Installation GREYHOUND Switch

Release

04/2016

Technical support

https://hirschmann-support.belden.eu.com

User Manual

Installation

GREYHOUND Switch - GRS1042/GRS1142

GREYHOUND Power Supply Unit - GPS1/GPS2/GPS3

GREYHOUND Media Module - GMM20/30/32/40/42

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 1805 141538

GREYHOUND Switch

Installation GREYHOUND Switch

Release

04/2016 3

Contents

Safety instructions 5

About this Manual 12

Legend 12

1 Description 13

1.1 General device description 13

1.2 Device name and product code 15

1.2.1 Basic device 15

1.2.2 Power supply units 17

1.2.3 Media modules 18

1.3 Device views 20

1.3.1 GRS1042 20

1.3.2 GRS1142 21

1.3.3 Power supply units 22

1.3.4 Media modules 23

1.4 Power supply 25

1.5 Signal contact 26

1.6 Ethernet ports 27

1.6.1 1/2.5 Gbit/s F/O port 27

1.6.2 100/1000 Mbit/s F/O port 27

1.6.3 100 Mbit/s F/O port 27

1.6.4 10/100/1000 Mbit/s twisted pair port 28

1.6.5 Support of PoE(+) 28

1.6.6 Out-of-band management port 29

1.7 Pin assignments 29

1.8 Display elements 30

1.8.1 Device state 30

1.8.2 Port state 32

1.8.3 Media module status 34

1.9 Management interfaces 36

1.9.1 V.24 interface (external management) 36

1.9.2 USB interface 37

1.9.3 SD card interface 38

2 Installation 39

2.1 Checking the package contents 39

2.2 Installing the SD card (optional) 39

4Installation GREYHOUND Switch

Release

04/2016

2.3 Mounting the cover panel and the power supply unit

(optional) 40

2.3.1 Mounting the cover panel 40

2.3.2 Mounting the power supply unit 40

2.4 Mounting a media module (optional) 41

2.5 Installing and grounding the device 42

2.6 Connecting the terminal blocks 46

2.6.1 Supply voltage 46

2.6.2 Signal contact 49

2.7 Installing an SFP transceiver (optional) 50

2.8 Operating the device 51

2.9 Connecting data cables 51

2.10 Filling out the inscription label 51

3 Making basic settings 52

4 Monitoring the ambient air temperature 53

5 Maintenance and service 54

6Disassembly 55

6.1 Removing a power supply unit 55

6.2 Removing a media module 56

6.3 Removing an SFP transceiver 56

6.4 Removing the device 57

7 Technical data 58

7.1 General technical data 58

7.1.1 Basic device 58

7.1.2 Power supply units 59

7.1.3 Media modules 61

7.2 Dimension drawings 62

7.2.1 Basic device 62

7.2.2 Power supply units 63

7.2.3 Media modules 64

A Further Support 75

Installation GREYHOUND Switch

Release

04/2016 5

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning the device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

6Installation GREYHOUND Switch

Release

04/2016

Correct usage

Only use the device for those purposes specified in the catalog and in the

technical description. Only operate the device with external devices and

components that are recommended and permitted by the manufacturer.

The proper and safe operation of this product depends on proper handling

during transport, proper storage, assembly and installation, and

conscientious operation and maintenance procedures.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Supply voltage

The supply voltage is electrically isolated from the housing.

Every time you connect the electrical conductors, make sure that the

following requirements are met:

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device

(e.g., a switch or a plug). This disconnecting device is clearly

identified. So in the case of an emergency, it is clear which

disconnecting device belongs to which power supply cable.

The electrical wires are voltage-free.

The ground screw on the back of the device is connected to the

protective conductor.

Supply with AC voltage:

A fuse is located in the outer conductor of the power supply.

The neutral conductor is on ground potential at both voltage inputs.

Otherwise, a fuse is also located in the neutral conductor.

Regarding the properties of this fuse:

See “General technical data” on page 58.

Supply with DC voltage:

A fuse suitable for DC voltage is located in the plus conductor of the

power supply.

The minus conductor is on ground potential. Otherwise, a fuse is

also located in the minus conductor.

Regarding the properties of this fuse:

See “General technical data” on page 58.

Supply with DC voltage: the fuse is suitable for a DC voltage.

If the neutral conductor (AC) or the negative conductor (DC) is not

grounded: there is a fuse in each of the two wires.

Supply with AC voltage:

The wire diameter of the power supply cable is at least 0.75 mm²

(North America: AWG18) on the supply voltage input.

Installation GREYHOUND Switch

Release

04/2016 7

Supply with DC voltage:

The wire diameter of the power supply cable is at least 1 mm²

(North America: AWG16) on the supply voltage input.

The cross-section of the protective conductor is the same size as

or bigger than the cross-section of the power supply cables.

The cables used are permitted for the temperature range of the

application case.

Relevant for North America:

For use in Class 2 circuits, the copper wire conforms to class 1,

60/75 °C or 75 °C.

Verify that the electrical installation meets locally or nationally

applicable safety regulations.

Use undamaged parts.

Internal fuses are triggered only in the case of a detected error in the

device. In case of damage or malfunction of the device, turn off the

supply voltage and return the device to the plant for inspection.

Only switch on the device when the housing is closed.

First connect the ground screw on the back of the device with the

protective conductor before you set up the other connections. When

removing the connections, you remove the protective conductor last.

For supply voltage connections with protective conductor connection:

First connect the protective conductor before connecting the wires for

the supply voltage.

If your device comprises a 2nd supply voltage connection of this type:

First connect the protective conductor before connecting the wires for

the supply voltages.

Shielded ground

The shielded ground wire of the twisted pairs cables is connected to the

front panel as a conductor.

Beware of possible short circuits when connecting a cable section with

conductive shield braiding.

WARNING

ELECTRIC SHOCK

Start connecting the electrical wires only if all the above safety

requirements are fulfilled.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8Installation GREYHOUND Switch

Release

04/2016

ESD Guidelines

The modules are equipped with electrostatically sensitive components.

These can be destroyed, or their life cycles reduced, by the effects of an

electrical field or by a charge equalization if the connections are touched.

You will find information about electrostatically endangered assemblies in

DIN EN 61340-5-1 (2007-08) and DIN EN 61340-5-2 (2007-08).

Device casing

WARNING

ELECTRIC SHOCK

Never insert sharp objects (small screwdrivers, wires, etc.) into the inside of

the device.

Never insert sharp objects (small screwdrivers, wires, etc.) into the

connection terminals for electric conductors, and do not touch the terminals.

Install this device solely in a switch cabinet or in an operating site with

restricted access, to which maintenance staff have exclusive access.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

WARNING

FIRE HAZARD

Install the device in a fire protected shell if you are mounting it vertically.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

Installation GREYHOUND Switch

Release

04/2016 9

Only technicians authorized by the manufacturer are permitted to open

the casing.

Keep the ventilation slits free to ensure good air circulation.

Make sure there is at least 3.94 inches (10 cm) of space in front of the

ventilation slits of the housing.

Do not touch the housing during operation or shortly after switching off

the device. Hot surfaces can cause injury.

Mount the device horizontally in a cabinet or vertically on a flat surface.

Operating the device as a table unit is inadmissible.

See “Installing and grounding the device” on page 42.

Operating the device in the maximum surrounding air temperature and

stacking devices: When installing the device, make sure there is at

least one free rack space (approx. 5 cm) above the device, because

heat is discharged via the housing of the device.

If you are operating the device in a 19" switch cabinet: install

sliding/mounting rails for supporting the weight of the device.

Operating conditions

Operate the device at the specified ambient temperature (temperature of

the ambient air at a distance of 2 inches (5 cm) from the device) and at

the specified relative humidity exclusively.

When you are selecting the installation location, make sure you

observe the climatic threshold values specified in the technical data.

Use the device in an environment with a maximum pollution degree

that complies with the specifications in the technical data.

10 Installation GREYHOUND Switch

Release

04/2016

CE marking

The labeled devices comply with the regulations contained in the following

European directive(s):

In accordance with the above-named EU directive(s), the EU conformity

declaration will be at the disposal of the relevant authorities at the

following address:

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 1805 141538

The product can be used in the industrial sector.

Interference immunity: EN 61000-6-2

Emitted interference: EN 55022

Reliability: EN 60950-1

Warning! This is a class A device. This device can cause interference in

living areas, and in this case the operator may be required to take

appropriate measures.

Note: The assembly guidelines provided in these instructions must be

strictly adhered to in order to observe the EMC threshold values.

LED or laser components

LED or LASER components according to IEC 60825-1 (2014):

CLASS 1 LASER PRODUCT

CLASS 1 LED PRODUCT

Device variant Directive

All variants 2011/65/EU (RoHS)

Directive of the European Parliament and of the Council on the

restriction of the use of certain hazardous substances in

electrical and electronic equipment.

All variants 2014/30/EU

Directive of the European Parliament and the council for

standardizing the regulations of member states with regard to

electromagnetic compatibility.

Only for device variants

featuring supply voltage with

characteristic value H:

2014/35/EU

Directive of the European Parliament and the council for

standardizing the regulations of member states with regard to

electrical equipment for use within specific voltage limits.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Hirschmann Interruttore

Hirschmann

Hirschmann ETHERNET IP67 Istruzioni per l'uso e l'installazione

Hirschmann

Hirschmann MSM20 Manuale utente

Hirschmann

Hirschmann SPIDER 8TX-PRO Manuale utente

Hirschmann

Hirschmann RS20-0800B Manuale utente

Hirschmann

Hirschmann PowerLION-24TP Manuale utente

Hirschmann

Hirschmann PowerMICE Manuale utente

Hirschmann

Hirschmann BATOne Manuale utente

Hirschmann

Hirschmann CS30 Manuale utente

Hirschmann

Hirschmann PowerMICE MS4128 Manuale utente

Hirschmann

Hirschmann OCTOPUS OS20 Manuale utente

Hirschmann

Hirschmann LION-GIGA-1SX Manuale utente

Hirschmann

Hirschmann RS20 series Manuale utente

Hirschmann

Hirschmann GREYHOUND GRS1020 Manuale utente

Hirschmann

Hirschmann GECKO 4TX Manuale utente

Hirschmann

Hirschmann RS20 series Manuale utente

Hirschmann

Hirschmann SPIDER PL Manuale utente

Hirschmann

Hirschmann OCTOPUS 8M Series Manuale utente

Hirschmann

Hirschmann RS20 series Manuale utente

Hirschmann

Hirschmann RS20 series Manuale utente

Hirschmann

Hirschmann MSP30 Manuale utente

Hirschmann

Hirschmann RSPE 30 Manuale utente

Hirschmann

Hirschmann MACH 4000 Series Manuale utente

Hirschmann

Hirschmann PAT TRS 05 / PATB3 Guida utente

Hirschmann

Hirschmann MSM20 Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
