HP Wireless Elite Keyboard User Manual
v1.0.EN
Part number: 510676-001
Contents
Installation and Uninstallation.............................................................................1
Battery Level Indicators ......................................................................................1
TouchSmart PC Functions ...................................................................................2
Troubleshooting................................................................................................2
HP Wireless Elite Keyboard User Manual 1
Installation and Uninstallation
Installing the HP Wireless Elite Keyboard
1Plug the receiver into an available USB port.
2Insert the HP Wireless Elite Keyboard Companion CD into the CD/DVD drive. Installation starts automatically and creates
the HP Wireless Elite Keyboard folder under All Programs. This folder contains the following:
Uninstalling the HP Wireless Elite Keyboard
1Click Start > All Programs > HP Wireless Elite Keyboard > Uninstall HP Wireless Elite Keyboard.
2Follow the onscreen instructions.
Battery Level Indicators
Displaying the Battery Level Indicators
•Click Start > All Programs > HP Wireless Elite Keyboard > Keyboard Battery.
The Keyboard Battery icon appears in the Windows System Tray (bottom right of the screen).
The following icons show you when to change the batteries in the keyboard:
70%~100% (Green)
40% ~70% (Yellow)
0%~40% (Red)
NOTES:
•When you plug in the receiver, the Battery indicator icon reappears if previously enabled.
•To update the Battery Level Indicator:
Keyboard: Fn+Space Key
•The Battery indicator icon takes at least 10 minutes to change color.
Hiding the Battery Level Indicators
•Right-click the Keyboard Battery icon in the Windows System Tray, and select Hide HP Wireless Elite Keyboard.
NOTE: If you remove the receiver, the Battery Level Indicator in the Windows System Tray (if previously enabled) and
Battery shortcut in All Programs are hidden.
TouchSmart PC Functions
The Fn+F9, Fn+F10, and Fn+F11 keys work only on the TouchSmart PC and the default functions are compatible only with
HP TouchSmart IQ504t and IQ506t series PCs.
To access the OSD (On-screen display) for these keys, press Fn+F9, Fn+F10, or Fn+F11 depending on the key you want to
display.
Troubleshooting
•I cannot find the Keyboard Battery icon in the Windows System Tray and the HP Wireless Elite Keyboard folder.
•Reboot your PC.
•I know my battery is weak but the Keyboard Battery icon in the Windows System Tray and the HP Wireless Elite
Keyboard folder do not show the correct color.
•The Battery indicator icon takes at least 10 minutes to change color.
•Function keys Fn+F9, Fn+F10, and Fn+F11 do not work on my PC.
•These keys work only on the TouchSmart PC.
•After Hot Swap/Hot Plug I cannot find the Keyboard Battery icon in the Windows System Tray.
•Wait about 30 seconds.
•Click Start > All Programs > HP Wireless Elite Keyboard > Keyboard Battery.
2HP Wireless Elite Keyboard User Manual
