MS9540 VoyagerCG

Honeywell’s MS9540 VoyagerCG®hand-held, single-line laser scanner

offers aggressive scanning of all standard 1D bar codes.

The Voyager series of hand-held, single-line scanners have united

form with function in becoming the industry benchmark for value and

performance.

This sleek scanner features patented automatic infrared activation and

decodes all standard 1D bar codes, including GS1 DataBarTM (formerly

known as RSS codes).

VoyagerCG also includes patented CodeGate®technology which

allows the user to easily target the desired bar code and complete

data transmission with the press of a single button.

For presentation scanning, Honeywell offers a stand with automatic

in-stand detection technology

The MS9541 VoyagerHDTM is ideal for applications that require high-

density scanning, delivering quick and accurate scanning of 1D bar

codes as small as 3 mil.

Expand scanner functionality by purchasing the MS9544 VoyagerPDFTM,

which delivers aggressive scanning of all standard 1D bar codes

including PDF.

For more information on the MS9540 VoyagerCG single-line laser

scanner, please visit www.honeywell.com/aidc

Single-Line Laser Scanner

Automatic Trigger:• Use scanner as either a hand-held

device or a ﬁxed presentation scanner when mounted in

the stand

650-nanometer laser:• High-visibility laser allows user to

place laser line on selected bar code

CodeGate:• Zero in on desired code and complete data

transmission with the push of a single button—ideal for

menu scanning applications

Flash ROM:• Future proof POS system with free ﬁrmware

updates via MetroSet®2 software and standard PC

Parsing (Data Editing):• Format bar code data to meet

host system’s speciﬁc requirements

Features

Honeywell Security & Data Collection

Honeywell Scanning & Mobility

90 Coles Road

Blackwood, NJ 08012

856.228.8100

www.honeywell.com

For more information:

www.honeywell.com/aidc

RoHS

2002/95/EC

MS9540-DS Rev A 01/09

MS9540 VoyagerCG Technical Speciﬁcations

Operational

Light Source Visible Laser Diode 650 nm ± 10 nm

Visual Indicators Green = ready to scan; Red = good read;Yellow = automatic scanning

Host System Interfaces USB, RS232, Keyboard Wedge,

IBM 46xx (RS485), OCIA, Laser Emulation, Light Pen Wand Emulation

Mechanical

Dimensions (LxWxH) 198 mm x 78 mm x 56 mm (7.8˝ x 3.1˝ x 2.2˝)

Weight 149 g (5.3 oz)

Electrical

Input Voltage 5 VDC ± 0.25 V

Operating Power (typical) 825 mW (165 mA @ 5 V)

Standby Power (typical) 600 mW (120 mA @ 5 V)

DC Transformers Class 2: 5.2 VDC @ 1 A

Laser Class Class 1: IEC60825-1, EN60825-1

EMC FCC Part 15, ICES-003, EN55022 Class B

Environmental

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -40°C to 60°C (-40°F to 140°F)

Humidity 5% to 95% relative humidity, non-condensing

Drop Designed to withstand 1.5 m (5´) drops

Environmental Sealing Sealed to resist airborne particulate contaminants

Light Levels 4842 Lux (450 foot-candles)

Scan Performance

Scan Pattern Single scan line

Scan Speed 72 scan lines per second

Scan Angle Horizontal: 50°

Print Contrast 35% minimum reﬂectance difference

Pitch, Skew 68°, 52°

Decode Capabilities Reads standard 1D and GS1 DataBar symbologies. PDF417 reading available in MS9544 only.

Visit www.honeywell.com/aidc/symbologies for details.

Warranty 5 year factory warranty

MS9541 Typical Performance*

Narrow Width Depth of Field

4.0 mil 6 mm - 38 mm (0.3˝ - 1.5˝)

6.8 mil 0 mm - 76 mm (0˝ - 3.0˝)

10.4 mil 0 mm - 108 mm (0˝ - 4.3˝)

13 mil 0 mm - 140 mm (0˝ - 5.5˝)

*Resolution: 3 mil (0.076 mm)

*Performance may be impacted by bar code

quality and environmental conditions

MS9540 / MS9544 Typical Performance*

Narrow Width Depth of Field

5.2 mil 13 mm - 51 mm (0.5˝ - 2.0˝)

7.5 mil 0 mm - 127 mm (0˝ - 5.0˝)

10.4 mil 0 mm - 165 mm (0˝ - 6.5˝)

13 mil 0 mm - 203 mm (0˝ - 8.0˝)

21 mil 25 mm - 254 mm (1.0˝ - 10.0˝)

*Resolution: 5 mil (0.127 mm)

*Performance may be impacted by bar code

quality and environmental conditions
