Hotpoint RB787WC Manuale di servizio

Specification Created 7/00

RB787WC/BC - Hotpoint 30" Free-Standing Self-Cleaning Electric Range

Dimensions (in inches)

Listed by

Underwriters

Laboratories

All Hotpoint ranges are equipped

with an Anti-Tip device. The

installation of this device is

an important, required step in

the installation of the range.

26-3/8*

46-3/8

1/4†

29-7/8

46-1/2

CENTER LINE

2-1/4

7-1/2

2-1/4

3-1/2

REAR

WALL

†The range may be placed with

0" clearance (flush) at the back

wall and side walls if the range

side trims extend beyond the

cabinet fronts at least 1/4".

Self-Clean models only

†Note: Check local codes for required breaker size.

A properly grounded branch circuit with a 3 prong grounding type

receptacle is required for Hotpoint ranges.

Note: 30" Electric Ranges conform to U.L. requirements for 0" spacing

from walls below countertops. However some kitchen cabinet

finishes can be damaged by heat from the range heating elements. It

is recommended that a clearance of at least 1-1/2 inches be maintained

to walls. Where varnished wood or plastic film finishes are used, a

minimum clearance of 6 inches should be maintained.

Receptacle Locations: Locally approved flexible service cord or conduit

must be used because terminals are not accessible after range

installation. See shaded area in drawing for location of electrical outlet

box. Recommended outlet locations allow range to be installed directly

against rear wall.

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

KW Rating

240V 10.5

208V 7.9

Breaker Size

40 Amps†

*Dimension from wall to front of closed oven door.

Dimension from wall to the front of closed oven

door handle is 28-1/2.

Specification Created 7/00

RB787WC/BC - Hotpoint 30" Free-Standing Self-Cleaning Electric Range

OFF

MED

FRONTREAR

OFF

MED

OFF

SURFACE

UNITS

MED

FRONT

REAR

OFF

MED

OVEN

LIGHT

OVENON

AUTO

SELF

CLEAN

PREHEATED

BROIL

OFF

200

250

300

350

400

450

500

550

LATCH

DOOR

TIMER

CLOCK

START

TIME

COOK

TIME

AUTOMATICOVEN

HOURMIN

ON/OFF

MIN

OVENCLEANING –

MOVEDOORLATCHTORIGHT.TOUCH"SELFCLEAN"PAD.TOUCH"START"PAD

Features and Benefits

•5.0 Cu. Ft. Self-Cleaning Oven

•Ribbon Patterned Cooktop

•Two 8" and Two 6" Ribbon Heating Elements

•Auto Self-Clean with Variable Cleaning Time

•EasySet Electronic Oven Controls

•Electonic Digital Clock and Minute Timer

•Automatic Oven Timer

•2 Oven Shelves

•Auto Oven Shut-Off

•Audible Preheat Signal

•Hot Surface Indicator Lights

•Broiler Pan with Grid

•Interior Oven Light

•Lift-Off Glass Oven Door with Window

•Full-Width Storage Drawer

•Designer-Style Handle

•Model RB787WCWW - White on white

•Model RB787BCBB - Black on black
