InstructionManual

HI145-00 • HI145-01

HI145-20 • HI145-30

Rugged Thermometers with

T-shaped Handle and Cal-Check®

IST145-R2 06/05

SPECIFICATIONS

HI145-00 / -20 HI145-01 / -30

°C °F

Range

-50.0 to 220°C -58.0 to 428°F

Resolution

0.1°C(-50.0 to199.9°C) 0.1°F(-58.8 to 199.9°F)

1°C(200 to 220°C) 1°F (200 to 428°F)

Accuracy

±0.3°C (-20 to 90°C) ±0.6°F (-4 to 194°F)

±0.4% FS (outside) ±0.4% FS (outside)

Typical EMC

±0.3°C ±0.5°F

Deviation

Probe

stainless steel

HI145-00/HI145-01 125 mm x dia 5 mm

HI145-20/HI145-30 300 mm x dia 5 mm

Battery Type

1 x 1.5V AAA

Battery Life

approx. 10,000 hours

of continuous use

Auto-off

after 8 minutes of non-use

Environment

-10 to 50°C (14 to 122°F); RH 95%

Dimensions / Weight

HI145-00/HI145-01 92x165x38 mm / 65 g

HI145-20/HI145-30 92x340x38 mm / 80 g

Warranty

All Hanna Instruments meters are warranted for two years against defects in work-

manship and materials when used for their intended purpose and maintained according

to instructions. This warranty is limited to repair or replacement free of charge.

Damages due to accident, misuse, tampering or lack of prescribed maintenance are

not covered. If service is required, contact the dealer from whom you purchased the

instrument. If under warranty, report the model number, date of purchase, serial

number and the nature of the failure. If the repair is not covered by the warranty, you

will be notified of the charges incurred. If the instrument is to be returned to Hanna

Instruments, first obtain a Returned Goods Authorization number from the Customer

Service department and then send it with shipping costs prepaid. When shipping any

instrument, make sure it is properly packaged for complete protection.

Recommendations for Users

Before using this product, make sure that it is entirely suitable for the environment in

which it is used. Operation of this instrument in residential areas could cause inter-

ference to radio and TV equipment. Any variation introduced by the user to the

supplied equipment may degrade the instrument's EMC performance. To avoid elec-

trical shocks, do not use this instrument when voltage at the measurement surface

exceeds 24 Vac or 60 Vdc. To avoid damage or burns, do not perform any measure-

ment in microwave ovens.

The HI145 thermometer is the ideal solution for

temperature monitoring of semi-solids, such as fro-

zen foods, as well as applications, such as in food

preparation and during cooking.

The HI 145 series is equipped with the exclusive

Cal-Check®feature. When teh instrument is turned

on, it performs a self check of its calibration status

and displyas it on the LCD.

HI145-00 (°C) and HI145-01 (°F) are equipped with

a 125 mm (5”) long AISI 316 stainless steel probe.

It has a conic sharp tip which provides fast re-

sponse and improved accuracy over the entire range.

HI145-20 (°C) and HI145-30 (°F) are supplied with

a 300mm (12”) long stainless steel probe and are

ideal for monitoring hot liquids in cooking applica-

tions, such as deep frying and soup preparation.

OPERATION

• Turn the HI145 on. The “CAL” message on the

LCD indicates that the instrument is performing

an automatic calibration check. If the test is suc-

cessful, the LCD will display “-0-”. If the calibra-

tion check fails and the meter requires re-calibra-

tion, the LCD will display “ERR”.

After performing the calibration check, the instru-

ment will automatically enter the normal mea-

surement mode.

• Insert the probe into the sample to be measured.

Thanks to the special probe shape, the insertion

even into semi-solid samples is very easy.

• Wait for a few seconds for the display to stabilize.

• To freeze the display, press the HOLD button. A

blinking M appears on the right side of the LCD to

indicate that reading has been memorized. Press

either button to return to the normal mode.

• After use, switch the instrument off, or the meter

automatically turns off after 8 minutes of non-use.

•Variations in readings or fading display can

indicate a low battery level.

FACTORY CALIBRATION

If the meter needs re-calibration, contact your deal-

er or the nearest Hanna service center.

It is recommended to recalibrate the thermometer

once a year.

BATTERY REPLACEMENT

When the HI145 cannot be switched

on or the display fades, unscrew the

two screws to access the battery com-

partment and replace the 1.5V AAA

battery, while paying attention to its

polarity.

Battery should only be replaced in a

safe area using a 1.5V AAA alkaline

battery.

PROTECTIVE CAP

The thermometer is supplied with a

protective cap, which can also be

used to hold the thermometer on the

side of a vessel.
