Hoshizaki F-450MAH Manuale utente

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com

FLAKER/C BELET DIMENSIONS

WxDxH

F-450MAH(C)

4/08

Item # 13133

MOD LAR FLAKER/C BELET ICE MACHINE

Warranty

Valid in United tates, Canada, Puerto Rico, & U. .Territories. Contact factory for warranty in

other countries.

Two Year - Parts & Labor on entire machine.

Five Year - Parts on Compressor, air-cooled condenser coil.

F-450MAH(C)

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

F-450MAH(C)

22 x 273/8 x 217/8

SLIM-LINE SERIES

*AutoCad available on KCL

F-450MAH

•U to 476 lbs. of ice roduction er 24 hours

F-450MAH-C

•U to 426 lbs. of ice roduction er 24 hours

F-450MAH & F-450MAH-C

•Durable stainless steel exterior

•CleanCycle12®Design

•15 minute flush cycle every 12 hours

•Removes sediment

•Cleaner ice

•Longer life and easy maintenance

•Removable air filters (Air-cooled model only)

•R-404A Refrigerant

B-900

B-800

B-700

B-500

B-300

F-450MAH

Air-Cooled

hown on an optional

B-300

F-450MAH-C

Air-Cooled

Also ava lable on Large B ns:

B-1150SS

B-1300SS

B-1500SS

B-1650SS

Hoshizaki

DIMENSIONS

WxDxH

F-450MAH(C)

22 x 273/8 x 217/8

©HOSHIZAKI AMERICA, INC.

F-450MAH(C) FLAKER/C BELET ICE MACHINE

SLIM-LINE SERIES

TILITY CONS MPTION

AIR-COOLED / F-450MAH

Model Number

70˚

50˚ 70˚

476

90˚

80˚

90˚

Approximate

Electrical

KWH per

100 LBS.

90/70 70/50

F-450MAH

Air Temp˚ F.

Water Temp˚ F.

SPECIFICATIONS

Model Number Condenser Amperage Min. Circuit

Ampacity Shipping

Weight

11.0 20 175 lbs.

Air-Cooled

F-450MAH

6.2 12.0

416

362

456

397

435

379

330

F-450MAH-C Air-Cooled 11.0 20 175 lbs.

915 858

355

90/70 70/50

4.3

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water Pressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PL MBING/F-450MAH(C)

• 115V/60/1

• 20 amp Max Fuse/HACR Breaker ize

• 3/8” OD copper or equivalent independent water supply

• 3/4” FPT independent drain connection

SERVICE

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filter

(Air-Cooled model only)

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com Printed in U.S.A.

•Air-cooled - Flaker ice machine

• Air-cooled - Cubelet ice machine

AIR-COOLED / F-450MAH-C

70˚

50˚ 70˚

426

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

368

317

407

350

387

333

287

310

F-450MAH-C 7.4 12.0

956 880 5.0

STOR AGE B I NS

Model Number Application Capacity ARI-Rated Capacity

B-500 500 lbs. 360 lbs.

B-700 700 lbs. 550 lbs.

B-300 300 lbs. 260 lbs.

B-900 900 lbs. 660 lbs.

B-1150 1150 lbs. N/A

B-800 800 lbs. 600 lbs.

B-1500 1490 lbs. N/A

B-1650 1605 lbs. N/A

B-1300 1275 lbs. N/A

FRONT IEW SIDE IEW

AIR-COOLED UNIT

ICE DROP ZONE

Potable

Water Gal.

per 100 lbs.
