wash

Compartment 3: Softening agent, conditioning agent, perfume, etc

Besides, there is a separate compartment 4 for bleaching agent. When bleaching, put

compartment 4 into compartment 1, as shown in Fig (a). Take the compartment out from

compartment 1 when the pre-washing program is chosen.

D Super-delicate wash

This function only works during the chemical fiber fabric wash. When soft fabrics (for

example, silk) are to be washed, select the normal wash mode, press down this button, the

water level will be raised to protect the soft fabrics.

Operational Functions

E Half load (Economical wash)

Pressing this button will reduce the consumption of water in the washing process. It

is recommended that this program be used when doing a small laundry load. Do not

forget to reduce the amount of detergent used.

F Without spinning

Press this button down, the machine will run without spinning but drain. Use this function

for chemical fiber and woolen clothes wash.

G Power button

Press the button to switch on the washing machine; press again to switch it off

H Power light

The light illuminates indicating that power is on.

I Door button

Press this button to open the door. Remember the door can only be opened when the

machine stops working or 2-3 minutes after the finish of washing program.

J Speed setting button

When this button is pressed, the spinning speed will be reduced. Under intense and

normal wash modes, the speed will reduce from 1000 r/min to 600 r/min.

K Non-soaking button

For chemical fiber and woolen fabrics, press this button and the washing machine will

automatically skip over “▲” to execute the next program. Press the button again, the

washing machine will stop at “▲” to activate the anti-crease soaking function for

chemical fiber and woolen fabrics.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Haier Rondella

Haier

Haier XQS60-78H Manuale utente

Haier

Haier HWM15-0501 Manuale

Haier

Haier HVS1200 Manuale utente

Haier

Haier HW85-B1486NZP Manuale utente

Haier

Haier HW90-B14636 Manuale utente

Haier

Haier HW90-BP14959S6 Manuale utente

Haier

Haier HW-D1060TVE Manuale utente

Haier

Haier HWM105-826S6 Manuale utente

Haier

Haier HWF5300AW Istruzioni per il montaggio

Haier

Haier HWD-C1200TXVE-U Manuale utente

Haier

Haier HWM1480KFL Manuale utente

Haier

Haier HNS1250TVE Guida rapida

Haier

Haier HW07-CP1439N Manuale utente

Haier

Haier HW100-B14266A Manuale utente

Haier

Haier HW100-BP14959S6 Manuale utente

Haier

Haier AWT-70LI Manuale utente

Haier

Haier HW-F1481 ME Manuale utente

Haier

Haier WM-1270TVE Manuale utente

Haier

Haier LMD3123PBEB0 Manuale utente

Haier

Haier HLT364XXQ - Genesis Washer Manuale utente

Haier

Haier XQB60-68 Manuale utente

Haier

Haier HBS800 Manuale utente

Haier

Haier JW-PK60A Manuale utente

Haier

Haier HMS1260TVE Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
