Specification Created 1/10

410398

HTH18GBT – Hotpoint®ENERGY STAR®18.2 Cu. Ft. Top-Freezer Refrigerator

Front View Top View

'94 TMNF Refer

Note: Before installing, consult installation instructions packed with product

for current dimensional data.

Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you

face the front of the refrigerator, the handle is on your left and the

hinges are on your right.

All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you

face the front of the refrigerator, the handle is on your right and the

hinges are on your left.

Height to top of hinge (in.) A 67-3/8

Height to top of case (in.) B 66-7/8

Height to mid-freezer (in.) 57

Case depth without door (in.) C 26-3/4

Case depth less door handle (in.) D 30-1/2

Case depth with door handle (in.) E 32-3/8

Depth with fresh food door open 90° (in.) F 56-3/8

Width (in.) G 28

Width with door open 90° with door handle (in.) H 30-3/4

Each side (in.) 3/4

Top (in.) 1

Back (in.) 1

Air Overall

Clearances Dimensions

Total volume and shelf

area are calculated by

the Association of Home

Appliance Manufacturers’

standards.

Listed by

Underwriters

Laboratories

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Created 1/10

410398

HTS15BBR / HTH15BBR / HTS15BCR / HTS16ABR / HTS16BBR

HTS16BCR / HTS16HBR / HTS17BBR / HTS17BCR

Features and Benefits

• Upfront Temperature Controls - Are positioned up front, close at hand, for maximum convenience and

ease of use

• Adjustable Glass Shelves - Lets consumers maximize usable storage space

• Gallon Door Storage - Makes room for milk and any other gallon size containers

• Can Storage Shelf - Soda can storage shelf conveniently dispenses soft drinks

• Vegetable/Fruit Crisper - For easy storage of fruits and vegetables

• NeverClean™ Condenser - Condenser coils are encased, so they don’t require cleaning in normal

operating environments

• Deluxe Quiet Design - Significantly reduces operating noise

• Square Doors - Classic design that’s compatible with any kitchen décor

• Model HTH18GBTWW – White

• Model HTH18GBTCC – Bisque

HTH18GBT – Hotpoint®ENERGY STAR®18.2 Cu. Ft. Top-Freezer Refrigerator
