Hoshizaki KM-255BAH Manuale utente

•Up to 235 bs. of ice production per 24 hours

•Bui t-in 120 bs. ice storage

•Individua crescent cube

•Protected by HoshiGuard Antimicrobia Agent

•Cyc eSaver®Design

•EverCheck®a ert system

•Stain ess stee evaporator

•Corrosion-resistant stain ess exterior surfaces provide onger ife

•Removab e air fi ter

•Comp ies with Ca ifornia Energy Commission guide ines (CEC)

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com

C BER DIMENSIONS

WxDxH

KM-255BAH

4/08

Item # 13207

CRESCENT C BER WITH B ILT-IN STORAGE BIN

Warranty

Valid in United States, Canada, Puerto Rico, & U.S. erritories. Contact factory for warranty in

other countries.

Three Year - Parts & Labor on entire machine.

Five Year - Parts & Labor on: Evaporator.

Five Year - Parts on: Compressor, air-cooled condenser coil.

KM-255BAH

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-255BAH

30 x 28 x 39*

*with 6" legs

*AutoCad available on KCL

KM-255BAH

Air-Cooled

Shown

KM-255

Hoshizaki

DIMENSIONS

WxDxH

©HOSHIZAKI AMERICA, INC.

KM-255BAH

CRESCENT C BER WITH B ILT-IN STORAGE BIN

TILITY CONS MPTION

AIR-COOLED

Model Number

70˚

50˚ 70˚

235

90˚

80˚

90˚

Ice Production

Per Cycle

KWH per

100 LBS.

Pot ble

Wter

Gl. per

100 lbs.

Lbs. Cubes

Air Temp˚ F.

W ter Temp˚ F.

SPECIFICATIONS

Model Number Condenser Amper ge Shipping

Weight

9.6 24.7

229

227

216

207

191

184

4204

207

90/70

Condenser

Wter

Gl. per

100 lbs.

N/A

O P E R AT I N G L I M I T S

• Ambient emp Range 45 - 100˚F

• Water emp Range 45 - 90˚F

• Water Pressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PL MBING/KM-255BAH

• 115V/60/1

• 3/8” ODcopper or equivalent independent potable water supply

• 3/4” FP independent drain connection

• 1/2” Potable water inlet

SERVICE

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filters

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com Printed in U.S.A.

KM-255BAH

30 x 28 x 39*

*with 6" legs

KM-255BAH

9.0 220 lbs.

Air-Cooled

KM-255BAH

AIR-COOLED UNIT

SIDE VIEW

• Air-cooled

6-3/4"

(172 mm)

(76 mm)

28-5/16"

(720 mm)

5-3/4"

(143.5 mm)

1-5/8"

(40 mm)

WATER INLET

1/2" FPT

POWER CORD

SUPPL

DRAIN

3/4" FPT

19-7/8"

(505 mm)

2-11/16"

(70 mm)

34-1/4"

(870 mm)

10-3/4"

(273 mm)

26-7/8"

(683 mm)

3/4"

(19 mm)

1-13/16"

(46 mm)

21˚

44˚

FRONT VIEW

30"

(762 mm)

32-7/8"

(835 mm)

(152 mm)

1-3/4"

(44 mm)

1-3/4"

(44 mm)

26-1/2"

(674 mm)
