Replace the release film
5
Follow the Ultraflow guide to complete the device binding and
pre-processing, and send the job to the printer for printing.
In the idle status, gently pull the resin bottle up along the track
and press the suspension button on the side of the printer, then
release the bottle so that it is stuck in suspension. When the resin
no longer drips naturally from the bottle, remove the bottle along
the rail and press the suspension button again to return it to the
original state.
When printing finished, open the hood and unlock the build
platform to take it out.
If you need to recover residual resin from the parts, hang the build
platform on the main axis at an angle as shown until the resin no
longer drips heavily.
After removing the platform, follow the instructions for the
post-processing like washing, removing parts and supports, and
post-curing etc.
STEP 7
STEP 6
STEP 5
STEP 8
STEP 1
Take out the liquid & temperature sensor and install it in the resin
tank as shown below. Make sure that the sensor is magnetically
attracted to the resin tank, and the convex part at the end is
inserted into the specified position, then you can shake it gently to
make sure it is fitted well.
Take out the build platform in the package and keep the locking
wrench raised, then install the build platform along the slide. Inset
it to the bottom, lock down wrench and close the hood.
Fully shaken the bottle and open it, then unscrew the cap as shown.
Insert the resin bottle downward along the slot into the printer, and
lift the top cover of the printer if using a 2L resin bottle.
Insert the resin bottle until you get tactile feedback and the display
shows that the resin bottle is inserted.
Keep the locking wrench raised
1
Twist the cap
counterclockwise
1
Install the build platform along the slide
2
Lock down the wrench
3Close the hood
4
CAUTION: Once the resin bottle is inserted into the printer,
the resin will flow into the resin tank, please make sure the
resin inserted is correct.
Resin tank and Release Film Spare Module are shown in the picture：
Replacement steps
Release Film Spare Module
Insert the resin bottle
downward along the slot
into the printer
2
1 2
Keep the platform unlocked, install the
platform diagonally as shown in the picture to
the end and wait for the resin inside the
model to flow out naturally
Lifting the locking handle and remove the
build platform with parts slightly
Resin Tank
