POWER TOOLS

TECHNICAL DATA

AND

SERVICE MANUAL

TABLE SAW

C 10RA2

SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT

LIST No. E929 Sep. 1999

MODEL

C 10RA2

--- 35 ---

Assembly Diagram for C 10RA2

--- 36 ---

Assembly Diagram for C 10RA2

--- 37 ---

PARTS

C 10RA2

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

1 318-086 BLADE GUARD ASS’Y 1 INCLUD.2-25

2 314-474 NUT CHUCK M6 1

3 314-479 BLADE GUARD 1

4 314-476 SELF-LOCKING RING 2

5 949-644 BOLT M6X40 (10 PCS.) 1

6 314-477 ARM 1

7 314-478 RIVET 2

8 318-088 BOLT M6X110 1

9 949-455 SPRING WASHER M6 (10 PCS.) 2

10 949-432 BOLT WASHER M6 (10 PCS.) 2

11 318-089 BOLT M6X90 1

12 314-483 GUARD BRACKET 1

13 949-556 NUT M6 (10 PCS.) 2

14 318-090 CUSHION 1

15 314-480 BUSHING 2

16 949-613 BOLT M6X16 (10 PCS.) 2

17 949-455 SPRING WASHER M6 (10 PCS.) 2

18 973-361 WASHER 2

19 314-476 SELF-LOCKING RING 2

20 314-444 KICK BACK PAWL 2

21 314-445 BUSHING 2

22 949-870 ROLL PIN D4X22 (10 PCS.) 1

23 314-447 SPRING 1

24 318-092 SPREADER 1

25 314-446 ROLL PIN 1

26 318-093 RIP FENCE ASS’Y 1 INCLUD.27-57,161

27 318-094 TAPPING SCREW D5X25 1

28 314-555 SEGMENT GEAR 1

29 318-095 REAR CLAMP 1

30 318-096 SPRING PIN 1

31 318-097 SLIDER (REAR) 1

32 318-098 HEX. NUT M4 2

33 318-133 PAN HD. SCREW M5X25 1

34 318-100 COUNTER HD. SCREW M4X20 2

35 318-101 SUPPORT 1

36 314-537 COMPRESSION SPRING 57L 1

37 318-102 FLAT WASHER 5/16"X5/8" 1

38 318-103 E-RING 1

39 318-104 LOCKING ROD 1

40 949-755 HEX. SOCKET HD. BOLT M6X16 (10 PCS.) 4

41 317-627 FLAT WASHER 1/4"X5/8" 4

42 318-105 PARALLEL BRACKET 1

43 317-567 ROUND WASHER HD. SCREW M5X8 1

44 318-106 NEEDLE POINTER 1

45 318-107 COUNTER HD. SCREW M4X12 4

46 318-108 WIDTH BODY 1

47 949-237 MACHINE SCREW M5X12 (10 PCS.) 1

48 949-431 BOLT WASHER M5 (10 PCS.) 1

49 318-096 SPRING PIN 1

50 318-111 SLIDER (FRONT) 2

51 318-098 HEX. NUT M4 4

: ALTERNATIVE PARTS

----

--- 38 ---

PARTS

C 10RA2

: ALTERNATIVE PARTS

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

52 318-113 CLAMPER 1

53 318-114 RUBBER BUSHING 1

54 318-115 ECCENTRIC SHAFT 1

55 949-558 NUT M8 (10 PCS.) 1

56 318-116 CLAMP BOLT 1

57 318-117 GRIP 1

58 314-484 TABLE INSERT FOR SAW BLADE 1

59 949-235 MACHINE SCREW M5X8 (10 PCS.) 2

60 949-342 FLAT HD. SCREW M6X25 (10 PCS.) 4

61 314-486 SEAL LOCK SCREW M6X20 1

62 318-118 MACHINE SCREW (W/WASHERS) M6X20 6

63 318-119 EXTENSION WING (LEFT) 1

64 318-120 SCALE (LEFT) 1

65 318-121 SCALE (CENTER) 1

66 314-490 SEAL LOCK SCREW M6X10 1

67 318-122 TABLE 1

68 318-123 RAIL 2

69 318-124 SIDE COVER (RIGHT) 2

70 318-125 SCALE (RIGHT) 1

71 318-126 EXTENSION WING (RIGHT) 1

72 318-127 SIDE COVER (LEFT) 2

73 318-128 HEX. SOCKET HD. CAP BOLT M6X35 16

74 314-512 BEVEL GEAR (A) 1

75 314-513 SLIDE PLATE 2

76 314-514 SLIDE BRACKET 1

77 949-455 SPRING WASHER M6 (10 PCS.) 4

78 949-803 BOLT M6X35 (10 PCS.) 4

79 315-042 MITER GAUGE ASS’Y 1 INCLUD.80-86

80 314-505 CLAMP HANDLE (B) 1

81 314-506 FLAT WASHER M6.4 1

82 314-507 MITER GAUGE 1

83 949-234 MACHINE SCREW M5X6 (10 PCS.) 1

84 314-509 ANGLE POINTER 1

85 314-510 PIN 1

86 314-511 SHEET BAR 1

87 967-469 HEX. SOCKET SET SCREW M6X6 4

88 314-516 FLAT WASHER M8X14.3 1

89 314-517 BEVEL GEAR (B) 1

90 314-518 SCREW BAR 1

91 314-519 NUT CHUCK M8 1

92 314-520 BODY 1

93 314-521 FLAT WASHER M6.4X12.7 1

94 314-522 SPECIAL NUT CHUCK M6 1

95 314-523 GUARD 1

96 949-455 SPRING WASHER M6 (10 PCS.) 1

97 949-255 MACHINE SCREW M6X12 (10 PCS.) 1

98 314-454 WASHER (A) 2

99 318-130 SET NUT 1

100 317-352 TAPPING SCREW D5X10 5

101 314-526 BLADE GUARD 1

102 314-527 FLAT WASHER M8X15 2

----

--- 39 ---

PARTS

C 10RA2

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

103 314-528 PIVOT SUPPORT 2

104 949-455 SPRING WASHER M6 (10 PCS.) 4

105 949-556 NUT M6 (10 PCS.) 4

106 967-469 HEX. SOCKET SET SCREW M6X6 2

107 314-533 ANCHOR BLOCK 1

108 314-534 FLAT WASHER M9.5 1

109 307-410 BOLT (W/WASHERS) M8X16 (BLACK) 1

110 314-529 SPECIAL BOLT M6X35 1

111 949-455 SPRING WASHER M6 (10 PCS.) 4

112 949-255 MACHINE SCREW M6X12 (10 PCS.) 4

113 314-530 BRACKET 1

114 314-531 SPACER 1

115 949-556 NUT M6 (10 PCS.) 1

116 314-535 COMPRESSION SPRING 20L 1

117 314-536 FLAT WASHER M16 1

118 314-537 COMPRESSION SPRING 57L 1

119 314-538 REGULATING BOLT 1

120 949-518 ROLL PIN D3X18 (10 PCS.) 1

121 973-361 WASHER 4

122 996-577 BOLT (W/WASHERS) M6X12 (BLACK) 4

123 314-539 BODY SHELL 1

124 WARNING LABEL (B) 1

125 WARNING LABEL (A) 1

126 NAME PLATE 1

127 314-555 SEGMENT GEAR 1

128 HITACHI LABEL 1

129 314-532 FLAT WASHER M6X25 2

130 314-556 TENSION HANDLE 1

131 314-557 WHEEL 1

132 314-558 HANDLE 1

133 314-534 FLAT WASHER M9.5 1

134 314-560 LABEL 1

135 318-131 PAN HD. TAPPING SCREW D4X12 3

136 314-561 POINTER BRACKET 1

137 949-433 BOLT WASHER M8 (10 PCS.) 1

138 949-558 NUT M8 (10 PCS.) 1

139 314-562 NEEDLE POINTER 1

140 314-580 TOOTHED LOCK WASHER M5 1

141 949-235 MACHINE SCREW M5X8 (10 PCS.) 1

142 314-541 EXTENSION SUPPORTER (L) 2

143 314-542 SPONGE 4

144 314-548 STRAIN RELIEF (RA-1418) 1

145 308-946 BOLT (W/WASHERS) M8X20 (BLACK) 4

146 314-540 SET PLATE 4

147 317-285 SWITCH BOX 1

148 314-544 STRAIN RELIEF (RU-1435) 1

149 949-429 BOLT WASHER M4 (10 PCS.) 3

150 314-545 TAPPING SCREW D4X10 3

151 314-456 POWER CABLE 1

152 314-457 CIRCUIT BREAKER SWITCH 1

153 308-946 BOLT (W/WASHERS) M8X20 (BLACK) 8

: ALTERNATIVE PARTS

----

--- 40 ---

PARTS

C 10RA2

: ALTERNATIVE PARTS

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

154 314-547 EXTENSION SUPPORTER (R) 2

155 314-549 TAPPING SCREW D5X16 2

156 318-132 PAN HD. TAPPING SCREW D4X8 2

157 314-553 TOOTHED LOCK WASHER M4 2

158 314-458 SWITCH PLATE 1

159 314-459 ROCKER SWITCH 1

160 317-158 INTERNAL WIRE 1

161 318-274 RUBBER STOPPER 1

201 314-451 SPINDLE ASS’Y 1 INCLUD.202,206-210

202 314-567 PARALLEL KEY 1

203 949-217 MACHINE SCREW M4X12 (10 PCS.) 4

204 949-453 SPRING WASHER M4 (10 PCS.) 4

205 314-572 BEARING RETAINER 1

206 620-4VV BALL BEARING 6204VVCMPS2L 1

207 314-568 COLLAR FOR D17 1

208 314-569 HELIX GEAR 1

209 967-261 RETAINING RING FOR D17 SHAFT 1

210 314-570 NEEDLE BEARING 1

211 314-575 BRACKET 1

212 314-452 ARMATURE ASS’Y 115V 1 INCLUD.213,214,219

213 620-1VV BALL BEARING 6201VVCMPS2L 1

214 620-0VV BALL BEARING 6200VVCMPS2L 1

215 314-578 BAFFLE 1

216 314-579 TAPPING SCREW D5X60 2

217 314-580 TOOTHED LOCK WASHER M5 2

218 314-453 STATOR 115V 1

219 314-577 BEARING BUSHING 1

220 314-583 BRUSH CAP 2

221 999-044 CARBON BRUSH (1 PAIR) 2

222 314-585 HOUSING ASS’Y 1 INCLUD.223,226

223 314-586 BRUSH HOLDER 2

224 949-454 SPRING WASHER M5 (10 PCS.) 4

225 949-245 MACHINE SCREW M5X30 (10 PCS.) 4

226 967-377 HEX. SOCKET SET SCREW M5X8 2

227 314-544 STRAIN RELIEF (RU-1435) 1

228 MOTOR NAME PLATE 1

----

--- 41 ---

: ALTERNATIVE PARTS

C 10RA2

STANDARD ACCESSORIES

OPTIONAL ACCESSORIES

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

701 314-590 WRENCH 22MM 1

702 314-591 WRENCH 23/26MM 1

703 314-592 ELBOW 1

704 314-616 TCT SAW BLADE 255MM-D15.88 HOLE-NT36 1

705 314-819 STAND 1

ITEM

No. CODE NO. DESCRIPTION NO.

USED

REMARKS

901 314-325 TABLE INSERT FOR CUTTER 1

902 314-324 PUSH STICK 1

----

Printed in Japan

(990715 N)
