Quick Check® 800 Series

Barcode reproduction accuracy is critical throughout the supply

chain. Honeywell helps assure that you can produce, receive,

and use barcodes meeting these tough requirements with Quick

Check desktop barcode veriﬁers. The QC800 veriﬁers analyze

barcode quality against traditional quality parameters and ISO/IEC

barcode print quality guidelines. Each unit includes all standard

symbologies and is manufactured and traceable to NIST (National

Institute of Standards and Technology) standards developed by

the UCC (Uniform Code Council) and AIM (Automatic Identiﬁcation

Manufacturers).

The QC800 Series Bar Code Veriﬁer offers the convenience of

simple point-and-shoot veriﬁcation through the use of a QC3800VE,

a customized, 3800 handheld linear imager. Quickly perform pass/

fail testing of dimensional and format quality parameters like average

bar deviation, wide-to-narrow ratios, encodation, and ISO/IEC

decodability. Full traditional and ISO/IEC dimensional, reﬂectance,

and format tests can also be performed using optional mouse and

pen style wands. In mouse wands choose from 3, 5, 6, 10, and 20

mil sizes, and in pen wands choose from 5, 6, and 10 mil sizes.

Results can be sent to a PC via an RS-232 communication interface

or the QCViewerII software. If a PC is not available, detailed hard-

copy results can be printed using the optional Quick Check printer.

Rechargeable batteries give users the ﬂexibility to take the QC800

wherever barcode veriﬁcation is required.

Test ISO/IEC and Traditional Quality Parameters

Menu-Driven for Easy Use

LCD and LEDs Display Test Results Instantly

Command Codes for Instant Programming

•

QC3800VE for simple point and shoot testing

Full ISO/IEC when using optional Mouse and Pen wands

Rechargeable batteries and integrated display enable taking

the QC800 series anywhere veriﬁcation capabilities are

required

•

Barcode Veriﬁer

Features

QC800 Series Speciﬁcations

QC800-DS Rev B 3/08

Features

Special reﬂectometer mode

“X” dimension determination

Data buffer (code content dependent)

Single Scan To Result (SSTR) menu

Command code programming

ANSI/CEN/ISO scan proﬁle test method

Instant “On-Screen” ISO/IEC grade

ISO/IEC 10-scan grade averaging

Veriﬁcation Methods

Parameters determined by ISO/IEC bar code print quality guidelines and traditional pass/fail criteria. Refer to model matrix below for conﬁgurations.

QC8xx*

ISO/IEC: X

Traditional: X

*QC800 Series veriﬁers include a handheld bar code linear imaging reader and provide ISO/IEC decodability/decode and dimensional traditional test results.

Full ISO/IEC results are provided using an optional mouse or pen wand.

To complete the QC800 series model number conﬁguration above, substitute XX with either 00, 10, 20, 30, or 50 from the list below. (For example, the retail version

of the QC800 series veriﬁer = QC810.)

00 = Symbologies only, no applications

10 = Retail

(SCC retail shipping-UCC/EAN ITF, UCC/EAN 128; UPC Coupon Code; SISAC; Bookland)

20 = Healthcare

(HIBCC; CCBBA; SCC retail shipping-UCC/EAN ITF, UCC/EAN 128)

30 = Industrial / Government

(LOGMARS; AIAG; ABCD/CTIA; SCC retail shipping-UCC/EAN ITF, UCC/EAN 128)

50 = All industry applications

(SCC retail shipping-UCC/EAN ITF, UCC/EAN 128; UPC Coupon Code; AIAG; LOGMARS; HIBCC;

SISAC; CTIA/ABCD; Bookland; CCBBA)

Dimensions

Height: 2.8 in. (7.1 cm)

Width: 4.3 in. (10.9 cm)

Length: 5.3 in. (13.5 cm)

Mechanical

Weight: 16 oz. (454 g)

Power: 4 AA rechargeable NiCad batteries and AC charger

Case: Lexan polycarbonate 141

Beeper: A single beeper provides an audible valid/invalid signal and a triple beep on known out of spec codes

Display: 4 line X 20 character LCD

Keypad: 6-button, power, select (4 arrows)

LEDs: 5 tri-colored LEDs

Environmental

Operating Temperature: 32° to 122° F (0° to 50° C)

Storage Temperature: 14° to 158° F (-20° to 70°C)

Relative Humidity: 5% to 95% Non-condensing

Optical

Test Aperture: Mouse: 3, 5, 6, 10, or 20 mil

Pen: 5, 6, 10 mil

Linear Imager: min. “X” dimension 5 mil Beam width: 5.25 in. (13.3cm)

Wavelength: Visible: 660nm

Infrared: 940nm

Symbologies

EAN/UPC with addenda, Code 39 (1-49 characters), Interleaved 2 of 5 (2-78 characters), Codabar, Code 128 (1-70 characters), MSI (1-50 characters), Code 16K

(individual rows), Code 49 (individual rows), Code 93, Code 11, Regular 2 of 5 (Discrete/Industrial 2 of 5), IATA 2 of 5 (Straight 2 of 5), Database look-up feature

Safety/Regulatory

FCC Class A, CE Certiﬁed

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Automation and Control Solutions

Honeywell

Imaging and Mobility

700 Visions Drive

PO Box 208

Skaneateles Falls, NY 13153-0208

www.honeywell.com/aidc
