HR91 FAQ & Setup Guide

Intro:

What is HR91?

HR91 is our new wireless radiator valve working with Evohome Wifi. It’s was

developed for homeowners that will use their Evohome unit or their mobile as the

primary way to control and monitor their heating system, instead of interacting

directly with the radiator valve.

What is different between HR91 and HR92?

HR92 allows you local temperature adjustment through the dial and direct status

check via the display. With HR91 you can directly set the temperature to a

predefined set-point of 21°C or 5°C and you can check the status of the radiator

through LED indications. Also HR92 allows you modify different parameters

including: auto window fall/rise rate, valve stroke range, temperature offset and valve

position display.

Can I activate or deactivate the open window function?

Yes you can do it from the Evohome controller, with a default duration of 30 minutes.

Can I use the child-lock feature in HR91?

Yes you can activate it from the Evohome controller.

How It Works:

How do I bind the TRV to Evohome?

Press and hold the right button for 5 seconds

Until the right LED flashed orange

A permanent green LED will indicate a succesful binding

The binding mode will last for 2 minutes and if the

device is not able to bind the LED will stop flashing

How do you check the status of the valve?

Once you install your TRV short press right

button to check the status of the device

A green LED flash indicates that your device is working properly

A permanent orange LED indicates that the battery levels are low.

A permanent red LED indicates a mounting issue.

A red LED flash will indicate a signal issue:

signal lost or the device is not bound.

Evohome controller will reactively provide you with

the device’s status regardless pressing the button

How do I check the signal strength?

Put your Evohome Controller should be in “RF COMMS CHECK” mode.

Press and hold both TRVs buttons for 5 seconds until both

LED are flashing amber Following that action you will be

able to view the signal strength in your Evohome controller.

How do I clear the binding?

Press and hold the right button for 10 seconds once

the bind is cleared the right LED will flash RED

How do I change the temperature?

By pressing the left button will set the device

to 5 °C and the left LED will flash orange

If you press again the same button the temperature

will go to 21 °C and the left LED will flash green

The set-point in both cases will remain until the next scheduled set-point.

The override button was developed to be used as a fail safe mechanism for

an occasion that you can’t have access to Evohome or your app.To maximize

your comfort levels, adjust your temperature via Evohome or your mobile app.

How do I identify the device’s zone name?

Once you bound the device, press the right button then

the zone’s name will pop up to your Evohome controller

User Interface Guide – Troubleshooting

Binding the device

Once batteries are

inserted the TRV

confirms this by

flashing both LEDs

green for 5 secs

If inserted

batteries are low,

LED permanently

Amber (5 secs)

Press binding

button for 5

seconds

Right LED will

flash amber for up

to 2 minutes whilst

binding

Succesful binding

is confirmed by

right LED showing

permanently green

for 5 seconds

After 2 minutes

binding timesout

(if unsuccessful)

TRV will return to

normal default

mode

Short press

binding button

Green flash (5

secs) indicates no

issue

Permament amber

(5 secs) indicates

the battery is low

Permanent amber

(3 secs) Batteries

are critical, less

than 2.1V. Buttons

function locked

Permanent red (10

secs) indicates a

mounting issue

Red flash (10

secs) indicates a

signal issue

(signal lost or not

bound)

User Interface Guide – Troubleshooting

Turn the device OFF (5°C)

Turn the device ON (21°C)

To turn the TRV

off, short press

the on/off button

The left LED with

flash amber for 5

seconds

To turn the TRV

on, short press

the on/off button

The left LED with

flash green for 5

seconds

Unbinding the Device

Signal Strength

Press binding

button for 10+

seconds

After 10 seconds

LED will flash red

for 10 seconds

When in RF

Comms Check,

hold both buttons

for 5 seconds

Both LED will

flash amber for

up to 10 minutes

Zone Identification

Locked Device

Short press

binding button

Right LED will

flash green for 5

seconds

Press both

buttons to check

if TRV is locked

TRV is locked if

both LED are red

for 3 seconds
